OPERATING PROCEDURES AND SAFETY INSTRUCTIONS
CAUTION:
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER NO USER FRIENDLY PARTS
Battery Chargers
Sealed or Valve Regulated
Lead Acid Batteries
Model: PSC-124000AP
CAUTION
THIS UNIT SHOULD NOT BE USED IN OUTDOOR APPLICATIONS.
EXPOSURE TO MOISTURE MAY RESULT IN FIRE OR SHOCK HAZARD
1
Advertisement
Table of Contents
Related Manuals for Power-Sonic PSC-124000AP
Summary of Contents for Power-Sonic PSC-124000AP
- Page 1 Battery Chargers Sealed or Valve Regulated Lead Acid Batteries Model: PSC-124000AP OPERATING PROCEDURES AND SAFETY INSTRUCTIONS CAUTION: CAUTION TO PREVENT THE RISK OF ELECTRIC SHOCK, DO THIS UNIT SHOULD NOT BE USED IN OUTDOOR APPLICATIONS. NOT REMOVE COVER NO USER FRIENDLY PARTS...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS PLEASE SAVE THESE INSTRUCTIONS This document contains important safety and operating instructions for Model PSC-124000AP battery chargers. Before using the battery charger, please read all instructions and cautionary markings on the battery charger, the battery, and the product using the battery.
- Page 3 GENERAL DESCRIPTION This unit is a parallel charger . It is designed to simultaneously float charge a battery while supporting or supplementing a parallel load This model is a two stage, constant voltage battery charger with current limiting, current fold back, and automatic temperature compensation of the output voltage.
- Page 4 constant current mode intermittently as the parallel load requires, or when charging a discharged battery. The indicator light will switch from yellow to green when the unit is operating in the constant voltage mode at about 75%, or less, of its maximum rated current. In the constant voltage mode the unit is regulating voltage and the battery is being properly charged.
- Page 5 TROUBLESHOOTING NO INDICATOR LIGHT - If the indicator light is dark, check the fuse and replace if necessary. If the fuse is good, check the voltage switch setting and input power (is the receptacle controlled by a light switch?). If all else appears normal then the charger probably needs repair. NO CHARGE INDICATOR, NOT CHARGING - If the charger will not go into charge mode (yellow indica- tor) then the battery is probably already charged.
- Page 6 Power-Sonic Corporation 7550 Panasonic Way San Diego, CA 92154 Tel: 619-661-2020 Fax: 619-661-3650 E-Mail: quality-assurance@power-sonic.com Website: http//www.power-sonic.com...
