[MAIN UNIT]
REF ORDER
NO. NO.
L36 6140000670 COIL
L39 6200004480 S.COIL
L40 6200009080 S.COIL
L41 6200004850 S.COIL
L42 6200004480 S.COIL
L43 6200004480 S.COIL
L48 6110001600 COIL
L49 6150005000 S.COIL
L50 6110001730 COIL
L52 6200004480 S.COIL
L53 6190001500 COIL
L54 6200007000 S.COIL
L55 6200003310 S.COIL
L56 6200003310 S.COIL
L57 6200003310 S.COIL
L60 6200005010 S.COIL
L61 6190001510 COIL
L62 6190001500 COIL
L63 6190001500 COIL
L64 6190001500 COIL
L65 6200005010 S.COIL
L67 6200008760 S.COIL
L68 6200009120 S.COIL
L69 6200008270 S.COIL
L70 6110001520 COIL
L71 6110002110 COIL
L72 6200002040 S.COIL
L73 6200002040 S.COIL
L75 6200004480 S.COIL
L77 6200009140 S.COIL
L78 6190001520 S.COIL
L79 6190001520 S.COIL
L80 6190001520 S.COIL
L81 6190001520 S.COIL
L82 6200004450 S.COIL
L83 6200004880 S.COIL
L84 6200004880 S.COIL
L85 6200004450 S.COIL
L86 6190001520 S.COIL
L87 6200006990 S.COIL
R1 7030006070 S.RESISTOR
R2 7030003480 S.RESISTOR
R3 7030003500 S.RESISTOR
R9 7030003720 S.RESISTOR
R11 7030003800 S.RESISTOR
R12 7030003730 S.RESISTOR
R13 7030003680 S.RESISTOR
R14 7030003770 S.RESISTOR
R15 7030003280 S.RESISTOR
R17 7030003280 S.RESISTOR
R18 7030003720 S.RESISTOR
R19 7030003720 S.RESISTOR
R20 7030003720 S.RESISTOR
R21 7030003640 S.RESISTOR
R24 7030003670 S.RESISTOR
R25 7030003560 S.RESISTOR
R26 7030003320 S.RESISTOR
R27 7030003470 S.RESISTOR
R28 7030003320 S.RESISTOR
R30 7030003590 S.RESISTOR
R31 7030003460 S.RESISTOR
R34 7030003470 S.RESISTOR
R35 7030003320 S.RESISTOR
R36 7030003600 S.RESISTOR
R37 7030003650 S.RESISTOR
R38 7030003460 S.RESISTOR
R40 7030003480 S.RESISTOR
R41 7030003600 S.RESISTOR
R42 7030003460 S.RESISTOR
R43 7030003500 S.RESISTOR
R45 7030003650 S.RESISTOR
R46 7030003320 S.RESISTOR
R48 7030003650 S.RESISTOR
R49 7030003750 S.RESISTOR
R50 7030003430 S.RESISTOR
R59 7310003600 S.TRIMMER
R61 7030003480 S.RESISTOR
R62 7030003440 S.RESISTOR
R63 7030003480 S.RESISTOR
R64 7030003680 S.RESISTOR
DESCRIPTION
LR-89
MLF1608D R82K-T
MC152-E558CN-100025=P3
MC152-E558CN-100024
MLF1608D R82K-T
MLF1608D R82K-T
LA-243
LS-527
LA-262
MLF1608D R82K-T
HK-08S070-1310
ELJRE 82NG-F
ELJFC R33M-F
ELJFC R33M-F
ELJFC R33M-F
NL 252018T-100J
HK-10S080-1210
HK-08S070-1310
HK-08S070-1310
HK-08S070-1310
NL 252018T-100J
0.26-0.9-9TR 30N
0.20-0.7-4TR 8.8N
0.26-1.0-5TL 17N
LA-232
LA-382
NL 252018T-101J
NL 252018T-101J
MLF1608D R82K-T
NL 252018T-6R8J
ZBFS5101-PT
ZBFS5101-PT
ZBFS5101-PT
ZBFS5101-PT
ELJFC 6R8M-F
ELJFC 3R3K-F
ELJFC 3R3K-F
ELJFC 6R8M-F
ZBFS5101-PT
ELJRE 56NG-F
ERJ12YJ101U (100 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 274 V (270 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 564 V (560 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 182 V (1.8 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 182 V (1.8 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 394 V (390 kΩ)
ERJ3GEYJ 821 V (820 Ω)
EVM-1XSX50 B54 (503)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
[MAIN UNIT]
REF ORDER
NO. NO.
R65 7030003220 S.RESISTOR
R66 7030003220 S.RESISTOR
R67 7030003220 S.RESISTOR
R68 7030003480 S.RESISTOR
R69 7030003700 S.RESISTOR
R70 7030003400 S.RESISTOR
R71 7030003280 S.RESISTOR
R72 7030003660 S.RESISTOR
R73 7030003370 S.RESISTOR
R74 7030003630 S.RESISTOR
R75 7030003340 S.RESISTOR
R76 7030003560 S.RESISTOR
R77 7030003560 S.RESISTOR
R78 7030003300 S.RESISTOR
R79 7030003340 S.RESISTOR
R80 7030003300 S.RESISTOR
R85 7030003620 S.RESISTOR
R86 7030003360 S.RESISTOR
R87 7030003330 S.RESISTOR
R95 7030003600 S.RESISTOR
R99 7030003270 S.RESISTOR
R101 7030003560 S.RESISTOR
R108 7030003440 S.RESISTOR
R110 7310003610 S.TRIMMER
R111 7030003680 S.RESISTOR
R112 7030003270 S.RESISTOR
R113 7030003620 S.RESISTOR
R114 7510001100 S.THERMISTOR NTCCM1608 4LH 104KC
R115 7030003680 S.RESISTOR
R116 7030003770 S.RESISTOR
R117 7030003800 S.RESISTOR
R118 7030003690 S.RESISTOR
R119 7030003680 S.RESISTOR
R120 7030003680 S.RESISTOR
R121 7310003580 S.TRIMMER
R122 7030003630 S.RESISTOR
R123 7030003630 S.RESISTOR
R124 7030003630 S.RESISTOR
R126 7030003560 S.RESISTOR
R127 7030003560 S.RESISTOR
R128 7030003560 S.RESISTOR
R131 7030003440 S.RESISTOR
R132 7030003560 S.RESISTOR
R148 7030003600 S.RESISTOR
R149 7030003520 S.RESISTOR
R150 7310003610 S.TRIMMER
R151 7030003500 S.RESISTOR
R152 7030003320 S.RESISTOR
R153 7030003540 S.RESISTOR
R174 7030003650 S.RESISTOR
R181 7030003700 S.RESISTOR
R182 7030003760 S.RESISTOR
R183 7030003800 S.RESISTOR
R184 7030003800 S.RESISTOR
R186 7030003700 S.RESISTOR
R187 7030003680 S.RESISTOR
R188 7030003640 S.RESISTOR
R192 7030003660 S.RESISTOR
R193 7030003400 S.RESISTOR
R194 7030003490 S.RESISTOR
R208 7030003320 S.RESISTOR
R209 7030003640 S.RESISTOR
R211 7030003540 S.RESISTOR
R212 7030003440 S.RESISTOR
R218 7030003520 S.RESISTOR
R219 7030000210 S.RESISTOR
R220 7030003550 S.RESISTOR
R221 7030000520 S.RESISTOR
R223 7030003620 S.RESISTOR
R224 7030003440 S.RESISTOR
R225 7030003560 S.RESISTOR
R226 7030003680 S.RESISTOR
R228 7030003480 S.RESISTOR
R229 7030003480 S.RESISTOR
R230 7030003520 S.RESISTOR
R231 7030003520 S.RESISTOR
R232 7030003520 S.RESISTOR
R233 7030003520 S.RESISTOR
R234 7030003600 S.RESISTOR
R235 7030003600 S.RESISTOR
5 - 3
DESCRIPTION
ERJ3GEYJ 150 V (15 Ω)
ERJ3GEYJ 150 V (15 Ω)
ERJ3GEYJ 150 V (15 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 680 V (68 Ω)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 680 V (68 Ω)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 121 V (120 Ω)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 390 V (39 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
EVM-1XSX50 B14 (103)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 390 V (39 Ω)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 564 V (560 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 124 V (120 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
EVM-1XSX50 B15 (104)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
EVM-1XSX50 B14 (103)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
MCR10EZHJ 39 Ω (390)
ERJ3GEYJ 822 V (8.2 kΩ)
MCR10EZHJ 15 kΩ
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
[USA/-1] only
ERJ3GEYJ 472 V (4.7 kΩ)
[USA/-1] only
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
S.=Surface mount
