Grass Collection System — Models 190 & 192
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Form No. 769-01136F
October 19, 2007

Advertisement

Table of Contents
loading

Related Manuals for Cub Cadet 190

Summary of Contents for Cub Cadet 190

  • Page 1 Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty ’ peratOr anual Grass Collection System — Models 190 & 192 WARNING READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE.

  • Page 2: Model Number

    Call a Customer Support Representative at (800) 800-7310 or (330) 220-4683 ◊ ◊ ◊ Write us at Cub Cadet LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019 Locate your nearest Cub Cadet Dealer at (877) 282-8684 Locate your nearest Cub Cadet Dealer at (877) 282-8684 ◊...

  • Page 3: Contents Of Carton

    NOTE: Model 190 Triple Bagger Kit is designed for use this attachment. Read and observe all WARNING and on Fast Attach™ compatible tractors equipped with 50- CAUTION statements. They are included to provide for inch cutting deck only. This will NOT mount, nor operate...

  • Page 4: Mounting Bracket Assembly

    Assembly & Operation NOTE: References to left, right, front and rear of the tractor are from the operator’s position, unless otherwise stated. • Before assembly, place the tractor on a firm, level Assembly surface, disengage the PTO, stop the tractor engine and set the parking brake.

  • Page 5: Assembly And Operation

    Attaching Blades WARNING: Always protect your hands while servicing blades by wearing heavy work gloves or using heavy rags. NOTE: Three 2-in-1 (Discharge/Bag) blades are included Assembly in the grass catcher kit. These will replace the 3-in-1 (Discharge/Bag/Mulch) blades already installed on the deck of the tractor.
  • Page 6 Attaching Chute Stop Bracket • Remove the carriage bolt and lock nut holding the chute stop to the deck. See Inset A of Fig. 2-8. Save the hardware. • Replace with new chute stop bracket, from the bag- ger kit, at the same position on the deck. See Inset Assembly B of Fig.
  • Page 7 Your triple bagger kit is a valuable accessory to your tractor. Optimize its performance by operating it correctly. NOTE: Model 190 Triple Bagger Kit is designed for use on Fast Attach™ compatible tractors equipped with 50- inch cutting decks only. This will NOT mount, nor operate safely or properly on any other tractor regardless of the tractor’s compatibility with similar accessories.
  • Page 9 Grassbag Frame Tube 736-0270 Bell Washer, .265 x .75 x .062 764-0251 Grass Catcher Bag 736-3092 Flat Washer .265 x 1.0 x .030 777D03361 Cub Cadet Logo (if equipped) 738-0380 Shoulder Screw, .50 x .27, 3/8-16 726-3040 Push Cap (if equipped)
  • Page 10 NOTES Use this page to make notes and write down important information.
  • Page 11 NOTES Use this page to make notes and write down important information.
  • Page 12 The limited warranty set forth below is given by Cub Cadet LLC with b. Service completed by someone other than an authorized service respect to new merchandise purchased or leased and used in the United dealer.
