Replaceable Mechanical Parts - Tektronix PG 508 Instruction Manual

SPECIAL NOTES AND SYMBOLS
X000 Part first added at this serial number
OOX Part removed after this serial number
INDEX NUMBERS
Items in this section are referenced by index
numbers to the figure on page A-23.
INDICATION SYSTEM
This mechanical parts list is indented to indicate
item relationships. Following is an example of the
indentation system used in the description column.
1 2 3 4 5
Assembly and/or Component
Attaching parts for Assembly and/or Component
Detail Part of Assembly and/or Component
Attaching parts for Detail Part
Parts of Detail Part
Attaching parts for Parts of Detail Part
" INCH
# NUMBER SIZE
ACTR ACTUATOR
ADPTR ADAPTER
ALIGN ALIGNMENT
AL ALUMINUM
1ASSEM ASSEMBLED
.ASSY ASSEMBLY
ATTEN ATTENUATOR
AWG AMERICAN WIRE GAGE FLH
BD BOARD
BRKT BRACKET
BRS BRASS
BRZ BRONZE
BSHG BUSHING
CAB CABINET
CAP CAPACITOR
CER CERAMIC
CHAS CHASSIS
CKT CIRCUIT
COMP COMPOSITION
CONN CONNECTOR
COV COVER
CPLG COUPLING
CRT CATHODE RAY TUBE
DEG DEGREE
DWR DRAWER
Name & Description
- - - * - - -
- - - * - - -
- - - * - - -
ELCTRN ELECTRON
ELEC ELECTRICAL
ELCTLT ELECTROLYTIC
ELEM ELEMENT
EPL ELECTRICAL PARTS LIST LPHLDR LAMPHOLDER
EQPT EQUIPMENT
EXT EXTERNAL
FIL FILLISTER HEAD
FLEX FLEXIBLE
FLAT HEAD
FLTR FILTER
FR FRAME or FRONT
FSTNR FASTENER
FT FOOT
FXD FIXED
GSKT GASKET
HDL HANDLE
HEX HEXAGON
HEX HD HEXAGONAL HEAD
HEX SOC HEXAGONAL SOCKET
HLCPS HELICAL COMPRESSION RES
HLEXT HELICAL EXTENSION
HV HIGH VOLTAGE
IC INTEGRATED CIRCUIT
ID INSIDE DIAMETER
IDENT IDENTIFICATION
IMPLR IMPELLER
REPLACEABLE
MECHANICAL PARTS
Attaching Parts always appear in the same
indentation as the item it mounts, while the detail parts
are indented to the right. Indented items are part of,
and included with, the next higher indentation. The
separation symbol - - - - - - indicates the end of
Attaching parts must be purchased separately,
unless otherwise specified.
In the Parts List, an Item Name is separated from
the description by a colon (:). Because of space
limitations, an Name may sometimes appear as
incomplete. For further Item Name identification, the
U.S. Federal Cataloging Handbook H6-1can be utilized
where possible.
ABBREVIATIONS
IN INCH
INCAND INCANDESCENT
INSUL INSULATOR
INTL INTERNAL
MACH MACHINE
MECH MECHANICAL
MTG MOUNTING
NIP NIPPLE
NON WIRE NOT WIRE WOUND
OBD ORDER BY DESCRIPTIONSQ
OD OUTSIDE DIAMETER
OVH OVAL HEAD
PH BRZ PHOSPHOR BRONZE
PL PLAIN or PLATE
PLSTC PLASTIC
PN PART NUMBER
PNH PAN HEAD
PWR POWER
RCPT RECEPTACLE
RESISTOR
RGD RIGID
RLF RELIEF
RTNR RETAINER
SCH SOCKET HEAD
SCOPE OSCILLOSCOPE
SCR SCREW
A-19
TM 11-6625-2980-14
ITEM NAME
SE SINGLE END
SECT SECTION
SEMICOND SEMICONDUCTOR
SHLD SHIELD
SHLDR SHOULDERED
SKT SOCKET
SL SLIDE
SLFLKG SELF-LOCKING
SLVG SLEEVING
SPR SPRING
SQUARE
SST STAINLESS STEEL
STL STEEL
SW SWITCH
T TUBE
TERM TERMINAL
THD THREAD
THK THICK
TNSN TENSION
TPG TAPPING
TRH TRUSS HEAD
V VOLTAGE
VAR VARIABLE
W/ WITH
WSHR WASHER
XFMR TRANSFORMER
XSTR TRANSISTOR
