Distributed by:
Duraflame, Inc., Stockton, CA 95201
For questions about Assembly and Operating instructions or Warranty Claims
contact Duraflame, Inc. Consumer Affairs
info@duraflame.com
1 (866) 552-3015
www.duraflame.com/illuma
Patents Pending
Tested to UL 1370 for "unvented bio-ethanol burners" by PFS Corporation
Note: Any reference to Burner or Burners applies to both burners in this entire document.
WARNING: If the information in this manual is not followed exactly, a fire or explosion may
result, causing property damage, personal injury, or loss of life.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IN THE EVENT OF AN ALCOHOL SPILL: DO NOT light the burner. Extinguish
any open flame near the spill. Wipe up the spill, and wait several minutes for the residue to
evaporate.
WARNING: Improper installation, adjustment, alteration, service, or maintenance can cause
injury or property damage. Refer to this manual for correct installation and operational
procedures.
WARNING: This appliance is for installation only in a solid-fuel-burning masonry fireplace, a
UL127 factory-built fireplace, or in an ANSI Z21.91 ventless firebox. It is design certified for
these installations in accordance with UL1370. Exception: Do not install this appliance in a
factory-built fireplace that includes instructions stating that it has not been tested or should
not be used with unvented gas logs.
This appliance may be installed in a fireplace or firebox approved for aftermarket, permanently
located, manufactured (mobile) homes, where not prohibited by local codes.
This appliance is for use only with duraflame
rating plate. This appliance is not convertible for use with other fuels, nor should you use
illuma-fuel
with any product other than duraflame
®
Save this manual for future reference.
Bio-ethanol fireplace burner and 24" log set
Model # 61020
illuma-fuel
or types of fuel indicated on the
®
®
illuma
log sets.
®
®
-1-
Advertisement
Table of Contents
Related Manuals for Duraflame iLLUMA 61020
Summary of Contents for Duraflame iLLUMA 61020
- Page 1 This appliance may be installed in a fireplace or firebox approved for aftermarket, permanently located, manufactured (mobile) homes, where not prohibited by local codes. This appliance is for use only with duraflame illuma-fuel or types of fuel indicated on the ®...
-
Page 2: Table Of Contents
TABLE OF CONTENTS page Safety Information ................ 3 Setup .................... 5 III. Minimum Firebox Dimensions ............6 Clearances ..................7 Installing Damper Stop ..............7 Installation ..................7 VII. Installing the Fuel Canister ............11 VIII. Operation ..................11 Refueling ..................13 Adjustments ................ -
Page 3: Safety Information
I. SAFETY INFORMATION IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this appliance. Improper use of this appliance or failure to comply with the safety rules can cause serious injury or death from burns, fire, explosion, or carbon monoxide poisoning. - Page 4 For contact with skin, rinse well with cool water. If irritation develops, see your doctor. Do not remove a duraflame illuma-fuel canister from the appliance until the canister is completely empty. WHAT TO DO IN THE EVENT OF A FUEL SPILL OR FUEL LEAK: DO NOT light the burner.
-
Page 5: Setup
In case of burns, seek treatment from your doctor or hospital. Duraflame accepts no responsibility for any damage that might result if this appliance is improperly installed, incorrectly operated, used for purposes other than that for which it is intended, or if it is repaired by unqualified persons. -
Page 6: Minimum Firebox Dimensions
Sliding Burner Cover Back Log Pin Burner Heat Shield Sparker Fuel Reservoir Tank Tray Back Log Support Burner Sparker Piercer Handle Fuel Tank Bracket Screw-down Hole (Another hole on opposite side) Burner / Base Grate Ignition Button Figure 1 Appliance Overview Install this appliance in compliance with all local building codes. -
Page 7: Clearances
• Two (2) appliance base screws inside a small bag. • One AA battery. If components are missing, contact Duraflame Consumer Affairs. 2. Remove all these components from their packaging. When handling the logs, take care not to damage them. Keep packing materials away from children, as they could be a choking or suffocation hazard. - Page 8 If after remedying both issues the sparker still does not create a spark, contact the installer, the store where you purchased the product or Duraflame, Inc.
- Page 9 Figure 3 Figure 4 Logs Placement of front log Figure 5 Figure 6 Showing space between tray Showing space between tray and log inside wall on the left and log inside wall on the right Figure 7 Figure 8 Placement of rear log Placement of right log...
- Page 10 Figure 9 Figure 10 Placement of left log Placement of front middle log Figure 11 Figure 12 Placement of back middle log All logs properly placed Figure 13 Proper placement of front log with a gap between the back of the tray and the hinge plate -10-...
-
Page 11: Installing The Fuel Canister
The burner should light. If it does not, hold down the igniter button until it does. You may need to wait a minute or so to allow the duraflame illuma-fuel to flow into the burner reservoir. Initially, the flames might be low with a bluish hue. The flames should grow in height and become yellow and orange as the fuel heats up. - Page 12 4. To extinguish the flames, grasp the handle of the snuffer device, and slide the cover forward over the burner slot. The slot must be completely covered to extinguish the flames. This appliance can be relit at any time—even immediately after extinguishing, if desired, using the igniter. However, if the fuel is hot or even warm the fuel may not ignite using the sparker because the fuel is evaporating at a higher rate than usual and creates and oxygen free environment around the sparker.
-
Page 13: Refueling
Figure 18 Check for leaks on the floor of the fireplace under the areas indicated. IX. REFUELING This appliance is designed so that one canister of illuma-fuel (1 L) will provide a continuous supply ® of fuel to the burner for about an hour and thirty minutes*. To allow for uninterrupted burning beyond this time, the burner has been designed so that ten minutes before the fuel is completely exhausted, the flame will start to shift to the right burner only and then to the right side of the right burner. -
Page 14: Adjustments
Figure 19 Figure 20 Area safe to touch log while How to remove canister when fire is burning fire is burning X. ADJUSTING BURN TIME You can extend the burn time and flame height of the fire. Experiment with different settings by slowly moving the snuffer forward as you would when you want to extinguish the flame (see Section IX Step 4), but do not cover the burner completely, or the fire will be extinguished. - Page 15 6. Dust the logs gently. 7. Make sure that all parts of the appliance are returned to their proper operating positions by following assembly instructions. Ensure the logs and the piercer are installed properly (see Figure 21). The top surface of the piercer should be level. If it is higher on the left end, then turn it around and place it back in place again.
-
Page 16: Troubleshooting
XII. TROUBLESHOOTING Use the following guide to solve any problems you might encounter in operating this appliance. PROBLEM SOLUTION 1. You see fuel on the ground near the • DO NOT light the burner. Extinguish any open appliance. flame near the spill. Wipe up the spill, and wait several minutes for the residue to evaporate. -
Page 17: Parts List
XIII. PARTS LIST Part Number 61021 Burner / Base 61022 Igniter 61023 Front Log 61024 Back Log 61026 Left Log 61025 Right Log 61027 Front Middle Log 61028 Back Middle Log 61007 Canister Tray & Piercer 61030 Heat Shield 61031 Grate 61010 Masonry Screws 61011 Sparker 61034 Complete Set of Logs... -
Page 18: Warranty
Correction in the manner provided above shall constitute a fulfillment of all liabilities of Duraflame, Inc. with respect to the quality of the product. The product MUST be installed by a person capable of following all instructions in accordance with all local codes and instructions furnished with the unit. - Page 19 This warranty gives you specific legal rights, and you may also have other rights that vary from state to state. For information about this warranty write to: Attn: Consumer Affairs, Duraflame, Inc., 2894 Monte Diablo Ave., Stockton, CA 95203, www. duraflame.com -19-...
