atBox Technology InternetVue DT11‐KIT User Manual page 9

Now, you can enter an IP address for this unit, and also a friendly device name. Some rules‐of‐thumb:

Because the DT11 / DT70 units will not be interacting with any other devices on your
network, the IP address should be on a subnet which is currently not used by any device on
your network. For example, if your router and DHCP server use the 192.168.1.x subnet, you
set all your DT11 / DT70 devices to another subnet, such as its current factory subnet
192.168.168.x. However, be sure that every DT11 / DT70 unit has a unique address.

For the Device Name, use a descriptive name which can easily be identified by the user. See
example below.

When done, click on SAVE, then EXIT. The unit will restart.
1.7. Disconnect the Ethernet cable from your computer and the unit. The DT11 / DT70 unit is now configured
with the IP address 192.168.168.200, and Device Name "Lobby TV".
1.8. Repeat steps 1.2 to 1.7 for all DT11 / DT70 units in your setup, making sure each unit has a different IP
address, but MUST HAVE the same first three octets (ie. 192.168.168.x). Here is an example:
Unit Type
DT11‐RX
DT11‐RX
DT11‐TX
DT11‐TX
1.9. Go back to the TCP/IP properties window as shown in
step 1.1.1 above, and change it back to "Obtain an IP
address automatically". Click OK, then OK, then CLOSE.
Device Name
Lobby TV
Upstairs TV
DVD‐Player‐1
DVR
Permitted IP Address Ranges:

192.168.0.0 to 192.168.254.254

172.16.0.0 to 172.31.254.254

10.0.0.0 to 10.254.254.254
IP Address
192.168.168.200
192.168.168.201
192.168.168.202
192.168.168.203
