atBox Technology InternetVue DT11‐KIT User Manual page 15

2. Run‐time OSD
When the DT11‐RX is streaming video from a source transmitter, the OSD options are different than in #1
above. Again, pressing the SOURCE button brings up the OSD:
> DVD‐1 (00:00:20) connected
> APPLE‐3 (00:00:26)
> REFRESH
> VGA SYNC
> PCA SETTING
> TVA OFF
> EXIT

In the Run‐Time OSD, the list of available transmitters is listed first. In the example here, two
transmitters are shown, "DVD‐1" and "APPLE‐3". The numbers in the parentheses are its MAC
addresses. The "connected" status indicates that this DT11‐RX unit is currently showing the AV
stream from the transmitter "DVD‐1".
To select another transmitter's content to display, simply press the SOURCE button again until it is
highlighted, wait three seconds, and its stream will be shown instead.

VGA SYNC (appears only if input at transmitter is VGA) re‐synchronizes VGA signal

REFRESH will search the network again for any enabled DT11‐TX (PCA) units

PCA SETTING brings up the options for the currently selected transmitter. Select this option to go to
the next menu below

TVA OFF disables the DT11‐RX from displaying any video or audio

EXIT turns off the OSD
> MULTI/ONE TVA
> BANDWIDTH SETTING
> INFORMATION
> EXIT

MULTI/ONE TVA brings up the MULTI/ONE menu below

BANDWIDTH SETTING brings up the BANDWIDTH menu below

INFORMATION displays the current operating modes of both the receiver and currently
selected transmitter

EXIT turns off the OSD
> ONE TVA ONLY
> MULTI TVA
> EXIT

ONE TVA ONLY sets the currently selected transmitter to Unicast mode wherein
only this receiver can display that transmitter's content

MULTI TVA sets the currently selected transmitter to Multicast mode wherein more
than one receiver can display that transmitter's content

EXIT turns off the OSD
