Page 1: User Manual
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) DS-8100HMI-B Embedded Mobile Net DVR User Manual (V1.0) - 1 -... - Page 2 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Statement Please kindly note and understand that there may be misprints and technically inaccurate description. The contents of this manual are subject to change without notice from time to time accompanying with the release of new version.
-
Page 3: Table Of Contents
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Production Description ......................................6 Overview ........................................6 Key Functions ......................................6 Installation help ........................................9 Check device and accessories ..................................9 SATA Installation ......................................9 SIM/UIM card installation ..................................11 Rear Panel Interface Description ................................12 KEY Ignition Switch Connection ................................ - Page 4 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Parameters Setup Guide ..................................... 32 Basic Setting ......................................32 5.1.1 Administrator and Password ................................. 32 5.1.2 Add and Delete User ..................................33 5.1.3 Unit Name and Device ID ................................34 Local Preview Setup ....................................35 5.2.1 Video output standard ...................................
- Page 5 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 5.8.2 GPS Setup ....................................... 49 5.8.3 Server Login Setup ..................................50 Utilities ..........................................51 Save Parameters ....................................... 51 Restore Parameters ....................................51 Upgrade ........................................52 Hard Disk Management .................................... 52 Clear Alarm Out ......................................53 Reboot ........................................
-
Page 6: Production Description
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 1 Production Description Overview Embedded digital net recorder DS-8100HM-B, which is an excellent product designed for vehicle surveillance. It combines the latest technology from fields of IT, mechanism and electronics, such as, video and audio compression & decompression, recording of high capacity hard disk, hard disk vibration- proof and bracing technology, TCP/IP, GPS, wireless, etc. - Page 7 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) · 1-ch AIN, 16kps OggVorbis standard real-time compression; · Choice of synchronously mixed video & audio and single video; · Support dual-stream, local storage and wireless network transmission can be set separately;...
- Page 8 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) · TCP/IP based; · Wireless comfortable compression technology; · Software for alarms e.g. switch triggered, abnormity and GPS; · Screen capture at client software; · Track tracing and video playback at client side;...
-
Page 9: Installation Help
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 2 Installation help 2.1 Check device and accessories Please check carefully according to the list inside once you get it. 2.2 SATA Installation Note: Please make sure the operation is under power off. - Page 10 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 5. Please wear antistatic gloves. 6. Put in the second HD on the 4. Upward Push out the HD Carefully put in the first HD on the bracket (PCB face down), aim at...
-
Page 11: Sim/Uim Card Installation
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Note: 1. Tips for HD purchase: please choose recommended high-quality HD from creditable provider, that should be comfortable for longtime and frequent read & write; 2. HD should be formatted after the installation, or there may be HD error with alarm. Format method please refer to section 6.4 ;... -
Page 12: Rear Panel Interface Description
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 1. Reverse the device, loosen 2. Carefully overturn the board 3. Unplug the pop-up slot, insert 4. Insert the SIM/UIM card back the screws of the wireless with wireless module, use your... -
Page 13: Key Ignition Switch Connection
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Interface Physical Name Description Connect the power input (Note: If the vehicle battery connected, please access DC IN Power Input a fuse in the battery anode). Ignition Switch Connect to ignition switch or battery (Please refer to 2.4) Wire Remote Connect to wire remote control. - Page 14 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 2. Please make sure that the positive pole of DVR power line connects the positive pole of vehicle batteries with the fuse. 1. Key interface connected to the vehicle ignition switch for DVR function of vehicle ignition startup and time-delay shutdown. There...
- Page 15 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Connect the “DC IN +” of DVR to the positive pole of vehicle batteries; Connect the “KEY +” of DVR to the vehicle ignition switch; Connect the “GND” and “KEY -” of DVR to the negative pole of vehicle batteries.
-
Page 16: Alarm Output Connection Guide
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 2.6 Alarm Output Connection Guide Typical Sample Mobile DVR Alarm Out AC Load Alarm Out DC Load JQC-3FG Output Relay (n)A (n)A (10A 250VAC) 12V DC ～220V AC (n)B Power (n)B... -
Page 17: Operation Guide
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 3 Operation Guide 3.1 Front Panel Description DS-8100HM-B Front Panel Description (The descriptions are subject to the physical product.) Fig.3.1 DS-8100HM-B LED Indicator Description: IR: IR Control receiver, please make sure the lamp is unblocked by any object. -
Page 18: Ir Control
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Other interfaces description: DS-8100HM-B HD Socket:On the front panel(HDD-LOCK),insert and pull HD bracket from here. Each side of the HD bracket has a bolt for manual fastening the HD bracket; HDD-LOCK:”HDD-LOCK”, when the groove of the lock core is upward means the HD is locked, if the groove is leftward means the HD bracket is opened Note: When insert HDDs, firstly, please fasten the bolts, then lock the HDD-LOCK, otherwise the HDDs will not work. - Page 19 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) PREV Multi-screen switch; Direction Up [], Down [], Left [], Right []: Keys 1. In menu mode, moving the activity frame by press [] & [], and selecting the data items by press [] &...
-
Page 20: Menu Description
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 3.3 Menu Description 3.3.1 Menu items Item Option Item Option Item Option Unit Name Select Camera Device ID Name & Position Require Password Brightness, Contrast, Hue, If HD full Overwrite /Stop Recording... -
Page 21: Menu Operations
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Copy to Camera Save Parameters Restore Parameters Upgrade Add & Del User Boot & Halt Hard Disk User Password & Verify Mobile GPS settings Utilities Stop Alarm Out Default & Set Right... - Page 22 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Fig 3.3 Fig 3.4 There is a rectangular box in the main menu interface, which is referred to as “Activity Frame”, you can move it from one icon to another by pressing [ ] or [ ] on the IR control.
-
Page 23: Input Method
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) iv. Press [ENTER] or [ESC] to exit edit. d) Button: Execute a special function or enter into next sub-menu. For example, press “Policy” button to enter into sub-menu. Press [Confirm] to save parameters and return to parent menu. -
Page 24: Basic Operation Guide
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 4 Basic Operation Guide Note: The user must have the appropriate rights for basic operations described in this chapter. The following Fig.4.1.are login prompt boxes: In this box, you can use [ ] and [ ] to select one username, then press [ ]to move to password. After entering the password, please press [ENTER] to exit the password box and press confirm to enter the menu. -
Page 25: Preview
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 4.2 Preview The preview interface will show up after the device started up. The date, time, and channel name can be seen in the preview interface, if you want to reset them, please refer to the section 5.2.3 OSD Setup. There are recording and alarm status of each channel displayed at the bottom of the screen. - Page 26 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) their user rights. Modify password for the users created by admin: For example, a user named “user” (The method of adding and deleting user please refer to section 5.1.2),please modify the password as follow: Step 1: Enter the main menu and select “User”...
-
Page 27: Ptz Control
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 4.4 PTZ Control Note: The user must have the “PTZ Control” right. Under the main menu mode, press the “PTZ” to enter the PTZ control interface. PTZ control keys description: Direction control keys:[ ],[ ],[ ],[ ];... -
Page 28: Playback
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Exit manual record: Press[ESC] key to exit manual record and enter preview mode. Press[MENU]key to enter main menu. Press[Play]key to enter into playback menu. Press[PTZ]key to enter PTZ control mode. 4.6 Playback Note: The user must have “Playback”... -
Page 29: Backup Recorded Files
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) In the playback interface, you can set search channels, record type, time section, and select “Search” button. DVR will search and list the matched files. (Fig.4.6) If the matched files are more than8, you can use “Page No.” to select page. In the file list box, use [ ], [ ]keys to move the scroll bar to the file, press [ENTER]key to playback the file. - Page 30 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Please enter the layback interface to apply the backup operation. (Fig.4.9) There are two methods of backup: 1. Backup the selected recorded files. In the playback interface, search the matched files, move “Active Frame” and press [Edit]key to select the files .
- Page 31 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) You can use our file player software to playback the backup files in PC. You can find the player software in attached CD. The files can be searched by their names, for example, if a file with name “ch01-200808071029.mp4”, that means this file is the record video of channel 1, the beginning time is...
-
Page 32: Parameters Setup Guide
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 5 Parameters Setup Guide Note: only the users have “Parameters Setup” right can set the parameters. You must reboot the DVR to make the new parameters take into effective, when the following parameters are modified and saved. (Fig.5.1) Other parameters do not need to reboot. -
Page 33: Add And Delete User
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Step 3: Use [ ],[ ]key to move “Active Frame” to password edit box, input the new password. Move “Active Frame” to “Verify password” edit box, input the verify password. Then choose the “Confirm” button, the password will be saved and taken into effective. -
Page 34: Unit Name And Device Id
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) “Remote Rights”: Remote rights define the rights of operating by IE or Client Server. PTZ control: Remote control PTZ; Record: Remote manual start/stop recording; Parameters setup: Remote setup the DVR parameters;... -
Page 35: Local Preview Setup
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Unit name is the name of DVR; it can be modified according to the requirement of monitoring. For example, it can be named as the car license number to facilitate the search of backup files. -
Page 36: Video Parameters Setup
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) In “Display” menu, you can setup DVR system date and time.(Fig.5.6) In “Image Setup” menu (Fig.5.7), you can setup time display position in the image. Move “Active Frame” to “Position” button on the right side of “OSD” and enter setup image, you can use[ ],[ ],[ ],[ ]keys to move the OSD position. -
Page 37: Preview Properties
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) NTSC). Firstly, move the yellow pane to your hope position and press[EDIT]key, the yellow pane will be turned into red, then you can use[ ]to expand downward ,[ ]to shrink upward,[ ]to expand rightward,[ ]to shrink leftward. After you make sure the red mask area, press[EDIT]key to save the mask area. The area will be blacked in the preview image.(Fig.5.9) Press[ESC]key to cancel the mask area. -
Page 38: Alarm Setup
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Switch time: That is image preview switch time. You can use [ ] or [ ]keys to select switch time. There are many options, including “5 Seconds”, “10 Seconds”,”20 Seconds”, “30 Seconds”, “1 Minutes”, “5 Minutes”... - Page 39 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) External alarm input setup: Select one alarm input from 1,2,3,4, and then choose an alarm type from “Normal Open” and “Normal Close” according to the sensor type. External alarm input setup includes alarm in handling and alarm in schedule. Alarm in handling includes record camera, PTZ linkage, trigger alarm out, etc.
-
Page 40: Motion Detection Alarm
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) In “Handle Method”, you can also setup “Audible warning”, “Upload to Center” and “Trigger Alarm Out”. The alarm in schedule is in “Alarm In Handling” menu. Note: The schedule is settled by day, you can copy this to the other days. - Page 41 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) You can use [PTZ] key to set the whole screen as motion area, and multi motion areas can be defined. Press [A]key to clear all motion areas. The minimum area is one panel. After you setup the areas, press [ENTER] key to return “Image Setup”...
-
Page 42: Video Loss Alarm
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 5.3.3 Video Loss Alarm When the video cable or camera has something wrong, the video image is lost. If you enable video loss alarm, in such case, DVR will make alarm. -
Page 43: Recording Parameters Description
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) are all full, DVR will handle it as “Hard Disk Full” exception, please refer to chapter 5.17 for exception menu. 5.4.1 Recording parameters description Stream Type: There are two options, one is “Audio & Video” stream and other is “Video” stream only. If you want to record video and audio, please select ... -
Page 44: Network Parameters
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) All Day, Rec. Type: If you need to record 24 hours, you can enable “All Day” option and select a record type. Period: If you do not need record all day or you need to record different types in different ... -
Page 45: Ptz
RS-485 parameters: Including baud rate, data bit, stop bit, parity flow control, etc. These parameters must be the same as those of PTZ Protocol. PTZ parameters: The PTZ protocol of DVR includes Hikvision, Pelco-p,Pelco-D,SAE/YAAN,Samsung,Howell,Panasonic,Philips, etc. The PTZ address in this ... - Page 46 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Fig.5.21 Fig.5.22 The parameters of adding cruise point are: Cruise No: 1 to 16; Preset: 1 to 128, please ensure the preset point has already been defined. Dwell Time: the dwell time on the preset point;...
-
Page 47: Exceptions
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Fig.5.23 Fig.5.24 5.7 Exceptions The exceptions can be handled include: hard disk full, hard disk error, illegal access, IP address conflict, network failure , NTSC/PAL differ and speed limit, etc. The parameters can be set in “Exceptions”... -
Page 48: Mobile Setup
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) You can select more than one handle methods. For example, if you choose exception type as “Hard Disk Error”, you can select “Audible Warning” and “Upload to Center”. When the disk has an error, the DVR will warning and the center host PC will receive a warning message. -
Page 49: Gps Setup
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) the setup time. Auto Work: “√”means start the auto work function. Press[EDIT]to switch. Date: the auto work setup is set by day; you can copy the schedule to the other days. -
Page 50: Server Login Setup
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Display Channel: You can set whether the GPS information display on each channel. ““means the selected channel will display the GPS information including the latitude, longitude, speed of the vehicle.(Please refer to section 4.2) 5.8.3 Server Login Setup... -
Page 51: Utilities
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 6 Utilities The “Utilities” menu is used for day-to-day management and maintenance of DVR. Including “SavePara” ,”RestorePara” ,”Upgrade” ,”Hard Disk”, “Stop Alarm Out”, “Reboot” ,”Power Off” ,”View Log” and “System Info”. The “Utilities” menu is shown in Fig.6.1. -
Page 52: Upgrade
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 6.3 Upgrade You can use this function to upgrade the firmware. Please confirm the language is matched. Press “Upgrade” icon, in the pop-up dialog, you can select either “FTP” or “USB” upgrade mode. -
Page 53: Clear Alarm Out
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) 6.5 Clear Alarm Out Clear the alarm output manually. 6.6 Reboot Reboot DVR 6.7 Power Off Not available for mobile DVR. 6.8 View Log After enter into the “LOG” menu, you can check the log(Fig.6.7) Press[ ]key on the front panel to view all the log, this will list the earliest 2000 record log. -
Page 54: System Information
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) get Status, Net Alert On, Net Alert Off, Net Reboot, BiComStart(Start Voice Talk), BiCom Stop(Stop Voice Talk), Net Upgrade, Net File Play, Net Time Play, Net PTZ and so on. For alarm major type, the minor type includes: External Alarm In, External Alarm Out, Motion Detect Start, Motion Detect Stop, View Tamper Start, View Tamper Stop and so on. -
Page 55: Appendix A Hdd Capacity Calculation
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for every hour, unit Mbyte. - Page 56 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) ∑ ×a% In the formula: a% － Alarm occurrence rate For example: According to the above formula, if the bit rate type is FIXED, for different bit rate, the file size of ONE channel in ONE hour is:...
-
Page 57: Appendix B Ethernet Connect Cable Made Method
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Appendix B ETHERNET Connect Cable Made Method Material and tool: One twist cable (8 pin, the length can be defined as to the actual demand, but must be within 100m), 2 standard RJ45 head, one tool for RJ45. -
Page 58: Appendix C Specifications
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Appendix C Specifications Model DS-8100HM-B Operating System Embedded RTOS Video Compression Standard H.264 Preview Resolution PAL:704×576(4CIF);NTSC:704×480(4CIF) Playback Resolution 4CIF(6fps)/DCIF(12fps)/2CIF(15fps)/CIF(fps)/QCIF(fps) Video Input 4-ch BNC(1.0Vp-p,75Ω),PAL/NTSC adaptive Video Output 2-ch BNC(1.0Vp-p,75Ω),PAL/NTSC optional Frame Rate PAL:1/16—25fps;NTSC:1/16—30fps... - Page 59 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Power Consumption ≤6W Operating Temperature -10℃～+55℃ Humidity 10％～95％ Dimensions 236mm×73mm×210mm Weight About 3Kg Device Control Special IR control for mobile DVR - 59 -...
-
Page 60: Appendix D Faq
User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) Appendix D FAQ Q: why a new machine has “di-di-di-di” voice warning after boot? A: Reason1: there is no HDD in DVR Reason2: the HDD is not initialized Reason3: the HDD lock of DS-8100HM-B is unlocked Reason4: HDD is broken If do not need the HDD, please go to the exception settings menu, disable the voice warning of “HDD error”... - Page 61 User Manual of DS-8100HMI-B Series Mobile Net DVR (V1.0) A: Please check the corresponding setup as the order: 1. Check the connection of RS-485 and the power connection of G-mouse module; 2. Check if the GPS interface of DVR is enabled? 3.
