INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
CERTIFIED UNDER: ANSI Z21.60 / CSA 2.26 DECORATIVE GAS APPLIANCES FOR INSTALLATION IN SOLID-FUEL BURNING APPLIANCES
GL18NE, GL24NE,
GL30NE
NATURAL GAS
GL18PE, GL24PE,
GL30PE
PROPANE
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.

SAFETY INFORMATION

WARNING
!
If the information in these instructions are
not followed exactly, a fi re or explosion
may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fi re department.
- Installation and service must be performed by a
qualifi ed installer, service agency or the supplier.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certifi ed kit is used.
Phone (705)721-1212 • Fax (705)722-6031 • www.napoleonfi replaces.com • ask@napoleonproducts.com
$10.00
$10.00
OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
INSTALLATION AND
GL18
GL24
GL30
C E R T I F I E D
1.37
W415-1071 / C / 01.11.12
1

Advertisement

Table of Contents
loading

Summary of Contents for Napoleon GL18NE

  • Page 1: Safety Information

    NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE. INSTALLATION AND OPERATING INSTRUCTIONS CERTIFIED UNDER: ANSI Z21.60 / CSA 2.26 DECORATIVE GAS APPLIANCES FOR INSTALLATION IN SOLID-FUEL BURNING APPLIANCES GL18NE, GL24NE, GL30NE NATURAL GAS GL18PE, GL24PE, GL30PE PROPANE CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS INSTALLATION OVERVIEW INTRODUCTION GENERAL INSTRUCTIONS GENERAL INFORMATION MINIMUM APPLIANCE SIZE RATING PLATE INSTALLATION GAS PIPING DAMPER STOP INSTALLATION FINISHING ANDIRON AND GRATE ASSEMBLY BATTERY INSTALLATION LOG PLACEMENT MEDIA LOGO PLACEMENT OPTIONAL ROCK PLACEMENT OPTIONAL REMOTE INSTALLATION (NOT SUPPLIED) WIRING DIAGRAM OPERATION OPERATING AND LIGHTING INSTRUCTIONS...
  • Page 3: Introduction

    2.0 INTRODUCTION WARNING • THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED. • ANY CHANGES OR ALTERATIONS TO THIS APPLIANCE OR IT’S CONTROLS CAN BE DANGEROUS AND IS PROHIBITED. • Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fi...
  • Page 4: General Instructions

    GENERAL INSTRUCTIONS WARNING ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT, WITH THE GLASS DOOR OPENED OR REMOVED. PROVIDE ADEQUATE CLEARANCE FOR SERVICING AND OPERATING THE APPLIANCE. PROVIDE ADEQUATE VENTILATION. NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE. OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT A MINIMUM OF 48”...
  • Page 5: General Information

    GENERAL INFORMATION WARNING THIS APPLIANCE MUST NOT BE INSTALLED IN A BEDROOM OR BATHROOM. GL18 GL24 GL30 Altitude (FT) 0-4,500 0-4,500 0-4,500 0-4,500 0-4,500 0-4,500 Max input (BTU/HR) 55,000 55,000 60,000 60,000 65,000 65,000 Min Inlet Gas Supply Pressure 4.5“ Water 11“...
  • Page 6: Installation

    3.0 INSTALLATION WARNING THIS APPLIANCE MUST BE INSTALLED IN A SOLID-FUEL BURNING FIREPLACE WITH A WORKING FLUE AND CONSTRUCTED OF NON-COMBUSTIBLE MATERIAL. The appliance and gas logs function as a system. If the appliance is not drafting properly and spilling into the room (check with a match or a smoke stick), reposition the damper clamp until a positive draft is obtained by opening the damper.
  • Page 7: Damper Stop Installation

    DAMPER STOP INSTALLATION The damper must be permanently locked in position to prevent full closure and to provide DAMPER STOP a minimum fl ue opening. Various methods for locking the damper may be used but may be restricted from region to region and it is DAMPER important to know the specifi...
  • Page 8: Finishing

    FINISHING ANDIRON AND GRATE ASSEMBLY USE ONLY ACCESSORIES With the 2 andirons laying face DESIGNED FOR AND down, secure the grate overtop LISTED WITH YOUR using two ¼-20 bolts (supplied in SPECIFIC LOG SET. the manual baggie). Install the grate/andiron assembly to the burner base using four 1 ¼”...
  • Page 9: Log Placement

    LOG PLACEMENT WARNING FAILURE TO POSITION THE LOGS IN ACCORDANCE WITH THESE DIAGRAMS OR FAILURE TO USE ONLY LOGS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. LOGS MUST BE PLACED IN THEIR EXACT LOCATION IN THE APPLIANCE. DO NOT MODIFY THE PROPER LOG POSITIONS, SINCE APPLIANCE MAY NOT FUNCTION PROPERLY AND DELAYED IGNITION MAY OCCUR.
  • Page 10: Media

    MEDIA Place lava or ember rock around the base of the appliance, making sure not to block any burner ports or valve access. Retain a small amount of lava rock for step 3 and if applicable step 4. Place formed charcoal lumps around the front and sides of the appliance. Use remaining lava or ember rock to blend with the charcoal lumps.
  • Page 11: Optional Rock Placement

    OPTIONAL ROCK PLACEMENT WARNING REAL ROCKS MUST NOT BE USED IN THIS APPLIANCE. HEAT WILL CAUSE THEM TO EXPLODE Begin with thin rock clusters on rear log support, then build outward in a pattern as shown. Removing a locating pin in the rear support may be required to accommodate the rock clusters. It is not necessary to use all of the rocks.
  • Page 12: Wiring Diagram

    WIRING DIAGRAM WARNING DO NOT WIRE 110 VOLTS TO THE VALVE OR WALL SWITCH. This appliance comes equipped with a battery pack. Install four AA batteries into the holder and connect to the wire harness. Connect the battery holder to the wire harness before using the appliance. It must be connected to the 6 volt battery pack (supplied).
  • Page 13: Operation

    6.0 OPERATION If the fi replace is equipped with decorative glass doors, they must be fully opened when operating this gas log set. Keep burner and control compartment clean. OPERATING AND LIGHTING INSTRUCTIONS WARNING IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
  • Page 14: Adjustments

    ADJUSTMENTS PILOT BURNER ADJUSTMENT Adjust the pilot screw to provide properly sized fl ame. Turn in a clockwise direction to reduce the gas fl ow. Check Pressure Readings: Inlet pressure can be checked by turning screw (A) counter- clockwise 2 or 3 turns and then placing pressure gauge tubing over the test point.
  • Page 15: Flame Characteristics

    FLAME CHARACTERISTICS It’s important to periodically perform a visual check of the pilot and burner fl ames. Compare them to the illustrations provided. If any fl ames appear abnormal call a service person. PILOT BURNER ELECTRODE FLAME SENSOR FLAME MUST ENVELOP UPPER 3/8”...
  • Page 16: Replacements

    9.0 REPLACEMENTS Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally all parts can be ordered through your Authorized dealer / distributor. FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM.
  • Page 17 ACCESSORIES REF NO. GAS LOGS DESCRIPTION GD-660 REMOTE WALL SWITCH W/20” WIRE W660-0026 PROGRAMMABLE TIMER ON/OFF REMOTE F45-6 ON/OFF REMOTE -BULK MKRY GREY RIVER ROCKS MKRM MULTI-COLOURED RIVER ROCKS W415-1071 / C / 01.11.12...
  • Page 18: Trouble Shooting

    10.0 TROUBLE SHOOTING MAINTENANCE MAINTENANCE WARNING MAINTENANCE TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE. APPLIANCE MAY BE HOT, DO NOT SERVICE UNTIL APPLIANCE HAS COOLED. DO NOT USE ABRASIVE CLEANERS. SYMPTOM PROBLEM TEST SOLUTION Pilot will not light. Wiring.
