Sony STR-DA5200ES Service Manual page 2

STR-DA5200ES
Reference Power Output at Stereo Mode
(4 ohms 1 kHz, THD
10%):
150 W + 150 W
Reference Power Output
(8 ohms 1 kHz, THD 10%)
2)
FRONT :
150 W + 150 W
2)
CENTER :
150 W
SURROUND
150 W + 150 W
SURROUND BACK
150 W + 150 W
Reference Power Output
(4 ohms 1 kHz, THD 10%)
2)
FRONT :
150 W + 150 W
2)
CENTER :
150 W
SURROUND
150 W + 150 W
SURROUND BACK
150 W + 150 W
1)
Depending on the sound field settings and the
source, there may be no sound output.
2)
Measured under the following conditions:
Power requirements: 230 V AC, 50/60 Hz
(in countries/area in Europe
other than the UK)
240 V AC, 50/60 Hz
(in the UK and general area)
Frequency response
PHONO RIAA equalization curve
± 0.5 dB
10 Hz − 100 kHz
MULTI CHANNEL
± 3 dB
INPUT, SA-CD/CD,
TAPE/CD-R,
MD/DAT, DVD,
VIDEO 1/2/3
Inputs (Analog)
PHONO Sensitivity: 2.5mV
Impedance: 50kohms
S/N: 90dB (A, 20 kHz
LPF)
MULTI CHANNEL Sensitivity: 150mV
INPUT, SA-CD/CD, Impedance: 50kohms
TAPE/CD-R, MD/DAT, S/N: 100dB (A, 20 kHz
DVD, TV/SAT, LPF)
VIDEO1/2/3
Inputs (Digital)
DVD, TAPE/CD-R, Impedance: 75ohms
SA-CD/CD (Coaxial) S/N: 96dB (A, 20 kHz
LPF)
VIDEO 1/2/3, TV/SAT, S/N: 96 dB
MD/DAT (Optical) (A, 20 kHz LPF)
Outputs
TAPE/CD-R, MD/DAT Voltage:150mV
(REC OUT), Impedance: 1kohms
VIDEO1/2 (AUDIO OUT)
FRONT L/R, CENTER, Voltage: 2V
SURROUND L/R, Impedance: 1kohms
SURROUND BACK L/R,
SUB WOOFER
EQUALIZER
±10 dB, 1 dB step
Gain levels
2
FM tuner section
Tuning range
Antenna (aerial)
Antenna (aerial) terminals
Sensitivity
Mono:
Stereo:
Usable sensitivity 11.2 dBf, 1 µV/75 ohms
2)
:
S/N
Mono:
2)
:
Stereo:
Harmonic distortion at 1 kHz
Mono:
Stereo:
Separation
Frequency response 30 Hz − 15 kHz, +0.5/−2 dB
Selectivity
2)
:
A M tuner section
2)
:
(US and Canadian models)
Tuning range
Antenna (aerial)
Usable sensitivity
S/N
Harmonic distortion 0.5% (50 mV/m, 400 Hz)
Selectivity
At 9 kHz:
At 10 kHz:
3)
You can change the AM tuning scale to either 9
kHz or 10 kHz. After tuning in any AM station,
turn off the receiver. While holding down
TUNING MODE, press POWER on the receiver.
All preset stations will be erased when you change
the tuning scale. To reset the scale to 10 kHz (or 9
kHz), repeat the procedure.
AM tuner section (AEP and UK models)
Tuning range
Antenna (aerial)
Usable sensitivity
S/N
Harmonic distortion 0.5% (50 mV/m, 400 Hz)
Selectivity
USB section
Bit rate
ATRAC:
MP3 (MPEG 1 Audio Layer-3):
WMA:
Sampling frequencies
ATRAC:
MP3 (MPEG 1 Audio Layer-3):
WMA:
87.5 − 108.0 MHz
FM wire antenna (aerial)
75 ohms, unbalanced
18.3 dBf, 2.2 µV/75 ohms
38.3 dBf, 22.5 µV/75 ohms
76 dB
70 dB
0.3%
0.5%
45 dB at 1 kHz
60 dB at 400 kHz
530 − 1,710 kHz 3)
(With
10-kHz tuning scale)
531 − 1,710 kHz 3)
(With 9-
kHz tuning scale)
Loop antenna (aerial)
50 dB µ/m (at 1,000 kHz or
999 kHz)
54 dB (at 50 mV/m)
35 dB
40 dB
531 − 1,602 kHz (With 9-
kHz tuning scale)
Loop antenna (aerial)
50 dB µ/m (at 999 kHz)
54 dB (at 50 mV/m)
35 dB
Remote commander RM-AAL006 (1)
(AEP and UK models)
48 − 352 kbps (ATRAC3
plus), 66/105/132 kbps
(ATRAC3)
8 − 320kbps, VBR
48 − 192 kbps, VBR
44.1 kHz
32/44.1/48 kHz
44.1 kHz
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
S video: Y: 1 Vp-p, 75 ohms
C: 0.286 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P /C : 0.7 Vp-p, 75 ohms
B B
P /C : 0.7 Vp-p, 75 ohms
R R
80 MHz HD Pass Through
General (US and Canadian models)
Power requirements 120 V AC, 60 Hz
Power consumption 480 W/580 VA (US/
Canada)
Power consumption (during standby mode)
1 W
AC outlets 2 switched, 100 W/0.8 A
MA X
430 × 175 × 430 mm
Dimensions
(width/height/depth)
including projecting parts
and controls
Mass (Approx.) 15.5 kg (34 lb 3 oz)
General (AEP and UK models)
Power requirements 230 V AC, 50/60 Hz
(in countries/area in
Europe other than UK)
240 V AC, 50/60 Hz
(in UK and general area)
Power consumption 480 W
Power consumption (during standby mode)
1 W
AC outlets 1 switched, 100 W MA
(Models for countries/
areas in Europe other than
the UK.)
430 × 175 × 430 mm
Dimensions
(width/height/depth)
including projecting parts
and controls
Mass (Approx.) 15.5 kg
Supplied accessories
Operating Instructions
Quick Setup Guide (1)
Optimizer microphone ECM-AC1 (1)
FM wire antenna (aerial) (1)
AM loop antenna (aerial) (1)
AC power cord (mains lead) (1)
Remote commander RM-AAL005 (1)
(US and Canadian models)
Remote commander RM-AAU009 (1)
R6 (size-AA) batteries (4)
Design and specifications are subject to
change without notice.
