- Page 1 ® CINEMA VISION ™ CVSAT50, CVCEN50, CVSUB50 OWNER’S GUIDE...
-
Page 2: Read First
READ FIRST! CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. Refer servicing to qualified service personnel. CAUTION: To prevent electric shock, do not use this (polarized) plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure. - Page 3 Floor Stand Cover † CVCEN50 One CVCEN50 loudspeaker with mounting brackets, wall-mount bracket attachment plate, cradle and speaker cable. Each CVCEN50 speaker comes with a mounting bracket and metal clip preinstalled, as shown in the diagram at the bottom of page 7. These parts are essential for mounting the speaker on the wall, or in the included cradle, and, therefore, should never be removed from the speaker.
-
Page 4: Speaker Placement
The JBL Cinema Vision speaker system may be used in 5.1-, 6.1- or 7.1-channel applications. In 5.1-channel applications, two of the sur-... -
Page 5: Mounting Options
MOUNTING OPTIONS SATELLITES AND SURROUNDS On shelves using the optional CVTS50 table stands. ATTACHING THE CVTS50 TABLE STAND (AVAILABLE SEPARATELY) TO THE CVSAT50 Important Safety Notes: • The table stand consists of two main parts: a metal col- umn and a glass base. Be extremely careful in han- dling the fragile glass base to avoid breakage that... - Page 6 JBL disclaims any liability for the selection of suitable floor stands and/or correct compatibility between the selected stand and the supplied stand adaptor.
-
Page 7: Wall Mounting
(–) conductor to the right as you face the wall. ATTACHING THE CRADLE TO THE CENTER SPEAKER Important Safety Notes: • The CVCEN50 cradle is only intended for use with the CVCEN50 speaker. Attempting to use the cradle with any... -
Page 8: Speaker Connections
Speakers and elec- tronics terminals have corre- sponding (+) and (–) termi- nals. Most manufacturers of speakers and electronics, including JBL, use red to denote the (+) terminal and black to denote the (–) terminal. The (+) lead of the speaker wire is noted with a stripe. -
Page 9: System Connection
SYSTEM CONNECTION The CVSUB50 subwoofer is equipped with only one input – a dedicated low- frequency effects (LFE) input. Since the LFE channel is by definition limited to only the lowest portion of the fre- quency spectrum, it is cru- cial that your receiver’s out- put be compatible. -
Page 10: Subwoofer Operation
SUBWOOFER OPERATION Press the Master Power switch (marked “Power” å) in to the On position to use the subwoofer. The CVSUB50 subwoofer will automatically turn on or go into standby (sleep) mode as described below. When your receiver or amplifier is off, or is not sending program material to the subwoofer, the sub- woofer will be in standby... -
Page 11: Troubleshooting
If the problem has fol- lowed the speaker, consult your dealer for further assis- tance or, if that is not possi- ble, visit www.jbl.com. If there is no sound from the center speaker: • Check all wires and con- nections between receiver/ amplifier and speaker. -
Page 12: Specifications
P R O D U C T L I N E : JBL CINEMA VISION CVSAT50, CVCEN50, CVSUB50 MODELS: Bring the thrill of live performance and movie sound DESIGN GOAL: to the home environment by calling on JBL’s professional engineering leadership. Titanium-laminate-dome tweeter, SATELLITE TYPE: sealed enclosure Bass-reflex enclosure SUBWOOFER TYPE: FreeFlow ™...
