Hpa2 Tm Headphone Outputs; Status Display - Benchmark DAC1 PRE Instruction Manual

TM
HPA2 Headphone Outputs
Number of Headphone Outputs
Output Connectors
Output Impedance
Output Level Control
Output Level Range (at 0 dBFS) into 60-Ohm Load
Maximum Output Current
Overload Protection (independent per channel)
Bandwidth
THD+N

Status Display

Indicators - Type and Location
Selection/Status Indication
DAC1 PRE Instruction Manual Rev J
2
¼" TRS with switch on left-hand jack
< 0.11 Ohms
Stereo Control on Front Panel
Off to +21 dBu
250 mA
Current limited at 300 mA, Thermal
> 500 kHz
-106 dB, 0.0005% into 30 Ohms at
+18 dBu (1.26W)
3 Blue LED's on Front Panel
Solid: Digital Input Selection
Flashing: Signal Error
None: Standby Mode
Page 44
