JBL AEH50-BL Owner's Manual

SPECIFICATIONS

AEH50 Complete Five-Piece Surround-Sound Home Cinema Speaker System
with 100 Watt Powered Subwoofer
JBL is a registered trademark of JBL, Incorporated.
Speaker complement
• Five 2-way magnetically-shielded satellite speakers with high-output
2.5 in (63.5 mm) woofer and precision .5 in (12.7 mm) tweeter
• One 8 in (200 mm) 100 Watt powered subwoofer with LFE input, adjustable
level control, and built-in crossover network for use with speaker-level outputs.
Features
• Five-channel system is expandable to 6.1 and 7.1 surround-sound operation
with optional additional AESS5 satellite speaker(s)
• Includes architectural-grade adjustable mounting brackets
• Includes subwoofer input RCA cable
Specifications
Satellites
Frequency Response (+/- 3dB):
Recommended Amplifier Power Range:
Impedance:
Speaker Sensitivity (2.83V/1m):
Crossover Frequency (+/- 3dB):
Midrange Driver(s):
High-Frequency Transducer:
Dimension (H x W x D):
Weight per Speaker:
Subwoofer
Amplifier
Frequency Response (+/- 3dB):
Woofer:
Enclosure type:
Dimension (H x W x D, icluding feet):
Weight:
LIMITED 5 YEAR WARRANTY AND EXCLUSIONS
Leviton warrants to the original consumer purchaser and not for the benefit of anyone else that this product at the time of its sale by
Leviton is free of defects in materials and workmanship under normal and proper use for five years from the purchase date. Levitonʼs
only obligation is to correct such defects by repair or replacement, at its option, if within such five year period the product is returned
prepaid, with proof of purchase date, and a description of the problem to Leviton Manufacturing Co., Inc., Att: Quality Assurance
Department, 59-25 Little Neck Parkway, Little Neck, New York 11362-2591. This warranty excludes and there is disclaimed liability for
labor for removal of this product or reinstallation. This warranty is void if this product is installed improperly or in an improper environment,
overloaded, misused, opened, abused, or altered in any manner, or is not used under normal operating conditions or not in accordance
with any labels or instructions. There are no other or implied warranties of any kind, including merchantability and fitness for a
particular purpose, but if any implied warranty is required by the applicable jurisdiction, the duration of any such implied warranty,
including merchantability and fitness for a particular purpose, is limited to five years. Leviton is not liable for incidental, indirect,
special, or consequential damages, including without limitation, damage to, or loss of use of, any equipment, lost sales or
profits or delay or failure to perform this warranty obligation. The remedies provided herein are the exclusive remedies under this
warranty, whether based on contract, tort or otherwise.
000-AEH50-BL – Leviton IS Part number: DI-000-AEH50-02A
003-AEH50-WH- Leviton IS Part number: DI-000-AEH50-02A
000-AESS5-BL Leviton IS Part number: DI-000-AESS5-02A
003-AESS5-WH Leviton IS Part number: DI-000-AESS5-02A
All features and specifications are subject to change without notice.
* Trademarks of Dolby Laboratories.
DTS is a registered trademark of Digital Theater Systems, Inc.
Leviton Tech Support #2 1-800-824-3005
w w w. l e v i t o n . c o m
150 Hz- 20 kHz
10- 100 Watts
Nominal 8 Ohms
86 dB
5000Hz, 6dB/octave
2-1/2" magnetcally shielded
1/2" magnetcally shielded
5" x 3-1/2" x 3-1/2" (127mm x 88mm x 88mm)
1.25 lbs. (
100 Watts RMS
35 Hz-150 Hz
8" (200)
Bass-reflex
16-1/4" x 11" x 13-3/4" (413mm x 279mm x 349mm)
28 lbs (12.7kg)
Vendor part number: 406-000-05421-E
Vendor part number: 406-000-05421-E
Vendor part number: 406-000-05430-E
Vendor part number: 406-000-05430-E
OWNER'S GUIDE
AEH50-BL
AEH50-WH
