D-Bracket™ Connector: J24 - Premio Computer Apollo User Manual

D-Bracket™ Connector: J24
The mainboard comes with a J24 connector for you to connect to D-
Bracket™. D-Bracket™ is a USB Bracket integrating four LEDs whose func-
tions are similar to D-LED™ and allows users to identify system problem through
16 various combinations of LED signals. For definitions of 16 signal
combinations, please refer to Chapter 1. D-LED™ & D-Bracket™.
J24
There are two types of D-Bracket™: one supports USB PC to PC Net-
working function, and the other doesn't (see photos on the next page). You
can purchase the one you need from your dealer.
Hardware Setup
2-25
