MODEL 7151 / AGES 13+ / 39 MPH MAX SPEED
7151 150cc FUN KART
OWNER'S MANUAL / PARTS GUIDE
15516R1
THIS VEHICLE IS FOR OFF-ROAD USE ONLY THIS VEHICLE IS NOT DESIGNED FOR USE ON RENTAL TRACKS OR RACING
BEFORE OPERATING THIS VEHICLE, THE OWNER AND EACH OPERATOR MUST UNDERSTAND THIS VEHICLE WAS NOT DESIGNED OR MANUFACTURED TO MEET SPECIFICATIONS FOR USE ON PUBLIC ROADS,
STREETS, HIGHWAYS AND THOROUGHFARES. THE OWNER AND EACH OPERATOR MUST READ AND UNDERSTAND ALL THE INSTRUCTIONS FOR PROPER ASSEMBLY AND SAFE OPERATION, AS WELL AS THE
INSTRUCTIONS CONCERNING THE ENGINE AND ALL OTHER PORTIONS OF THE VEHICLE. CHILDREN MUST BE 13+ YEARS OF AGE FOR THIS VEHICLE AND SUPERVISED BY AN ADULT AT ALL TIMES WHEN USING
THIS FUN KART. SPEED REDUCTION KITS ARE AVAILABLE FOR ALL VEHICLES. THIS VEHICLE IS NOT A TOY.
Advertisement
Table of Contents
Related Manuals for American Sportworks 7151 150cc
Summary of Contents for American Sportworks 7151 150cc
- Page 1 Book 2 of 2 MODEL 7151 / AGES 13+ / 39 MPH MAX SPEED 7151 150cc FUN KART OWNER’S MANUAL / PARTS GUIDE 15516R1 THIS VEHICLE IS FOR OFF-ROAD USE ONLY THIS VEHICLE IS NOT DESIGNED FOR USE ON RENTAL TRACKS OR RACING BEFORE OPERATING THIS VEHICLE, THE OWNER AND EACH OPERATOR MUST UNDERSTAND THIS VEHICLE WAS NOT DESIGNED OR MANUFACTURED TO MEET SPECIFICATIONS FOR USE ON PUBLIC ROADS, STREETS, HIGHWAYS AND THOROUGHFARES.
- Page 2 EMISSION CONTROL SYSTEM WARRANTY STATEMENT FOR 150cc ENGINES Your warranty rights and obligations The U.S. Environmental Protection Agency and Geason Enterprises, LLC dba Geason Powersports (hereinafter “Geason Powersports”) are pleased to explain the emission control system warranty on your 2013 Off-Road ATV. New off-road motor vehicles must be designed, built and equipped to meet U.S. EPA Federal anti-smog standards. Geason Powersports must warrant the emission control system on your vehicle for 5,000 km, or at least 30 months, whichever comes first, provided that there has been no abuse, neglect or improper maintenance of your vehicle.
-
Page 3: Limited Warranty
American SportWorks (hereinafter referred to as “ASW”) hereby warrants to the original purchaser that the frame components of new ASW fun karts will be free from defects in material and workmanship. The period of warranty is thirty (30) days from date of purchase for the component parts (except as noted below), ninety (90) days from the date of purchase for the frame, and one (1) year from date of purchase on select engines. -
Page 4: Table Of Contents
TABLE OF CONTENTS Emissions Warranty ..............i ASW Limited Warranty . -
Page 5: Emissions Warranty
This vehicle is designed for for some reason, you did not receive these items please drivers and riders 13 years and older. contact American Sportworks or visit our website at www. amsportworks.com. For more information on American Sportworks and its WARNINGS AND CAUTIONS products visit our website at www.amsportworks.com. -
Page 6: Section 2 Operation
SECTION 2 operation KART OPERATION A. Operation controls WARNING Do not attempt to start or operate the engine until completely familiar with the location and use of each control necessary to operate this vehicle. The operator must know how to stop this machine before starting and driving it. - Page 7 SECTION 2 operation G. Seat Adjustment The unit is equipped with an adjustable driver’s seat. To adjust, lift the lever just in front of the seat bottom and move the seat either forward or backward. Release the lever at the desired seat location, ensuring that it snaps back into place to lock the seat in position. WARNING Never operate this vehicle when the seat is not securely locked into position.
-
Page 8: Kart Features And Locations
SECTION 2 operation L. Park Brake (see fig. L1) The park brake should be applied during starting, engine warming (choke cycle), and anytime the vehicle is parked and/or left unattended. The park brake is set by applying pressure to the brake pedal and latching the locking lever over the latch pin. To apply the park brake fig. -
Page 9: Section 3 Service
Take this manual and all supplements to the dealer when ordering parts in person. If replacement parts are not available from a dealer, they may be ordered directly from American Sportworks by contacting ASW at 1-800-643-7332 or online at www.amsportworks.com. -
Page 10: Spark Plug
SECTION 3 service C. Spark Plug (see fig. C1) a. Remove the spark plug and inspect it each time you change the oil (Use a spark plug wrench). The electrodes should be kept clean and free of carbon. The presence of carbon or excess oil will greatly reduce engine performance. -
Page 11: Shock Adjustment
SECTION 3 service H. Adjustment of Front and Rear Shock (see fig. H1) There are five adjustable positions on each shock. The center notch is the default position as set by the manufacturer (Ref Figure). Use a round nut wrench to adjust the shock. -
Page 12: Section 4 Maintenance
SECTION 4 maintenance GENERAL MAINTENANCE A. Front Wheel Replacement (see fig. A1) Do not disassemble the castle nuts when you replace the front wheels. It is only necessary to remove the 4 lug nuts to remove the wheel. (See Figure) Tighten the nuts securely after replacing the wheels. -
Page 13: Specifications And Electrical Schematic
SECTION 4 maintenance 7151 SPECIFICATIONS ENGINE FRAME Type Single Cylinder, 150cc, Air Cooled, 4 cycle Type - Heavy Gauge - Jig Welded 1.25” Main Frame Power (BHP @ RPM) ≈ 9.0 @ 7500 Rear Axle 1.25” Hardened Alloy Steel Torque (Ft-lbs @ RPM) ≈...
