About your AIS class B transceiver
In addition there are two other connections for the VHF antenna and an optional external GPS antenna. Figure 3 shows an overview of
the electrical connections to the AIS transceiver.
AIS Class B
Power in
transceiver
Switch
NMEA0183
device
Chartplotter
USB
NMEA 2000
Figure 3
Electrical connections to the AIS transceiver
