Stanley S32 Operation And Maintenance Manual

S32 series pneumatic stapler
Hide thumbs

Advertisement

Table of Contents

BOSTITCH
®
S32
PNEUMATIC STAPLER
ENGRAPADORA NEUMÁTICA
AGRAFEUSE PNEUMATIQUE
OPERATION and MAINTENANCE MANUAL
MANUAL DE OPERACIÓN Y DE MANTENIMIENTO
MANUEL D'INSTRUCTIONS ET D'ENTRETIEN
BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD STUDY THIS MANUAL TO
UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS. KEEP THESE
INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE. IF YOU HAVE ANY QUESTIONS,
CONTACT YOUR STANLEY-BOSTITCH REPRESENTATIVE OR DISTRIBUTOR.
ANTES DE OPERAR ESTA HERRAMIENTA, TODOS LOS OPERADORES DEBERÁN ESTUDIAR
ESTE MANUAL PARA PODER COMPRENDER Y SEGUIR LAS ADVERTENCIAS SOBRE SEGURI-
DAD Y LAS INSTRUCCIONES. MANTENGA ESTAS INSTRUCCIONES CON LA HERRAMIENTA
PARA FUTURA REFERENCIA, SI TIENE ALGUNA DUDA, COMUNÍQUESE CON SU REPRESEN-
TANTE DE STANLEY-BOSTITCH O CON SU DISTRIBUIDOR.
LIRE ATTENTIVEMENT LE PRÉSENT MANUEL AVANT D'UTILISER L'APPAREIL. PRÉTER UNE
ATTENTION TOUTE PARTICULIÈRE AUX CONSIGNES DE SÉCURITÉ ET AUX AVERTISSE-
MENTS. GARDER CE MANUEL AVEC L'OUTIL POUR FUTUR RÉFÉRENCE. SI VOUS AVEZ DES
QUESTIONS, CONTACTEZ VOTRE REPRÉSENTANT OU VOTRE CONCESSIONNAIRE
STANLEY-BOSTITCH.
103693 REVF 5/99
Stanley Fastening Systems

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S32 and is the answer not in the manual?

Questions and answers

Related Manuals for Stanley S32

Summary of Contents for Stanley S32

  • Page 1 DAD Y LAS INSTRUCCIONES. MANTENGA ESTAS INSTRUCCIONES CON LA HERRAMIENTA PARA FUTURA REFERENCIA, SI TIENE ALGUNA DUDA, COMUNÍQUESE CON SU REPRESEN- TANTE DE STANLEY-BOSTITCH O CON SU DISTRIBUIDOR. LIRE ATTENTIVEMENT LE PRÉSENT MANUEL AVANT D’UTILISER L’APPAREIL. PRÉTER UNE ATTENTION TOUTE PARTICULIÈRE AUX CONSIGNES DE SÉCURITÉ ET AUX AVERTISSE- MENTS.

  • Page 2: Table Of Contents

    INTRODUCTION The Stanley-Bostitch S32 series tacker tools are precision-built tools, designed for high speed, high volume fastening. These tools will deliver efficient, dependable service when used correctly and with care. As with any fine power tool, for best performance the manufacturer's instructions must be followed.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS EYE PROTECTION which conforms to ANSI specifications and provides protection against flying particles both from the FRONT and SIDE should ALWAYS be worn by the operator and others in the work area when loading, operating or servicing this tool. Eye protection is required to guard against flying fasteners and debris, which could cause severe eye injury.

  • Page 4: Tool Specifications

    OPERATING PRESSURE: The operating pressure of the S32 tool is 60 to 100 p.s.i. (4.2 to 7.1 kg/cm2). Select the operating pressure within this range for best fastener performance. DO NOT EXCEED THIS RECOMMENDED OPERATING PRESSURE.

  • Page 5: Air Supply: Fittings, Hoses, Filters, Air Consumption, Regulators, Operating Pressure, Setting Correct Pressure

    Frequent, but not excessive, lubrication is required for best performance. Oil added through the air line connection will lubricate the internal parts. Use STANLEY-BOSTITCH Air Tool Lubricant, Mobil Velocite #10, or equivalent. Do not use detergent oil or additives as these lubricants will cause accelerated wear to the seals and bumpers in the tool, resulting in poor tool performance and frequent tool maintenance.

  • Page 6: Loading The Tool

    Disengage the latch and pull back on the staple guide unit. Insert the staples into the magazine. CAUTION: Load with points upward. Push the staple guide unit closed, until the latch engages. NOTE: Use only fasteners recommended by Stanley-Bostitch for S32 series staplers, or fasteners which meet Stanley-Bostitch specifications.

  • Page 7: Tool Operation

    THIS MANUAL. II. REFER TO “TOOL SPECIFICATIONS” IN THIS MANUAL TO IDENTIFY THE OPERATING SYSTEM ON YOUR TOOL. There are three available systems on STANLEY-BOSTITCH pneumatic tools. They are: 1. TRIGGER OPERATION 2. CONTACT TRIP OPERATION 3. SEQUENTIAL TRIP OPERATION OPERATION 1.
  • Page 8 IN ADDITION TO THE OTHER WARNINGS CONTAINED IN THIS MANU- AL OBSERVE THE FOLLOWING FOR SAFE OPERATION • Use the STANLEY-BOSTITCH pneumatic tool only for the purpose for which it was designed. • Never use this tool in a manner that could cause a fastener to be directed toward the user or others in the work area.

  • Page 9: Basic Tool Operation (Diagram)

    BASIC TOOL OPERATION Stanley-Bostitch pneumatic tools are cycled by a compressed air operated single piston design. The following illustrations show the four functional cycles that occur when the tool is operated to drive a fastener: FIG.1 FIG.2 EXHAUST OPEN AT REST...

  • Page 10: Trouble Shooting

    COIL NAILERS Skipping fasteners; intermittent feed Feed piston dry ....Add STANLEY-BOSTITCH Air Tool Lubricant in hole in feed piston cover Feed piston O-rings cracked/worn ..Replace O-rings/check bumper and spring.

  • Page 11: Accessories

    ACCESSORIES AVAILABLE: BC602 1 pint Stanley-Bostitch Air-Tool Lubricant BC603 1 pint Stanley-Bostitch "Winter-Formula" Air-Tool Lubricant BC604 1 quart Stanley-Bostitch Air-Tool Lubricant ORK10 O-Ring/Bumper Repair Kit 104649 Cold Weather Bumper 100679 Lube (1lb. Can) -11-...

This manual is also suitable for:

S32sxS32slS3297S3297-lhf
