Table Of Contents
Button Description ................................................................2-3
Battery Installation ..................................................................3
Programming Your Universal Remote
TV........................................................................................4
TV Codes ........................................................................4-5
VCR ....................................................................................6
VCR Codes ....................................................................6-7
Cable Box ..........................................................................8
Cable Box Codes ..............................................................9
Aux....................................................................................10
Code Search ............................................................................11
Code Retrieval ........................................................................11
Sleep Feature ..........................................................................12
Trouble Shooting ....................................................................13
Button Description
INDICATOR LIGHT
The Indicator Light flashes to show that the remote is working.
POWER
The POWER button operates the same as your original remote
(note: some RCA, GE and ProScan models require you to press
the device key to turn the device on and the power key to turn the
device off).
CODE SEARCH
Used to program the remote or to search through codes.
TV, VCR, CABLE, AUX
The TV, VCR, CABLE and AUX buttons are used to select the
device you want to control.
REW, PLAY, FWD, REC, STOP, PAUSE
The REW (Rewind), PLAY, FWD (Fast Forward), REC (Record),
STOP, and PAUSE buttons operate the same as on your original
VCR remote. You must press the REC button twice to begin
recording.
TV•VCR
The TV•VCR button operates the TV•VCR function of your VCR.
ENTER
The ENTER button operates the same as on your original remote.
VOL & CHAN
The VOL (Volume) and CHAN (Channel) arrows increase or
decrease the channel numbers or volume controls.
MUTE
The MUTE button operates the same as on your original remote.
PREV CH
The PREV CH (Previous Channel) button operates the same as on
your original remote.
0-9
The number buttons operate the same as on your original remote,
and are used for entering device codes.
A•B
The A•B button operates the A•B switch if your cable box has one.
SLEEP
The SLEEP button allows you to set a time to turn off the TV
automatically.
2
Battery Installation
Your Universal Remote requires two (2) new AAA
alkaline batteries. To install the batteries:
1. On the back of the remote, push down on the tab
and lift the cover off.
2. Match the batteries to the + and - marks inside the
battery case, then insert the batteries.
3. Press the battery cover back into place.
Button Description
POWER
CODE SEARCH
REW
REC
TV•VCR
MUTE
1
4
7
A
•
TV
VCR
CABLE
AUX
PLAY
FWD
STOP
PAUSE
ENTER
CHAN
CHAN
PREV CH
2
3
5
6
8
9
0
B
SLEEP
3
Advertisement
Table of Contents
Related Manuals for GE 94902 RM94902
Summary of Contents for GE 94902 RM94902
- Page 1 The SLEEP button allows you to set a time to turn off the TV automatically. Battery Installation Your Universal Remote requires two (2) new AAA alkaline batteries. To install the batteries: 1. On the back of the remote, push down on the tab and lift the cover off.
-
Page 2: Programming For Tv
Programming For TV 1. Manually turn on the TV. 2. Press and hold the CODE SEARCH button until the INDICATOR LIGHT lights, then release the CODE SEARCH button. 3. Press and release the TV button (the INDICATOR LIGHT will blink then remain lit). 4. -
Page 3: Programming For Vcr
Programming For VCR 1. Manually turn on the VCR. 2. Press and hold the CODE SEARCH button until the INDICATOR LIGHT lights, then release the CODE SEARCH button. 3. Press and release the VCR button (the INDICATOR LIGHT will blink then remain lit). 4. -
Page 4: Programming For Cable Box
Garrard...011 CABLE GC Electronics ...009 Gemini ...018, 019, 049 General Instrument ...003 Hamlin...020, 021, 022 Hitachi ...003 Hytex ...002 Jasco ...011 Jerrold ...001, 003, 005, 007 Magnavox ...025 Memorex ...026 Movie Time ...002, 027 A¥B SLEEP NSC ...002, 027 Oak ...002, 016, 029 Panasonic...000, 048... -
Page 5: The Aux Button
The AUX Button The AUX Button allows you to assign another TV, VCR or Cable Box to be controlled. 1. Manually turn on the the device you wish to assign to the AUX button (TV, VCR or Cable Box). 2. Press and hold the CODE SEARCH button until the INDICATOR LIGHT lights, then release the... -
Page 6: Sleep Feature
Sleep Feature This feature will turn off your TV at the time you choose from 1 to 99 minutes. To Program Sleep Feature: 1. Press and hold the SLEEP button. INDICATOR LIGHT will stay lit. Release the SLEEP button. 2. Enter time in minutes using the numerical key pad. -
Page 7: How To Order
City/State: ________________________________________ Zip: ______________________________________________ Daytime Phone Number: ____________________________ Card Number: Exp:________________ Signature: ________________________________________ 1-800-654-8483 Jasco Products Company 311 NW 122nd Street Oklahoma City, Oklahoma 73114 Include this completed form with your order. Model # TL96597 TL96596 We are required by law to collect... - Page 8 90 Day Limited Warranty Jasco Products Company warrants this product to be free from manufacturing defects for a period of ninety days from the origi- nal date of consumer purchase. This warranty is limited to the repair or replacement of this product only and does not extend to consequential or incidental damage to other products that may be used with this unit.
