Maktec MT410 Instruction Manual

Hide thumbs Also See for MT410:
Table of Contents

Advertisement

Quick Links

Cutter
110 mm (4 - 3/8")
MODEL MT410
I N S T R U C T I O N
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
DOUBLE
INSULATION
M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT410 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Maktec MT410

Summary of Contents for Maktec MT410

  • Page 1 Cutter 110 mm (4 - 3/8”) MODEL MT410 DOUBLE INSULATION I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    SPECIFICATIONS Model MT410 Blade diameter 110 mm (4-3/8”) Hole diameter 20 mm (13/16”) Max. cutting capacity 32 mm (1-1/4”) 13,000 No load speed (Min Overall length 226 mm (8-7/8”) Net weight 2.9 kg (6.4 lbs) • Manufacturer reserves the right to change specifications without notice.

  • Page 3: Additional Safety Rules

    9. Use safety glasses and hearing protec- the switch. Ensure switch is off when plug- tion. ging in. 18. Use outdoor extension leads. Also use face or dust mask if the cutting oper- ation is dusty. When tool is used outdoors, use only exten- 10.
  • Page 4 5. Keep hands away from rotating parts. serious accidents, because it is extremely dangerous.(Fig. 1) 6. Make sure the wheel is not contacting the workpiece before the switch is turned on. 7. Wait until the wheel attains full speed before cutting. 8.

  • Page 5: Operating Instructions

    OPERATING INSTRUCTIONS Removing or installing diamond wheel 001676 (optional accessory) CAUTION: • Always be sure that the tool is switched off and unplugged before installing or removing the wheel. • Use only the Makita wrench to install or remove the wheel.

  • Page 6: Adjusting Depth Of Cut

    Adjusting depth of cut 001672 Loosen the wing bolt on the depth guide and move the base up or down. At the desired depth of cut, secure the base by tightening the wing bolt. CAUTION: • After adjusting depth of cut, always tighten the wing bolt securely.

  • Page 7: Operation

    Switch action 001673 CAUTION: • Before plugging in the tool, always check to see that the switch trigger actuates properly and returns to the “OFF” position when released. For tool with lock button To start the tool, simply pull the switch trigger. Release the 1.

  • Page 8: Maintenance

    MAINTENANCE CAUTION: • Always be sure that the tool is switched off and unplugged before carrying out any work on the tool. After use Blow away dust from the inside of the tool by running the tool at an idle for a while. Brush off accumulation of dust on the base.
  • Page 9 Memo...
  • Page 10 Memo...
  • Page 11 Memo...
  • Page 12 Makita Corporation 884432-944...
