CYBEX VR3 Chest Press Owner's And Service Manual page 32

ITEM QTY PART NO.
1 1 08229
2 1 11000-384
3 1 11040-301
4 2 11040-440
6 1 12001-200
7 1 12000-201
8 1 12000-202
9 1 12000-203
10 1 12000-204
11 1 12000-205
12 1 12000-207
13 1 12000-208
14 2 12000-307
15 2 12000-333
16 1 12000-337
17 1 12000-339
18 1 12000-340
19 1 12000-342
20 1 12000-343
21 1 12000-344
22 1 12000-345
23 1 12000-353
24 2 12000-368
25 2 12000-369
26 1 12000-392
27 1 12000-393
28 1 12000-395
29 2 12000-396
30 1 12000-420
31 4 12000-398
32 1 12000-598*
33 1 12000-999*
34 4 12050-346
35 1 12050-348
36 3 12050-368
37 2 12050-369
38 2 12050-370
39 4 12050-375
40 2 12060-350
41 1 12070-329
42 1 12070-394
43 3 12090-322
44 7 12100-303
45 2 12102-330
46 1 12190-208
47 2 12210-347
48 2 12210-348
49 3 4000Y316-X*
50 2 4520-362-X*
51 1 4605-381-X*
52 1 4715-346
53 1 51198
54 2 610A-350
55 1 BS070201
56 2 BS070208
57 1 CM000211
*Language Key
1-German
2-French
3-Spanish
4-English
6- Japanese
7-Swedish
8-Russian
Service
Page 6-4
Cybex VR3 12001 Chest Press Owner's Manual
DESCRIPTION
PIN,DETENT
BLOCK, STOP
CLAMP BLOCK INSERT
KNOB
MAIN FRAME
ARM RH
ARM LH
ARM LINKAGE
SEAT BACK
SEAT BOTTOM
DETENT LINK
DETENT PLATE
PIN, PIVOT
TIE ROD
SHAFT, PIVOT, 12.75
PIN, DETENT
DECAL, SEAT ADJUST
PIN, DETENT
LINK BAR
INSERT, PLASTIC
FOOT PAD, 4.00 x 7.00
GAS SPRING MOUNT
END CAP
RING, HANDLE GRIP
CHANNEL, INCREMENT WEIGHT
CHANNEL, INCREMENT WEIGHT
TOP CAP
END CAP
PANEL INSERT
SPACER
PLACARD, VR3 CHEST PRESS
OWNER'S MANUAL
WHEEL, PLASTIC ROLLER
GUIDE, ROLLER
LINK, SEAT MOUNT
ENDCAP
SPRING, TORSION
PIN, PIVOT
WT ROD .625 X 54.63
DECAL, ADJUSTING
DECAL, INDICATOR
FOOT PAD
BUMPER
INSERT, INCREMENT WEIGHT
DETENT BAR
GUIDE ROD CAP
GUIDE ROD CAP
DECAL, CAUTION
DECAL, CAUTION
WARNING LABEL
COM SPRING .72 x 1.50 LG
WARRANTY SHEET (NOT SHOWN)
END CAP
COM SPRING .56 x .66 1.50 LG
COMPRESSION SPRING
DECAL, PATENT PENDING
ITEM QTY PART NO.
58 1 EZ000008
59 2 FB030232
60 4 FB030247
61 2 FB030250
62 2 FB030251
63 8 FB130205
64 2 FC030006
65 4 FC030007
66 133'' GB000202
67 6 GP000209
68 1 HC622817
69 8 HC700416
70 4 HC700416
71 6 HC700428
72 2 HD303312
73 2 HF449064
74 12 HF579000
75 2 HN-60065
76 2 HN575100
77 2 HN625200
78 6 HN704901
79 2 HS347600
80 2 HS477100
81 8 HT512517
82 2 HX-60184
83 12 HX570412
84 3 HX620420
85 4 HY740000
86 2 JC620412
87 2 JC620415
88 2 JC620422
89 4 JC700412
90 6 JC700420
91 4 JD383315
92 2 JN794400
93 2 JN794401
94 4 JS347400
95 4 JS388300
96 4 PP080226
97 2 PP130002
98 2 PR060005
99 2 12000-350
100 1 4800-180
101 1 4800-183
102 1 4800-172
103 1 12000-467
104 4 HT570410
105 1 13000-402
106 1 13000-400
107 1 HT552515
108 2 HT512517
109 1 11000-407-X*
110 1 11040-790
111 1 12100-312
112 2 DE-60261
113 8 HC700417
DESCRIPTION
GAS SPRING 250N
BRG, RADIAL 17 mm EXT RACE
BRG, RADIAL 25 MM EXT RACE
BRG ROD END MALE .500-20 RH
BRG ROD END MALE .500-20 LH
BRG,FLG .62 x .75 .38 LG
TOLERANCE RING 1.575 ID
TOLERANCE RING 2.047 ID
STANDARD WEIGHT STACK BELT
.95 WIDE
PULLEY ASSEMBLY-3.50
SHCS .250-20 X 1.00
BHSCS .375-16 X .75
(REMOVED 6-9-2008)
BHSCS .375-16 X .875
BHSCS .375-16 X 2.25
S BOLT .250 X .500 .190-10-24
INSERT 1.12 X .250-20 UNC
PANEL FASTNER, 10-24 U TYPE
NUT, HEX SELF- LOCKING .312-18
BLK ZINC
LOCKNUT .190-No 10-24
LOCKNUT, .250-20 NYLON
LOCKNUT, .375-16 NYLON
WASHER, SAE .375
WSHR, SPRG 1.050 1.271 .100 T
TAP SC 10-24 X 1.00 TYPE WB PN
HD PHIL BLK
BALL STUD, .312-18 UNC x 10mm
BHSCS, 10-24 X .50, SS
BHSCS .2 0-20 X 1.250 SS
SET SCREW
BHSCS .250-20 X .50
BHSCS .250-20 X .75
BHSCS .250-20 x 1.50
BHSCS .375-16 X .50
BHSCS .375-16 X 1.25
SHOULDER BOLT .500 x .75
.375-16 UNC
JAM NUT .500-20
JAM NUT .500-20 LH
LOCKWASHER, INT TOOTH .375
SPLIT LOCKWASHER .500
INSERT, DOMED PLASTIC 2.00,
RIB
INSERT, DOMED PLASTIC
BUMPER, WEIGHT
GRIP 1.62 OD X 1.20 ID
BACK PAD W/WEAR COVER
WEAR COVER
SEAT PAD
PULLEY COVER
SCREW, PHN HD TORX 10-24 X
.375 BLK
MOUNT, WATER BOTTLE HOLDER
HOLDER, WATER BOTTLE
TAP SC NO 8-16 X.75
TAP SC 10-24 X 1.00 TYPE WB
INCREMENT WEIGHT DECAL
DECAL, MADE IN U.S.A.
BUMPER
PLUG
BHSCS .374-16 X 1.00
