- Page 1 INSTRUCTION MANUAL Cutter MT413 013754 DOUBLE INSULATION IMPORTANT: Read Before Using.
-
Page 2: Specifications
ENGLISH (Original instructions) SPECIFICATIONS Model MT413 Blade diameter 110 mm Hole diameter 20 mm Max. diamond wheel thickness 2 mm Max. cutting capacity 32 mm Rated speed (n) / No load speed (n 13,000 (min Overall length 227 mm Net weight 2.9 kg... -
Page 3: General Power Tool Safety Warnings
Designation of Machine: tools. Unmodified plugs and matching outlets will Cutter reduce risk of electric shock. Model No./ Type: MT413 Avoid body contact with earthed or grounded are of series production and surfaces such as pipes, radiators, ranges and Conforms to the following European Directives: refrigerators. - Page 4 15. Do not overreach. Keep proper footing and 26. Follow instruction lubricating balance at all times. This enables better control changing accessories. of the power tool in unexpected situations. 27. Keep handles dry, clean and free from oil and 16. Dress properly. Do not wear loose clothing or grease.
- Page 5 Wear personal protective equipment. entering into the pinch point can dig into the surface of Depending on application, use face shield, the material causing the wheel to climb out or kick out. safety goggles safety glasses. The wheel may either jump toward or away from the appropriate, wear dust...
-
Page 6: Functional Description
their own weight. Supports must be placed under FUNCTIONAL DESCRIPTION the workpiece near the line of cut and near the edge of the workpiece on both sides of the wheel. j) Use extra caution when making a “pocket CAUTION: cut” into existing walls or other blind areas. Always be sure that the tool is switched off and •... -
Page 7: Operation
For tool with lock button 1. Inner flange To start the tool, simply pull the switch trigger. Release 2. Diamond wheel the switch trigger to stop. 3. Outer flange For continuous operation, pull the switch trigger, push in 4. Hex bolt the lock button and then release the switch trigger. -
Page 8: Maintenance
over the workpiece surface, keeping it flat and advancing smoothly until the cutting is completed. Keep your cutting line straight and your speed of advance uniform. MAINTENANCE CAUTION: Always be sure that the tool is switched off and • unplugged before attempting to perform inspection or maintenance. - Page 12 Makita Corporation Anjo, Aichi, Japan www.makita.com 885206-225...
