Memory Installation

The mainboard provides 4 gold-lead sockets for 184-pin RIMM modules.
To operate properly, at least two RIMM modules must be installed. The
mainboard supports the memory size up to 2 GB.

Memory Population Rules

Support RIMM only.
To operate properly, make sure that the RIMM banks are using the same
type and equal size density memory.
Support FSB 100MHz: PC600/PC800 RIMM.
Note: PC700 will run at PC600 specification.
Support up to 32 Direct Rambus Device.
Support ECC Single bit Correction and Multiple bit error detection
(Setting in BIOS).
Install two RIMM modules either on "RIMM 1and RIMM 2" or on
"RIMM3 and RIMM4" slots.
About RIMM Module
RIMM module is a module integrated with RDRAM chips. It is similar to
a DIMM package but uses different pin settings. Rambus trademarked the term
RIMM as an entire word for a module using Rambus technology.
RIMM1
2-5
Hardware Setup
RIMM Slots
(RIMM 1~4)
