Summary of Contents for Trust 742AV
- Page 1 742AV USB2.0 LCD POWER VIDEO User’s manual V1.0...
- Page 2 Thank you for your purchase. Register your product via our Internet site at www.trust.com/register, so that you will be eligible for optimal guarantee and service support. You will also be automatically informed of the development of your and other Trust products.
- Page 3 742AV USB2.0 LCD POWER VIDEO Fig. 1 Fig. 2 Fig. 3 Fig. 4...
- Page 4 742AV USB2.0 LCD POWER VIDEO Fig. 5 Fig. 6 Fig. 7 Fig. 8 Fig. 9 Fig. 10 Fig. 11...
-
Page 5: Table Of Contents
742AV USB2.0 LCD POWER VIDEO Table of contents INTRODUCTION..................2 ..............2 ENERAL COMMENTS REGARDING PHOTOGRAPHY SAFETY ......................3 ..................3 ENERAL INFORMATION ......................3 ATTERIES APPROVAL ....................3 DESCRIPTION OF THE CAMERA .............4 SETTING THE CAMERA FOR THE FIRST TIME ........5 ..................5 TTACH THE WRIST STRAP ....................5... -
Page 6: Introduction
Introduction This instruction manual is for users of the TRUST 742AV USB2.0 LCD POWER VIDEO. The TRUST 742AV USB2.0 LCD POWER VIDEO can be used to take photographs, to record live video images, to record voice memos, to play MP3 files or as a web cam for video- conferencing on the Internet. -
Page 7: Safety
General information Carefully read the following instructions before use. • The TRUST 742AV USB2.0 LCD POWER VIDEO does not require any special maintenance. Use a slightly damp, soft cloth to clean the camera. • Do not use aggressive substances, such as white spirit, to clean the device. -
Page 8: Description Of The Camera
742AV USB2.0 LCD POWER VIDEO This device meets the essential requirements and other relevant conditions of the applicable European directives. The Declaration of Conformity (DoC) is available at www.trust.com/13929/ce. Description of the camera Use table 1 in combination with figure 1. -
Page 9: Setting The Camera For The First Time
742AV USB2.0 LCD POWER VIDEO Item Description Function A/V out connector Connector for A/V cable (see chapter 10.5) Earphone connector Connector for earphone USB connector Connector for USB cable Strap hook (2) Attach wrist strap here (see chapter 5.1) When playing a video clip or audio file the Speaker sound can be heard from this part. -
Page 10: Using The Camera
742AV USB2.0 LCD POWER VIDEO Select ‘Time’ and press OK-button (5, fig. 1). Time/Date settings will appear. Use the direction buttons (4, fig. 1) to set the date/time: - Up = Decrease 1 value - Down = Increase 1 value... -
Page 11: Install Driver (Windows)
742AV USB2.0 LCD POWER VIDEO Still image: Zoom out Down Left Go to previous still-image / video-clip Right Go to next still-image / video-clip Table 2: Functions full-screen review Press ‘Index’-button (6, fig. 1) to switch to thumbnail mode. 6.2.2 Thumbnail review The thumbnail review gives an overview of max. -
Page 12: Copy Mp3 Files To Your Camera
742AV USB2.0 LCD POWER VIDEO Note: Make a backup of the files before using Windows Explorer in Windows XP. This program may alter your photographs and this cannot be undone. 8.2.2 Make sure your computer is turned on. Connect the camera to your MAC. -
Page 13: Video Studio 7
742AV USB2.0 LCD POWER VIDEO photographs and save them on your computer. Follow the instructions below to install Photo Explorer 8.0 SE: Start the Trust Software Installer. Select ‘Install Software’. Select ‘Ulead Photo Explorer 8.0 SE’. Select the language you wish to use. -
Page 14: Menu Button
742AV USB2.0 LCD POWER VIDEO See table 3 for the basic functions in MP3 mode. Use this table with fig. 10 Item Function Play / Pause button Volume up Next file / Fast wind (during playing) Volume down OK / Menu button (for menu options see chapter 10.2.4) - Page 15 742AV USB2.0 LCD POWER VIDEO Adjusts the exposure compensation: +1.5 +1.2 +0.9 +0.6 +0.3 Exposure 0.0 * - 0.3 - 0.6 - 0.9 - 1.2 - 1.5 Add special effect when recording video-clip: - Normal (No effect) * Effect - B / W (Black & White) - Classic (Sepia toned;...
-
Page 16: Settings Mode
742AV USB2.0 LCD POWER VIDEO Adjusts the exposure compensation: +1.5 +1.2 +0.9 +0.6 +0.3 Exposure 0.0 * - 0.3 - 0.6 - 0.9 - 1.2 - 1.5 Add special effect when making a photograph: - Normal (No effect) * Effect - B / W (Black &... -
Page 17: Macro Select Dial
742AV USB2.0 LCD POWER VIDEO Set the flicker-setting: Flicker 50 Hz (Europe) * 60 Hz (America) Set the setting of your TV system: TV System PAL (Europe) * NTSC (America) Set the language of the camera: - English * - German... -
Page 18: Using Flash Strobe (Still-Image Mode)
742AV USB2.0 LCD POWER VIDEO - Centre, see fig. 8 (Camera will measure the lighting condition within the central area) - Centre low, see fig. 9 (Camera will focus the metering on the centre-low area) 10.6 Using flash strobe (Still-image mode) If the light is not sufficient for picture-taking, you can use the flash strobe. -
Page 19: Install Trust Photo Site
There are a number of conditions attached to the use of this site. The conditions can be found at www.trustphotosite.com. This software can be used to upload your photographs to the Trust Photo Site. Note: The latest version of the Trust Photo Upload software can always be downloaded from the Trust website. -
Page 20: Using Trust Photo Upload Software
742AV USB2.0 LCD POWER VIDEO 11.3 Using Trust photo upload software Start Trust Photo Upload from the Windows Start menu (Start – Programs – Trust – Trust Photo Upload). Use the ‘Explorer’ to select the photographs you wish to upload. You can use the buttons on the right-hand side of the Explorer to select photographs, unselect photographs, view photographs, etc. -
Page 21: Troubleshooting
742AV(Still) 742AV(Video) USB Audio device Start – Settings – Control panel – Add or Remove Programs Trust 742AV USB2.0 LCD Power Video Trust Photo Upload Ulead Photo Explorer 8.0, Ulead Photo Express 4.0, Ulead Video Studio 7. Note: The information given above will vary when the installation has been altered by the user (for example, not everything has been installed or locations other than the default locations have been selected). -
Page 22: Removing Camera Driver
Removing camera driver To remove the camera driver from your computer do the following steps: Select START -> Programs -> Trust -> 742AV USB2.0 LCD POWER VIDEO - > Uninstall 742AV USB2.0 LCD POWER VIDEO Following the instructions on the screen. - Page 23 742AV USB2.0 LCD POWER VIDEO Problem Cause Possible solution The camera is still Disconnect the USB cable. The connected to your camera cannot be operated when it computer. is connected to a computer. The camera is turned Turn the camera on.
- Page 24 742AV USB2.0 LCD POWER VIDEO Problem Cause Possible solution The paper used is Use original paper from your printer unsuitable for printing manufacturer for the most reliable photographs. result. There is insufficient Improve the lighting or select a The video light.
-
Page 25: Warranty Conditions
Trouble- shooter. If you still have problems after trying these solutions, please contact one of the Trust Customer Care Centres. You can find more information at the back of this instruction manual. Please have the following information available: •... - Page 26 SERVICE CENTRE 24 HOURS free service: www.trust.com Residents in the UK and Ireland should contact: UK Office Mon - Fri Phone +44-(0)845-6090036 From 8:00 - 16:00 +31-(0)78-6543299 I residenti in Italia possono contattare: lun - ven Ufficio italiano 9:00 – 17:00...
