Trust 350FT Instruction Manual

Powercam flash
Hide thumbs
Table of Contents

Advertisement

Quick Links

TRUST 350FT POWERC@M FLASH
UK
UK
TRUST 350FT POWERC@M FLASH
Instruction manual
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 350FT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trust 350FT

Summary of Contents for Trust 350FT

  • Page 1 TRUST 350FT POWERC@M FLASH TRUST 350FT POWERC@M FLASH Instruction manual Version 1.0...

  • Page 2: Thank You

    TRUST 350FT POWERC@M FLASH Thank you Thank you very much for purchasing this product from the Trust range. We wish you hours of fun with it. Please read this manual carefully before using the product. Registration Register your purchase via our Internet site at www.trust.com...

  • Page 3: Table Of Contents

    TRUST 350FT POWERC@M FLASH Contents Introduction ............................. 3 Conventions used in the manual.................... 3 Contents of the box........................3 Minimum system requirements ....................3 Safety..............................4 General information ......................... 4 Batteries ............................ 4 Camera Memory ........................4 Inserting the batteries........................5 Camera functions ..........................
  • Page 4 TRUST 350FT POWERC@M FLASH 11. Troubleshooting..........................26 12. Specifications ..........................28 13. Trust Customer Care Centers ...................... 29...

  • Page 5: Introduction

    This instruction manual is for users of the Trust 350FT PowerC@m Flash. Basic knowledge of computers is necessary to be able to install this product. Please consult one of the Trust Customer Care Centers if you have any problems. The last page of this electronic instruction manual, as well as the back of the printed, quick installation manual, contains more information about these Customer Care Centers.

  • Page 6: Safety

    General information Carefully read the following instructions before use. The Trust 350FT PowerC@m Flash does not require any special maintenance. Use a slightly damp, soft cloth to clean the camera. Do not use aggressive substances, such as petrol or white spirit, to clean the device. These may harm the material.

  • Page 7: Inserting The Batteries

    Note: The camera will make a noise when the battery voltage becomes too low. 3. Close the battery flap again by gently pushing it and sliding it upwards. 4. The Trust 350FT PowerC@m Flash is now ready for use.

  • Page 8: Camera Functions

    TRUST 350FT POWERC@M FLASH 4. Camera functions Figure 2: Camera functions Function Description Exposure button Takes a photograph. Mode button Changes the camera mode. Flash Gives extra lighting. LED for the automatic exposure Flashes when a recording is made using the automatic exposure function.

  • Page 9: Lcd Screen

    TRUST 350FT POWERC@M FLASH LCD screen Figure 3: Explanation of the LCD screen Function Description Counter Indicates how many photographs have been taken. Continuous mode Appears when the camera is set to the continuous mode (film recording). This only works in the CIF (320 x 240) resolution.

  • Page 10: Using The Camera

    5. Using the camera Setting the resolution The Trust 350FT PowerC@m Flash can take photographs in two different resolutions, i.e. VGA (640 x 480, approx. 60 photographs) and CIF (320 x 240, approx. 190 photographs). The camera’s default setting is the VGA (640 x 480) resolution, which can be used to take approximately 60 photographs.

  • Page 11: Setting The Macro Button

    TRUST 350FT POWERC@M FLASH Setting the Macro button The Trust 350FT PowerC@m Flash has a Macro function which is set by sliding the MACRO button (10) upwards or downwards. The functions are described in the table below. Standard mode (90 cm to infinity).

  • Page 12: Automatic Exposure

    Note: The video function only works in the low (CIF) resolution. The TRUST 350FT POWERC@M can be used to take a number of photographs, one after another, using the CONTINUOUS mode. 1. Turn the camera on by pressing the ON/OFF button (7). A beep will be heard when the camera is turned 2.

  • Page 13: Deleting The Last Recording

    This camera only works with this driver on a system using Windows 98 or later versions. This camera does not work on an Apple Mac with OS 8, 9 and Mac OSX. Note: The latest driver can be downloaded from www.trust.com/11336. Check whether a new driver is available and use this for the installation. Note: Make sure all other programs are closed during the installation.

  • Page 14: Trust Software Installer

    TRUST 350FT POWERC@M FLASH Trust Software Installer 1. Insert the CD-ROM into your CD-ROM drive. The Trust Software Installer will start automatically. If the installation program does not start automatically, start 'Setup.exe' on the CD-ROM. Figure 4 will appear. The Trust Software Installer will appear in Windows 98, Windows ME, Windows 2000 and Windows XP.

  • Page 15: Installing The Software

    Figure 7: Installation in Windows 98 / Windows ME / Windows 2000 / Windows XP 4. Select the option to restart your computer and click on 'Finish'. Start the Trust Software Installer again (see figure 4) so that you can install the other software. See chapter 7 for instructions on how to install the other software.
  • Page 16 TRUST 350FT POWERC@M FLASH Figure 9: Installing Photo Fantasy 2000 3. Click on 'Yes' to accept the license agreement and continue with the installation. Figure 10 will appear. Figure 10: Installing Photo Fantasy 2000 4. Click on 'Next’ to continue. Figure 11 will appear.

  • Page 17: Connecting And Checking

    ‘Start – Settings – Control Panel’. Double-click on the ‘System’ icon and select the ‘Device Manager’ tab. - Imaging Device – Trust 350FT PowerC@m Flash(Still camera) Trust 350FT PowerC@m Flash(video camera) ‘Start – Settings – Control Panel’ and then double-click on the ‘Add/Remove Programs’ icon.

  • Page 18: Using The Software And Downloading Recordings

    TRUST 350FT POWERC@M FLASH Start - Programs - Trust - … - 350FT PowerC@m Flash – AVI Maker – Uninstall 350FT PowerC@m Flash Note: The information given below will vary when the installation has been altered by the user (for example, not everything has been installed or locations other than the default locations have been selected).
  • Page 19 5. Here, you will see a number of example photographs which you can insert. To insert photographs from the camera’s memory, click on ‘Acquire’ (E). Figure 17 will appear. Figure 17: Selecting a camera 6. Select ‘350FT PowerC@m Flash’ and click on ‘Select’. Figure 18 will appear.
  • Page 20 TRUST 350FT POWERC@M FLASH Figure 18: Loading photographs 7. Select the photograph that you wish to use by double clicking on it. Figure 19 will appear. Figure 19: Loading photographs 8. The selected photograph will now be visible in the row of ‘Sample Photos’ (see figure 16).

  • Page 21: Photo Impression 2000

    TRUST 350FT POWERC@M FLASH Mirrors the inserted photograph. G Moves the photograph (left, right, up, down). Increases or reduces the size of the photograph. Rotates the photograph clockwise or anticlockwise. Adds text. Zooms in or out. Colour settings (only works for coloured subjects).
  • Page 22 Video function For recording live video images. Table 6: Photo Impression 2000 functions 3. Select ‘350FT PowerC@m Flash’ for B (see figure 22). 4. Click on the Camera/Scanner icon (D). The TWAIN window will now be opened (see figure 23).
  • Page 23 TRUST 350FT POWERC@M FLASH Figure 23: TWAIN window We have made two recordings in this example: VGA (640 x 480) and CIF (324 x 240). When you wish to have a better view of a picture, you only need to move the mouse cursor over the picture and the picture will be enlarged.

  • Page 24: Loading Photographs In A Higher Resolution (Picture Resolution)

    This function only works if the recording has been made in a hardware resolution of 640 x 480 (VGA). Video Impression 1.6 Video Impression 1.6 can be used to make video recordings with your TRUST 350FT POWERC@M FLASH. Note: This function only works if the camera has been connected to your PC using the USB cable provided with the camera.
  • Page 25 TRUST 350FT POWERC@M FLASH Figure 26: Video Impression 1.6 2. Click on the ‘New’ icon (A). Figure 27 will appear. Figure 27: Video Impression 1.6 3. Click on the ‘acquire’ icon (B). Figure 28 will appear.
  • Page 26 TRUST 350FT POWERC@M FLASH Figure 28: Video Impression 1.6 4. Select ‘Trust 350FT PowerC@m Flash’ for C. 5. Click on button D to view the camera’s settings. Figure 29 will appear. Figure 29: Camera settings 6. For ‘Color Space / Compression:’, select the RGB 24 format.

  • Page 27: Photo Montage 2000

    The Help function contains information concerning all the program’s functions. 10. Maintenance Use a dry, soft cloth to clean the Trust 350FT PowerC@m Flash. NEVER use a cleaning agent. This will cause irreparable damage to the camera. Clean the lens using a dry cotton bud.

  • Page 28: Troubleshooting

    TRUST 350FT POWERC@M FLASH 11. Troubleshooting Method 1. Read the solutions given below. 2. Check for up-to-date FAQ’s, drivers and instruction manuals on the Internet www.trust.com/13136 Problem Cause Possible solution The computer's USB Try a different USB port or connect Windows does not detect a port does not work.
  • Page 29 Trust products. You will also have the chance of winning some spectacular prizes. If you still have problems after trying these solutions, please contact one of the Trust Customer Care Centers. The last page of this electronic instruction manual, as well as the back of the printed quick installation manual, contains more information.

  • Page 30: Specifications

    TRUST 350FT POWERC@M FLASH 12. Specifications Sensor type CMOS Recording element (CMOS) Lens f = 8.0 mm, F 2.4 Shutter speed 1/15 - 1/10,000 second Focus Fixed (0.9 m to infinity) Hardware resolution High: VGA 640 x 480 (300K) Low: CIF 320 x 240 Picture resolution 1280 x 960 (1.3 Mpix)

  • Page 31: Trust Customer Care Centers

    TRUST 350FT POWERC@M FLASH 13. Trust Customer Care Centers 24 Hours free support: WWW.TRUST.COM Residents in the UK and Ireland should contact: UK Office Mon - Fri Phone +44-(0)0845-6090036 From 8:00 - 16:00 +31-(0)78-6543299 I residenti in Italia possono contattare:...
