These log sets can be installed in vented or unvented applications. See installation details for the particular application that applies.
INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
ANSI Z21.60-2002 / CSA 2.26-2002 DECORATIVE GAS APPLIANCES FOR INSTALLATION IN SOLID-FUEL BURNING APPLIANCES
GVFL18N
NATURAL GAS
GVFL18P
PROPANE
GVFL24N
NATURAL GAS
GVFL24P
PROPANE
GVFL30N
NATURAL GAS
GVFL30P
PROPANE
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 4Y8 Canada (705)721-1212 fax(705)722-6031
W415-0530 / 12.14.05
OPERATION INSTRUCTIONS
CERTIFIED UNDER: ANSI Z21.11.2B-2004 GAS FIRED ROOM HEATER : VOLUME II, UNVENTED ROOM HEATERS AND
www.napoleonfireplaces.com ask@napoleon.on.ca
INSTALLATION
If the information in this manual is
not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of
life.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical
• Immediately call the gas supplier
• If you cannot reach your gas
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
If this unit is used as an unvented
gas-fired heater, it uses air (oxygen)
from the room in which it is installed.
Provisions for adequate combustion
and ventilation air must be provided.
Refer to "Installing in an unvented
application" section in this manual.
IMPORTANT: Read these instructions
carefully before trying to operate this
vent-free gas heater.
AND
WARNING
switch; do not use any phone in
your building.
from a neighbour's phone. Follow
the gas supplier's instructions.
supplier, call the fire department.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Napoleon GLVF18N
Summary of Contents for Napoleon GLVF18N
- Page 1 These log sets can be installed in vented or unvented applications. See installation details for the particular application that applies. INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER. CERTIFIED UNDER: ANSI Z21.11.2B-2004 GAS FIRED ROOM HEATER : VOLUME II, UNVENTED ROOM HEATERS AND ANSI Z21.60-2002 / CSA 2.26-2002 DECORATIVE GAS APPLIANCES FOR INSTALLATION IN SOLID-FUEL BURNING APPLIANCES GVFL18N NATURAL GAS...
-
Page 2: Table Of Contents
Warnings Warranty General Instructions General Information Maintenance and Cleaning Air Shutter Minimum Fireplace Size Andiron and Grate Assembly Gas Piping Installing In An Unvented Application Combustion and Ventilation Determining Confined or Unconfined Space PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE •... - Page 3 NAPOLEON products are manufactured under the strict Standard of the world recognized ISO NAPOLEON products are designed with superior components and materials, assembled by trained crafts- men who take great pride in their work. Once assembled the complete log set is thoroughly inspected by a qualified technician before packaging to ensure that you, the customer, receive the quality product that you NAPOLEON GAS LOG SET LIMITED WARRANTY The Phazer™...
-
Page 4: General Instructions
GENERAL INSTRUCTIONS Do not use this gas log set if any part has been under water. Call a qualified service technician to inspect the appliance before operating. Thoroughly clean the chimney, flue and fireplace before in- stalling this appliance into it. Do not burn solid fuels in any fireplace that is equipped with this gas log set. -
Page 5: Air Shutter
AIR SHUTTER " " " The air shutter settings are factory set for most installations. However, adjustment may be required depending on fuel type, vent performance and altitude. Closing the air shutter will cause a more yellow flame, but can lead to carboning. Opening the air shutter will cause a more blue flame, but can cause flame lifting from the burner ports. -
Page 6: Installing In An Unvented Application
INSTALLING IN AN UNVENTED APPLICATION COMBUSTION & VENTILATION AIR PROVISIONS This heater shall not be installed in a confined space or unusually tight construction unless provisions are pro- vided for adequate combustion and ventilation air. In order to avoid the possibility of exposed insulation or vapour barrier coming in contact with the fireplace body, it is recommended that the walls of the fireplace enclo- sure be 'finished', (i.e. -
Page 7: Installing In A Vented Application
Unvented gas heaters are a supplemental zone heater. They are not intended to be the primary heating appliance. Unvented gas heaters emit moisture into the living area. In most homes of average construc- tion, this does not pose a problem. In houses of extremely tight construction, additional me- chanical ventilation is recommended. -
Page 8: Operating / Maintenance
OPERATION / MAINTENANCE OPERATING INSTRUCTIONS IF THE FIREPLACE IS EQUIPPED WITH DECORATIVE GLASS DOORS THEY MUST BE FULLY OPENED WHEN OPERATING THIS GAS LOG SET LIGHTING INSTRUCTIONS 1. Locate the pilot burner at the rear of the log set on the right side. - Page 9 FOR YOUR SAFETY READ BEFORE LIGHTING: WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. A. This fireplace is equipped with a pilot which must be lit by hand while following these instructions exactly.
-
Page 10: Log Placement
LOG PLACEMENT PHAZER logs, exclusive to Napoleon Fireplaces, provide a unique and realistic glowing effect that is different in every installation. These logs are fuel specific. Do not interchange. Refer to the replacement parts list. Failure to follow these log placement instructions may cause sooting. -
Page 11: Finishing
FINISHING 1. Place lava or ember rock around the base of the appli- ance, making sure not to block any burner ports or valve access. Retain a small amount of lava rock for step 3 and if applicable step 4. 2. -
Page 12: Replacement Parts
Contact your dealer for questions concerning prices and availability of replacement parts. Normally all parts can be ordered through your Napoleon dealer or distributor. When ordering replacement parts always give the following information: FOR WARRANTY REPLACEMENT PARTS THE ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM Part # Description...
