About The Flat Panel Monitor - Silicon Graphics 1600SW Owner's Manual

5. Remove the box containing the AC adapter from the foam
packing, and remove the AC adapter from the box.
Also note the 3 mm hex wrench included with the shipment.
Use this tool if you wish to remove the monitor from its
pedestal, for example to place the monitor on a mounting
arm or wall mount.
You are finished unpacking the flat panel monitor. The next sections
describe the flat panel monitor and how to set it up.

About the Flat Panel Monitor

You may want to take a moment to familiarize yourself with the
monitor's features, as shown in Figure 1-1.
Power button
LED
Figure 1-1 Front and Rear Views of the Flat Panel Monitor.
Setting Up and Using the Flat Panel Monitor EN-3
Power
connector
Sensor
port
3 mm hex
screws
Interface
cable
Clip
Connects to
the computer
