Distributed by:
Duraflame, Inc., Stockton, CA 95201
For questions about Assembly and Operating instructions or Warranty Claims
contact Duraflame, Inc. Consumer Affairs
info@duraflame.com
1 (866) 552-3015
www.duraflame.com/illuma
Patents Pending
WARNING: If the information in this manual is not followed exactly, a fire or explosion may
result, causing property damage, personal injury, or loss of life.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IN THE EVENT OF AN ALCOHOL SPILL: DO NOT light the burner. Extinguish any
open flame near the spill. Wipe up the spill, and wait several minutes for the residue to evaporate.
WARNING: Improper installation, adjustment, alteration, service, or maintenance can cause injury
or property damage. Refer to this manual for correct installation and operational procedures.
WARNING: This appliance is designed for installation only in a solid-fuel-burning masonry fireplace,
a UL127 factory-built fireplace, or in an ANSI Z21.91 ventless firebox, or on a table or cabinet.
There are no other standards for this type of appliance for other installations, thus be very careful
and follow all directions for such installations.
This appliance may be installed in a fireplace or firebox approved for aftermarket, permanently
located, manufactured (mobile) homes, where not prohibited by local codes.
This appliance is for use only with duraflame
rating plate. This appliance is not convertible for use with other fuels, nor should you use
illuma-fuel
with any product other than duraflame
®
Save this manual for future reference.
22" Bio-ethanol Indoor/Outdoor Fireplace
Model # 64000
illuma-fuel
or types of fuel indicated on the
®
®
illuma
fireplaces.
®
®
-1-
Advertisement
Table of Contents
Related Manuals for Duraflame illuma 64000
Summary of Contents for Duraflame illuma 64000
- Page 1 22” Bio-ethanol Indoor/Outdoor Fireplace Model # 64000 Distributed by: Duraflame, Inc., Stockton, CA 95201 For questions about Assembly and Operating instructions or Warranty Claims contact Duraflame, Inc. Consumer Affairs info@duraflame.com 1 (866) 552-3015 www.duraflame.com/illuma Patents Pending WARNING: If the information in this manual is not followed exactly, a fire or explosion may result, causing property damage, personal injury, or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS page Safety Information ................ 3 Setup .................... 5 III. Minimum Firebox Dimensions ............7 Clearances ..................7 Installing Damper Stop ..............7 Installation ..................7 VII. Installing the Fuel Canister ............10 VIII. Operation ..................10 Refueling ..................12 Adjustments ................ -
Page 3: Safety Information
I. SAFETY INFORMATION IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this appliance. Improper use of this appliance or failure to comply with the safety rules can cause serious injury or death from burns, fire, explosion, or carbon monoxide poisoning. - Page 4 For contact with skin, rinse well with cool water. If irritation develops, see your doctor. Do not remove a duraflame illuma-fuel canister from the appliance until the canister is completely empty. WHAT TO DO IN THE EVENT OF A FUEL SPILL OR FUEL LEAK: DO NOT light the burner.
-
Page 5: Setup
If water has entered the burner reservoir of the appliance, ensure that the water has been emptied from the appliance before use. Water can dilute the duraflame illuma-fuel and affect the performance of the appliance. Do not use the appliance if there is visible damage. If you see damage, contact the store where purchased or Duraflame’s customer service. - Page 6 WARNING: Seal any fresh air vent or ash clean-out doors located on the floor or walls of the fireplace. Failure to do so may result in drafts that could cause sooting. Use a heat-resistant sealant. Do not seal the chimney flue damper. WARNING: Never install this appliance in a bedroom or bathroom unless installed as a vented appliance in a recreational vehicle where curtains, furniture, clothing, or other flammable objects are less than 42 inches from the front, top, or sides of the appliance or in high traffic...
-
Page 7: Minimum Firebox Dimensions
III. MINIMUM FIREBOX DIMENSIONS WARNING: Maintain or exceed the minimum clearances. IV. CLEARANCES (Vent-free operation only) Firebox Side Firebox Back 18” 26” at least 12” Figure 2 Minimum Dimensions of Firebox WARNING: Maintain or exceed the minimum clearances. V. INSTALLING DAMPER STOP (Vented operation) For vented operation of this appliance, a damper stop must be installed in the fireplace to prevent full closure of the damper blade. - Page 8 3. Check each component for shipping damage. If components are damaged, contact the store where purchased or Duraflame, Inc. 4. a1. If installing this unit in a firebox, check the firebox dimensions to ensure that they are at least equal to the minimum dimensions shown in Figure 2. The minimum clearances that the appliance originally required will be adequate for this installation.
- Page 9 Figure 3 Figure 4 Placement of rear glass panel Placement of right glass panel Figure 5 Figure 6 Placement of left glass panel Placement of front glass panel...
-
Page 10: Installing The Fuel Canister
If it does not, hold down the igniter button until it does. You may need to wait a minute or so to allow the duraflame illuma-fuel to drain into the burner reservoir and reach the right level before you push the sparker button. Initially, the flames might be low with a bluish hue. - Page 11 Figure 7 Figure 8 Door on side open Proper placement of canister Figure 9 How to operate snuffer 4. To extinguish the flames, grasp the snuffer knob, and turn it towards you to move the burner cover forward. The slot must be completely covered to extinguish the flames. This appliance can be relit at any time—even immediately after extinguishing, if desired, using the igniter.
-
Page 12: Refueling
Figure 10 Check for leaks on the floor of the fireplace under the areas indicated. IX. REFUELING This appliance is designed so that one canister of illuma-fuel (1 Liter) will provide a continuous ® supply of fuel to the burner for about two hours and thirty minutes*. To allow for uninterrupted burning beyond this time, the burner has been designed so that a few minutes before the fuel is completely exhausted, the flame will start to shift to the right side of the burner. -
Page 13: Adjustments
6. If the flame is out by this time, use the igniter to start it again. *NOTE: Burn times will vary depending on conditions such as temperature, draft and how level the surface is. Figure 11 How to remove canister when fire is burning X. - Page 14 burner may be very sharp. 5. Make sure that all parts of the appliance are returned to their proper operating positions by following assembly instructions. Ensure the piercer is installed properly (see Figure 12). The top surface of the piercer should be level. If it is higher on the back end or on one side, then turn it around and place it back in place again.
-
Page 15: Troubleshooting
XII. TROUBLESHOOTING Use the following guide to solve any problems you might encounter in operating this appliance. PROBLEM SOLUTION 1. You see fuel on the ground near the • DO NOT light the burner. Extinguish any open appliance. flame near the spill. Wipe up the spill, and wait several minutes for the residue to evaporate. -
Page 16: Parts List
XIII. PARTS LIST Part Numbers 64001 Small Glass 64002 Large Glass 61002 Igniter 61007 Canister Tray & Piercer 61010 Masonry Screws 61011 Sparker 64003 Hold Downs -16-... -
Page 17: Warranty
We reserve the right to amend the specifications of this product at any time without notice. The only warranty applicable is our standard written warranty. We make no other warranty, expressed or implied. LIMITED WARRANTY – DURAFLAME ILLUMA LOG SETS, FIRE PITS & FIREPLACE APPLIANCES ®... - Page 18 Some states do not allow a limitation on how long an implied warranty lasts or an exclusion or limitation of incidental or consequential damages, so the above limitation on implied warranties, or exclusion or limitation on damages may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state.
