INSTRUCTION MANUAL
Cutter
MT411
008647
DOUBLE INSULATION
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT411 and is the answer not in the manual?

Questions and answers

Summary of Contents for Maktec MT411

  • Page 1 INSTRUCTION MANUAL Cutter MT411 008647 DOUBLE INSULATION WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
  • Page 2: Specifications

    ENGLISH SPECIFICATIONS Model MT411 Blade diameter 110 mm Hole diameter 20 mm Max. cutting capacity 32 mm No load speed (min 12,000 Overall length 217 mm Net weight 2.7 kg • Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
  • Page 3: Operating Instructions

    Do not operate tool when you are tired. Never attempt to cut with the tool held upside 20. Check damaged parts. down in a vise. This can lead to serious Before further use of the tool, a guard or other part accidents, because it is extremely dangerous.
  • Page 4 Hex wrench storage Sighting 1. Hex wrench 008650 008653 When not in use, store the hex wrench as shown in the Align the edge of the front of the base with your cutting figure to keep it from being lost. line on the workpiece.
  • Page 5 Hold the tool firmly. Set the base plate on the workpiece 1. Brush holder to be cut without the wheel making any contact. Then turn the tool on and wait until the wheel attains full 2. Screwdriver speed. Now simply move the tool forward over the workpiece surface, keeping it flat and advancing smoothly until the cutting is completed.
  • Page 8 Makita Corporation 884777-3...
