Controls:

1. Power button
2. Band button
3. Advanced setting button
4. Info button
5. Preset buttons
6. Auto tune button
7. Volume/Tuning Control/Select knob/button
8. DC IN socket
9. AUX IN1 socket
10. LCD display
11. Soft bended rod antenna
12. Handle
13. Speaker
14. Battery compartment locker
15. AUX IN2 socket
16. Industrial Rechargeable Battery Connect Terminals
The following tables indicate the operating time on a single charge.
Battery
Capacity
1.3 Ah
2.0 Ah
BH9020
BH9020A
2.6 Ah
3.0 Ah
BH9033
3.3 Ah
BH9033A
Operating time may differ by the type of battery, charging or operating conditions.
4
9.6V
12V
PA09
PA12
9120
1220
9122
1222
BH1220
BH1220C
9134
1234
9135
1235
BH1233
BH1233C

Battery Installation

1. Pull out the battery compartment
locker to release the battery
compartment.
2. Insert the battery pack to power radio.
The suitable battery packs for this
radio are listed as below.
1
Cluster Battery:
9.6V:
12V:
14.4V:
18V:
Slide Battery:
9.6V:
12V:
14.4V:
18V:
24V:
Battery Cartridge - Voltage
14.4V
PA14
1420
BL1415
1422
BH1420
1434
1435
BL1430
BH1433
2
9135/9134/9122/PA09/9120
1235/1234/1222/PA12/1220
1435/1434/1422/PA14/1420
1835/1834/1822/PA18
BH9033/BH9033A/BH9020/BH9020A
BH1233/BH1233C/BH1220/BH1220C
BH1433/BH1420/BL1430/BL1415
BL1830/BL1815
BH2433/BH2420
18V
24V
PA18
BL1815
1822
BH2420
1834
1835
BL1830
BH2433
1. Battery
compartment
(covering main
battery pack and
back up
batteries)
2. Battery
compartment
locker
Operating time
(At Max.
Volume)
Approx.
3.5 hour
Approx.
5.5 hour
Approx.
7.0 hour
Approx.
8.5 hour
Approx.
9.0 hour
