- Page 1 ETA-S20 AC Power Distribution Unit & Surge Suppressor ETA-S20 AC Power Distribution Unit & Surge Suppressor 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. Telephone: 800-321-6699 • Fax: 800-996-3821 – 1 – ETAsys.com Specifications are subject to change without notice.
- Page 2 ETA-S20 AC Power Distribution Unit & Surge Suppressor TABLE OF CONTENTS Important Safety Instructions ........................3 Introduction ............................5 Key Features ............................5 Applications ............................5 Front Panel Description ........................... 6 Rear Panel Description ..........................6 Installation .............................. 7 Specifications ............................7 Warranty ..............................
-
Page 3: Safety Instructions
ETA-S20 AC Power Distribution Unit & Surge Suppressor SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage “ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. - Page 4 WARNING – WHEN THE DEVICE IS IN USE • To prevent electric shock, do not remove the product cover as there are high voltage components inside. Refer all servicing to ETA Systems. • Should any of the following irregularities occur during use, immediately switch off the power, disconnect the power cord from the AC outlet and contact ETA Systems. Do not to attempt to continue operation with the product as this may cause fire or electric shock: • Smoke or strange smell coming from the unit. •...
-
Page 5: Key Features
The ETA-S20’s circuitry is very fast and can suppress unwanted energy within a nanosecond response and sustain the suppression up to 2 milliseconds, thus ensuring virtually trouble-free protection. If the suppression circuitry is damaged, the AC Protect LED will turn Off to indicate a fault has occurred. -
Page 6: Front Panel Features
2. AC Mains Breaker The 120VAC 20A 2500W rated breaker will open if the combined draw of all AC outlets exceeds 20A. Note: The breaker is designed to exceed its rating for a short period of time. If the breaker is tripped, you must first remove the load from the ETA-S20 and then push to reset. 3. Power Switch To turn the ETA-S20 On or Off, press the switch to the ON or OFF position. This switch powers the “switched” outlets. The switch... -
Page 7: Installation
AC Power Distribution Unit & Surge Suppressor INSTALLATION Before installing, we strongly suggest you read the entire manual to ensure you benefit from all the features of the ETA-S20. The ETA-S20 can be placed on a shelf or rack mounted in a standard 19" width rack. When rack mounted, placement within the rack is flexible however the ETA-S20 should be within 6' of a dedicated 20A AC outlet. When rack mounting, use Rack Rail type screws which ⁄ " x 1". Always make sure the 20A outlet is properly inspected by a certified electrician prior to connecting the ETA-S20. Make sure to inspect the equipment that is to be plugged into the ETA-S20 to ensure it does not exceed 20A total amperage draw. -
Page 8: Limited Warranty
This warranty shall extend from the date of purchase for a period of one year. Additionally, fuses and lamps carry no warranty. ETA Systems will solely at its discretion, replace at no charge or repair free of charge defective parts or products when the product has been applied and used in accordance with our published operation and installation instructions.
