  • Page 1 MX575A MX575B D/GPS Compass Installation Manual...
  • Page 2 As we are continously improving our products we retain the right to make changes to the product and the documentation at any time. Updated manuals are available from our website www.simrad- yachting.com and are free to download. Copyright 2010 by Navico Holdings AS.
  • Page 3 Unlike many other consumer electronics industries which only sell consumer electronic devices, your marine dealer is often your best advisor for installation and service of your new GPS receiver. Simrad strongly encourages you to utilize the knowledge and experience of your sales and service dealer.

  • Page 4: Table Of Contents

    Contents General .................... 1 1.1 MX575 D/GPS Beacon Operation ..........2 1.2 Satellite Based Augmentation System (SBAS) ....... 2 1.3 Receiver Autonomous Integrity Monitoring (RAIM) ..... 2 1.4 Understanding the MX575 D/GPS Satellite Compass ....3 1.5 Supplied Equipment ................ 4 MX575 Mounting ................
  • Page 5 MX575A/B DGPS Compass Figure 1 – MX575 Mounting Orientations............ 5 Figure 2– MX575 antenna location relative to other antennas ..... 6 Figure 3 - MX575 with Fixed-Mount base ........... 7 Figure 4 - MX575 with Pole-Mount base ............. 8 Figure 5– Fixed-Mount base ................. 9 Figure 6 - Bottom view of Fixed-Mount base ..........
  • Page 6 MX575A/B DGPS Compass Figure 31 – Standard connection to the MX500/MX510 Antenna port through the MX5XX junction box .............. 29 Figure 32 – MX575 connection to the MX512 Antenna port through the MX512 Junction Box .................. 30 Figure 33 – Alternative connection to MX420/2 CDU (PORT 2) as a GPS Satellite Compass only ................

  • Page 7: General

    MX575A/B DGPS Compass 1. General This manual describes the installation and operation of the MX575A & MX575B D/GPS Satellite Compass. They share common functionality and installation thus they will be generally called MX575. The specific model number will be called upon to describe a unique functionality.

  • Page 8: Mx575 D/Gps Beacon Operation

    MX575A/B DGPS Compass 1.1 MX575 D/GPS Beacon Operation The MX575 D/GPS Satellite Compass is an integrated GPS and beacon receiver unit that is fully automatic and usually does not require user intervention in most cases. It will automatically search for available GPS satellites and beacon differential stations as soon as power is applied.

  • Page 9: Understanding The Mx575 D/Gps Satellite Compass

    MX575A/B DGPS Compass satellites, incorrect pseudoranges, poor GPS satellite geometry, excessive atmospheric interference and problems at particular reference stations. The RAIM messages will only become available when it is connected to the MX 1.4 Understanding the MX575 D/GPS Satellite Compass The MX575 is a complete GPS heading and positioning system in a single enclosure that requires only one power/data cable connection.

  • Page 10: Supplied Equipment

    MX575A/B DGPS Compass 1.5 Supplied Equipment The following items are supplied with the MX575 Kit: Description Part Number MX575 A or B DGPS Compass Comprising: MX575A D/GPS Compass 3508 102 70900 (or) MX575B D/GPS Compass 000-10280-001- Sensor Accessories: 15m Power/data Cable...

  • Page 11: Mx575 Mounting

    MX575A/B DGPS Compass 2. MX575 Mounting The preferred orientation for the MX575 D/GPS Satellite Compass is parallel to the axis of the vessel. In other words, it should be pointing towards the bow of the boat. This mounting configuration will provide the ability for the MX575 to output the positioning, heading and pitch of the vessel.

  • Page 12: Mx575 Mounting Guidelines

    MX575A/B DGPS Compass should be programmed into the MX575 to calibrate its heading. Obviously, the physical orientation of the MX575 could be adjusted to correct for this deviation. MX575 Mounting Guidelines Install the MX575 where it has a clear view of the sky around it.

  • Page 13: Installation Procedure

    MX575A/B DGPS Compass 2.2 Installation Procedure 2.2.1 Mounting The MX575 may be mounted with either the fixed-base or pole-mounting base. Both mounts are supplied with the system. The fixed base allows you to mount the MX575 on horizontal flat surfaces, such as radar platforms.

  • Page 14: Fixed Base Mounting

    MX575A/B DGPS Compass The following figure shows the MX575 with the pole mount Figure 4 - MX575 with Pole-Mount base 2.2.2 Fixed Base Mounting The supplied fixed base is intended to allow you to mount the system on a flat surface.

  • Page 15: Figure 6 - Bottom View Of Fixed-Mount Base

    MX575A/B DGPS Compass The base also features four tunnels that allow you to bring the power/data cable out from within the mount in order to route it along the surface of the plate beneath the MX575 system. Alternatively, you may wish to route the power/data cable through the mounting surface rather than bringing it out through one of the tunnels.

  • Page 16: Figure 7- Running Cable Through The Fixed Base Mount

    MX575A/B DGPS Compass To install the MX575 using the fixed base, insert either end of the power/data cable through the center of the fixed base as shown in the following two figures. Figure 7- Running cable through the fixed base mount...

  • Page 17: Figure 9- Power/Data Cable Key And Keyway

    MX575A/B DGPS Compass Align the connector keyway of the cable to the key of the connector mounted on the MX575 enclosure as show in Figure 8. Insert the cable-mount connector into the bulkhead connector, aligning the locking ring at the same time.

  • Page 18: Figure 11- Fastening The Fixed-Base To The Mx575

    MX575A/B DGPS Compass Once you have secured the connector, slide the fixed base up to the bottom of the MX575 enclosure. There are two alignment keys on top of the base that must fit into two holes of the enclosure.

  • Page 19: Pole And Rail Mounting

    MX575A/B DGPS Compass Once you have fastened the fixed-base to the MX575 enclosure using six mounting screws, you are ready to fasten the assembly to your mounting surface. We recommend that you use machine screws that have an Allen Key head (hexagonal) and an “L-shaped”...

  • Page 20: Figure 13- Threading On The Lock Nut And Washer

    MX575A/B DGPS Compass Figure 13- Threading on the lock nut and washer When mounting the MX575 using the pole mount, the cable must be run first through the center of the pole mount base (from top to bottom), through the pole, and then through any bulkheads as needed (the power/data connector is too large to fit through the threaded portion of the pole mount base).

  • Page 21: Figure 14 - Running The Cable Through The Pole Base

    MX575A/B DGPS Compass The following three figures detail the process of routing the cable. Figure 14 - Running the cable through the pole base Figure 15- Running the cable through the pole base...

  • Page 22: Figure 16 - Running The Cable Through The Pole Mount

    MX575A/B DGPS Compass Figure 16 - Running the Cable through the Pole Mount Once you have routed the cable correctly through the pole mount base and the mounting pole, the mounting assembly should look like the following figures. Figure 17 - Completed cable run...

  • Page 23: Figure 18 - Threading The Pole-Base Onto The Mount

    MX575A/B DGPS Compass Thread the pole mount base onto the pole mount four to five full turns. Figure 18 - Threading the Pole-Base onto the mount Ensure that there’s a gap between the lock nut and washer, and the pole mount base as shown in the following figure.

  • Page 24: Figure 20 - Power / Data Cable Key And Keyway

    MX575A/B DGPS Compass At this point, fasten the cable to the MX575 connector. Notice that the connector on the receiver enclosure has a key and that the cable-mount connector has a keyway. The key and keyway need to align as you insert the cable-mount connector into the bulkhead connector.

  • Page 25: Figure 21 - Connected Power / Data Cable

    MX575A/B DGPS Compass Figure 21 - Connected Power / Data cable The next step is to fasten the MX575 enclosure to the pole mount base using the supplied self-tapping screws. The following figure illustrates this process. There are two alignment keys on top of the base that must fit into two holes of the MX575 enclosure.

  • Page 26: Figure 22 - Fastening The Pole Base To The Mx575

    MX575A/B DGPS Compass Figure 22 - Fastening the Pole Base to the MX575 The next step is to rotate the hex nut and washer up to the bottom surface of the pole mount base. Do not tighten them at this point as you will need to align the MX575.

  • Page 27: Figure 24- Locking The Mx575 Once Aligned

    MX575A/B DGPS Compass Orient the MX575 using the gun-sights on the top of the enclosure. Using an adjustable wrench, tighten the lock nut against the MX575 while ensuring accurate alignment of the MX575 system. Figure 24- Locking the MX575 once aligned Note: You will need to tighten the locking nut against the pole mount base tightly.

  • Page 28: Figure 25 - Lining Up The Alignment Sight

    MX575A/B DGPS Compass Figure 25 - Lining up the alignment sight Figure 26 - Correctly Lined-up alignment sight...

  • Page 29: Connecting To A Power Source

    MX575A/B DGPS Compass If you have another accurate source of heading data on your vessel, such as a gyro compass, you may use its data to correct for a bias in MX575 alignment using the MX CDU configuration. Alternatively, you may wish to physically adjust the heading of the MX575 so that it renders the correct heading measurement, however, adding a software offset (see pgs.

  • Page 30: Mx575 Operation

    MX575A/B DGPS Compass 3. MX575 Operation The MX575 D/GPS Satellite Compass is powered by connecting the Red (18 gauges) and Black (18 gauges) to an 8 to 36 VDC power source. Once powered, the MX575 will proceed through an internal start-up sequence, however it will be ready to communicate within a few seconds.

  • Page 31: Standard Data Interface To The Cdu

    MX575A/B DGPS Compass Wire Pair Color code Function Pin# Gauge Bare RF SHIELDED DRAIN Power GRND Power input BLK with BLU stripe RS-232, port A RX RS-232, port A TX Signal GRND BLK with GRN stripe RS-422-, port A RS-422+, port A...
  • Page 32 MX575A/B DGPS Compass MX575A/B VNDR# 051-0157-002 (16) Red/Wht RED(+12 VDC) (1) Blk/Shield BLK(GND) (8) Org YEL/BLK (9) Org/Wht MX420 CDU BLK/BRN (10) Yel (11) Yel/Blk (4) Brn In (A) (5) Brn/Wht In (B) (6) Prpl Out ( A) (7) Prpl/Wht...
  • Page 33 MX575A/B DGPS Compass MX420/2 MX575A RED (12 VDC) BLK (GND) MX420/2 JUNCTION BOX VNDR# 051-0157-002 Rs232 UPPER LOWER PORT 2 BLK/BRN B IN B OUT A IN A OUT YEL/BLK MX ANTENNA GREY PORT PURPLE CABLE A BLK/GRN B OUT...
  • Page 34 MX575A/B DGPS Compass Mx575 A/B MX420/8 RED (+12 VDC) BLK (GND) BLK/BRN (PORT B RX RS-232) MX420/8 JUNCTION BOX YEL (PORT B RS-422+) UPPER LOWER YEL/BLK (PORT B RS-422-) GREY PURPLE BLK/GRN GRY (SIGNAL GND) CABLE A B IN B OUT...

  • Page 35: Connection Using A 3-Meter Antenna Cable Assembly

    MX575A/B DGPS Compass MX500/MX510/MX512 Mx575 A/B ANT CONN. BLK/BRN YEL/BLK P/N 3508 102 70150 VNDR# 051-0157-002 10-PIN CABLE ASSY. (3 METERS) BLK/GRN W HT PRPL NOT CONNECTED CONNECTION VIA WIRE S PLICE OR T ERMINAL S TRIP Figure 30 – Standard connection to MX500/MX510/MX512 ANT port...
  • Page 36 MX575A/B DGPS Compass Figure 32 – MX575 connection to the MX512 Antenna port through the MX512 Junction Box...

  • Page 37: Alternative Data Interface

    MX575A/B DGPS Compass 3.3 Alternative Data Interface The MX575 can also be used as a source of true heading & ROT device only when connected to PORT 2 (or any other available ports other than PORT 3) as shown in Figure 32 and 33. The CDU will not change the default NMEA data output configuration of the MX575 in this setup.
  • Page 38 MX575A/B DGPS Compass MX575 A/B MX420/8 RED (+12 VDC) BLK (GND) MX420/8 JUNCTION BOX UPPER LOWER POWER GREY GRY (SIGNAL GND) PURPLE BLK/BRN (PORT B RS-232 +) CABLE A B IN B OUT PORT 2 A IN A OUT YEL/BLK (PORT B RS-422 -)

  • Page 39: Figure 35 - Mx575 Interface To Mx5Xx Cdu (Port 1) As A Gps Satellite Compass Only

    MX575A/B DGPS Compass Figure 35 - MX575 Interface to MX5xx CDU (PORT 1) as a GPS Satellite Compass only...

  • Page 40: Data Interface To Pc Or Other Navigation Systems

    MX575A/B DGPS Compass 3.4 Data Interface to PC or Other Navigation Systems Figure 35 shows the power and data I/O connections of the MX575 compass when using it to supply the position and heading data to a PC charting system using a 9-pin D-connector and terminal strip (these are user supplied items).

  • Page 41: Mx575 Configuration

    MX575A/B DGPS Compass 4. MX575 Configuration The MX CDU will automatically configure the navigation functionality of the MX575 when connected to PORT 3 (primary antenna input port) of the CDU. Additionally, it is necessary to configure the MX575 before you can view the True heading and ROT data in the CDU NAV screens.
  • Page 42 MX575A/B DGPS Compass In the MX420 CDU, go to the NAV 5 (Figure 40) and NAV 6 (Figure 41) screens. Here you will have both the Heading and Rate of Turn values displayed. The MX420 CDU can also pass through the HDT and ROT data to any data port selected.

  • Page 43: Configuring The Mx575 As A Gps Satellite Compass

    MX575A/B DGPS Compass 4.1 Configuring the MX575 as a GPS Satellite Compass Before beginning on this section, make sure the MX575 D/GPS Satellite Compass is connected to the MX420CDU as shown in Figure 33 to 35. In this manual, we used NMEA 2 I/O (or Port 2).
  • Page 44 MX575A/B DGPS Compass Figure 38 – Compass Setup with MX420 CDU Figure 39 – ROT Setup with MX420 CDU...

  • Page 45: The Nav 5 & Nav 6 Compass Display Screens

    MX575A/B DGPS Compass 4.2 The NAV 5 & NAV 6 Compass Display Screens Figure 40 – NAV 5 Compass Display Screen Figure 41 – NAV 6 Compass Display Screen...

  • Page 46: Mx575 Specifications

    MX575A/B DGPS Compass 5. MX575 Specifications The tables below provide the technical specifications of the MX575 D/GPS, communication, beacon sensor, GPS sensor, mechanical, power and environmental specifications Table 3 : Communication specifications Item Specification 2 full duplex RS-232 and 2 half-duplex...
  • Page 47 MX575A/B DGPS Compass < 2.0 m. RMS (autonomous, no SA)** Horizontal accuracy < 1.0 m RMS (DGPS)* - MX575A < 0.5 m RMS (DGPS)* - MX575B ° Heading accuracy < 0.50 ° Pitch/roll accuracy < 1 ° Rate of turn following...
  • Page 48 MX575A/B DGPS Compass Table 7 : Power specifications Item Specification Input voltage 10 to 36 VDC Power consumption < 5.0 W Current consumption < 360 mA @ 12 VDC Isolation Power supply isolated from serial ports Reverse polarity protection Table 8 : Environmental specifications...
  • Page 49 MX575A/B DGPS Compass Table 9: Type-Approval Compliance Type MX575A MX575B IMO RES. MSC116(73), IMO RES. MSC 116(73) IMO RES. A.694(17) IMO RES. 694(17) ISO 22090-3 Ed.4.0, 2002 IMO RES. MSC 191(79) IMO MSC.112(73) IMO RES. MSC 112(79) Compass IEC 60945 ED.4.0, 2002 ISO 22090-3 ED.

  • Page 50: Data Output

    MX575A/B DGPS Compass 6. Data Output The MX575 data output conforms to the NMEA 0183 V3.0 at 4800, 9600, or 19200 baud. Below is a list of the NMEA sentences output: NMEA 0183 Data Output Sentences (1) GBS - GNSS Satellite Fault Detection (Modified MX Marine version) This message is used to support Receiver Autonomous Integrity Monitoring (RAIM) feature in the MX420 CDU.
  • Page 51 MX575A/B DGPS Compass (2) GGA – Global Positioning System Fix Data Time, position and fix related data for a GPS receiver. 5 6 7 8 9 10 11 12 13 14 $GPGGA,hhmmss,llll.llll,a,yyyyy.yyyy,a,x,xx,x.x,x.x,M,x.x,M,x.x,xxxx*hh<CR><LF > Notes: 1 ----- UTC of position 2,3 --- Latitude, N/S...
  • Page 52 MX575A/B DGPS Compass (4) GSA – GPS DOP and Active Satellites GPS receiver operating mode, satellites used in the navigation solution reported by the $GPGGA sentence, and DOP values. $GPGSA,a,x,xx,xx,xx,xx,xx,xx,xx,xx,xx,xx,xx,xx,x.x,x.x,x.x*hh<CR><LF> 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17...
  • Page 53 MX575A/B DGPS Compass 7 - Standard deviation of longitude error (meters) 8 - Standard deviation of altitude error (meters) (6) GSV - GPS Satellite in View Number of satellites (SV) in view, PRN numbers, elevation, azimuth and SNR values. Four satellites maximum per transmission, additional satellite data sent in second or third message.
  • Page 54 MX575A/B DGPS Compass (8) RMC - Recommended Minimum Specific GPS Data Time, date, position, course and speed data provided by a GPS navigation receiver. This sentence is transmitted at intervals not exceeding 2 seconds. data fields must be provided: null fields used only when data is temporarily unavailable.
  • Page 55 MX575A/B DGPS Compass (11) VTG - Course Over Ground and Ground Speed The actual course and speed relative to the ground. $GPVTG,x.x,T,x.x,M,x.x,N,x.x,K,a*hh<CR><LF> 1 2 3 4 5 6 7 8 9 Notes: 1,2 ------ Course over ground, degrees True 2,3 ------ Course over ground, degrees Magnetic...
  • Page 56 MX575A/B DGPS Compass (13) PCSI - Beacon Status Message This message contains a variety of information relating to the status of Beacon engine inside the MX575. The $PCSI,1 output message from the SBX beacon module is intelligently routed through the MX575 to the port from which the $PCSI,1 message was requested.

  • Page 57: Proprietary Input Data Messages

    MX575A/B DGPS Compass 6.1 Proprietary Input Data Messages The table below gives a list of the available proprietary input messages and their description: Message Type Description $PMVXG,303 RESET CONTROL $PMVXG,026 NMEA MESSAGE SCHEDULE $PMVXG,200 SET PORT CONFIGURATION $PCSI BEACON PCB CONTROL...
  • Page 58 MX575A/B DGPS Compass Sentence Type - $PMVXG,303 Description: Reset Control This message allows the user to command various types of resets to the MX575. Flow: Input $PMVXG,303 – Reset Control Field Description Units Format Range Reset Control 0 = No Action 1 = Reset Serial I/O to Factory Default Settings.
  • Page 59 MX575A/B DGPS Compass Sentence Type - $PMVXG,026 Description: NMEA Message Schedule This message enables/disables output of the specified sentence to the NMEA port and defines the output rate. Flow: Input $PMVXG,026 – NMEA Schedule Field Description Units Format Range Equipment Port...
  • Page 60 MX575A/B DGPS Compass Sentence Type: $PMVXG,200 Description: Set Port Configuration This message sets the transmission rate, number of data bits, and parity convention for each of the serial interface ports. Flow: Input $PMVXG,200 – PORT CONFIGURATION Field Description Units Format...
  • Page 61 MX575A/B DGPS Compass $PMVXG,200,1,7,,,,,*60...
  • Page 62 MX575A/B DGPS Compass Sentence Type: $GPMSK Description: Beacon tune command There are three main derivatives of this command that affects the method of beacon receiver tuning, and each are described in the following sections. Full Manual command ($GPMASK): This command instructs the MX575’s internal beacon receiver to tune to a specified frequency and MSK Rate.
  • Page 63 MX575A/B DGPS Compass Partial Manual Tune Command ($GPMASK): This command instructs the internal beacon receiver to tune to a specified frequency and automatically select the correct MSK rate. It has the following form: $GPMSK,fff.f,M,,A,n<CR><LF The internal SBX will reply with the following response: $PCSI,ACK,GPMSK,fff.f,M,,A,n<CR><LF>...
  • Page 64 MX575A/B DGPS Compass Automatic Beacon Search Command ($GPMSK,305): This command initiates the beacon receiver to automatic mode of operation in which the receiver operates without operator intervention, selecting the most appropriate beacon station. This command has the following format: $GPMSK,305,A,,A,,,<CR><LF>...
  • Page 65 MX575A/B DGPS Compass Beacon Database Search Mode ($GPMSK,305): This operating mode has been added to the MX575 beacon receiver in order to be compliant with the specification IEC 61108-4 for ship borne DGPS maritime radio beacon receiver equipment. The basic operation is outlined below.
  • Page 66 MX575A/B DGPS Compass Sentence Type: $JSHOW Description: Command to show its current configuration. This command is used to poll the MX575 receiver for its current configuration. This command has the following structure. $JSHOW[,subset] <CR><LF> Using the $JSHOW command without the optional ‘,subset’ field will provide a complete response from the receiver.
  • Page 67 MX575A/B DGPS Compass This line indicates the status of the altitude aiding feature This line indicates the threshold of estimated differential performance that allows the green DGPS LED to illuminate (on the Mini MAX only) This line indicates the current elevation mask cutoff angle, in degrees...
  • Page 68 MX575A/B DGPS Compass Current differential mode, ‘W’ indicates WAAS mode. When GP is specified for ‘subset’, the following is an example response provided: $>JSHOW,GP,GGA,1.0 This response will provide the >$JSHOW,GP message header, followed by each message currently being output through the current port and also the update rate for...
  • Page 69 MX575A/B DGPS Compass Sentence type: $JDIFF Description: Beacon receiver differential mode This command is used to change the differential mode of the receiver. The default differential mode is Auto/Database. This command has the following structure. $JDIFF,diff<CR><LF> Where the differential mode variable, ‘diff’, has one of the following values: $JDIFF,diff<CR><LF>...
  • Page 70 MX575A/B DGPS Compass Sentence Type: $JSAVE Sending this command is required after making changes to the operating mode of the receiver in order to ensure the changes are saved for the subsequent power cycle. This command has the following structure.

  • Page 71: Product Warranty And Limitation Of Liability

    MX575A/B DGPS Compass PRODUCT WARRANTY AND LIMITATION OF LIABILITY This product is warranted by NAVICO (the “Seller”) to original purchaser (the “buyer”) for use only to be free of all defects in material and workmanship for a period of twelve (12) months from date of purchase by Buyer.
  • Page 72 MX575A/B DGPS Compass THIS PRINTED LIMITED WARRANTY IS ACCEPTED BY BUYER IN LIEU OF ANY OTHER WARRANTY FOR THE PRODUCT, WHETHER EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO...
  • Page 73 Master the Elements Doc. no. 3508-102-70920...
