Installation
Installation
Guide
2-Port USB Dual-Link DVI-D Cable KVM Switch
with Audio and Microphone Support
GCS982U
PART NO. M1196

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GCS982U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for IOGear GCS982U

  • Page 1 Installation Installation Guide 2-Port USB Dual-Link DVI-D Cable KVM Switch with Audio and Microphone Support GCS982U PART NO. M1196...
  • Page 3: Table Of Contents

    Table of Contents Package Contents Firmware Upgrade System Requirements Upgrade Fail Overview Federal Communications Commission (FCC) Statement Standard Installation CE Compliance Advanced Installation SJ/T 11364-2006 LED Indication Limited Warranty Port Switching Contact Hotkeys Summary Table Autoscan Interval Table Mac Keyboard Emulation Sun Keyboard Emulation Factory Default Settings...
  • Page 4: Package Contents

    Package Contents • 1 x 2-Port USB Dual-Link DVI-D Cable KVM Switch • 1 x Remote Switch Button • 1 x Installation Guide • 1 x Warranty Card...
  • Page 5: System Requirements

    System Requirements Console • DVI-D supported monitor • USB keyboard and mouse • Powered speakers and microphone (optional) Computers • Two USB ports • A DVI-D supported connection • 3.5mm audio and microphone connections (optional) Operating System • Windows XP • Windows Vista (32-bit / 64-bit) • Windows 7 (32-bit / 64-bit) • Mac OS X or greater...
  • Page 6: Overview

    Overview 1. LEDs 9. CPUs USB Keyboard connection 2. Console DVI-D Video Port 10. CPUs USB Mouse connection 3. Console USB Mouse Port 11. CPUs DVI-D connection 4. Console USB Keyboard Port 12. CPUs Audio connection 5. Console Mic. Port 13.
  • Page 7: Standard Installation

    Standard Installation Step 1 Step 3 Please make sure your computers and monitor Connect your USB keyboard and mouse to the are powered off before you start. console USB keyboard port and console USB mouse port. If you would like to use the remote Step2 switch button, please connect it to the remote Connect the DVI cable from your monitor to...
  • Page 8 Step 4 Step 5 Connect your powered speaker and mic. to the Connect a set of your molded KVM cable to each of console audio port and console mic. port. your computers – DVI cable to the DVI output, USB cables to open USB ports from your computer, audio cable to your audio output and mic.
  • Page 9: Advanced Installation

    Advanced Installation Step 1 Step 3 Please make sure your computers and monitor are Connect your USB keyboard to the console USB powered off before you start. keyboard port. If you would like to use the remote switch button, please connect it to the remote Step2 switch button port.
  • Page 10 Step 4 Step 5 Connect a powered USB hub to the console mouse Connect your powered speaker and mic. to the port, then connect the mouse to any available USB console audio port and console mic. port. port in the hub. Then, connect any peripherals that you want to share between your computers to the other available USB ports in the hub.
  • Page 11 Step 6 Final Step Connect a set of your molded KVM cable to each of Turn on your computers. your computers – DVI cable to the DVI output, USB cables to open USB ports from your computer, audio cable to your audio output and mic. cable to the mic.
  • Page 12: Led Indication

    LED Indication LED Indication - LED will light up in Green showing the port that can be controlled by the console. - Both LEDs will be flashing together when the KVM is in Firmware Upgrade Mode.
  • Page 13: Port Switching

    Port Switching You can switch ports via remote switch button, Port Switching via Hotkey Commands mouse or hotkey commands. To trigger a Hotkey Mode, simply press [Scroll Lock] [Scroll Lock]**. Please refer to Hotkey Sum- mary Table for details. Port Switching via Remote Switch Button Simply press the remote switch button once to switch focus to the next port.
  • Page 14: Hotkeys Summary Table

    Hotkeys Summary Table Hotkey combination Description [Enter] Switch KVM and audio focus to the next port [k] [Enter] Switch KVM focus to the next port [s] [Enter] Switch audio focus to the next port Activate Autoscan Mode. It will toggle between the two computers every [a] [Enter] 5 seconds [Scroll Lock] [Scroll Lock] +...
  • Page 15 Hotkey combination Description List out current settings [F4] [Enter] Note: Please have a Notepad or word document opened before you trigger this function. [Scroll Lock] [Scroll Lock] + [F5] [Enter] Perform a USB keyboard and mouse reset [F10] [Enter] Auto detect keyboard operating system [r] [Enter] Reset to factory default settings [Ctrl] [Ctrl]* +...
  • Page 16: Autoscan Interval Table

    Autoscan Interval Table Description 3 seconds 5 seconds (default) 10 seconds 20 seconds...
  • Page 17: Mac Keyboard Emulation

    Mac Keyboard Emulation The PC compatible (101/104 key) keyboard can emulate the functions of the Mac keyboard. The emulation mappings are listed in the table below. [Alt] PC Keyboard Mac Keyboard [Shift] Shift [Print Screen] [Scroll Lock] [Crtl] Ctrl  [Ctrl] [1] [Enter] Return...
  • Page 18: Sun Keyboard Emulation

    Sun Keyboard Emulation The PC compatible (101/104 key) keyboard can emulate the functions of the Sun keyboard. The emulation mappings are listed in the table below. [Ctrl] [F9] Find PC Keyboard Sun Keyboard [Crtl] [F10] [Crtl] [t] Stop [Crtl] [F2] Again [Crtl] [1] [Crtl] [2]...
  • Page 19: Factory Default Settings

    Factory Default Settings Function Default Setting Autoscan Interval 5 seconds Hotkeys [Scroll Lock] [ Scroll Lock] Keyboard Operating Platform PC compatible Mouse Emulation Mouse Port-Switching Keyboard Emulation On (Gaming mode: Off) Power on Detection Enable Keyboard Language US English...
  • Page 20: Firmware Upgrade

    When you see Step 1 the 2 LEDs are flashing on the KVM, you can now Go to www.iogear.com to download the latest release the remote switch button. available firmware or the specific firmware that you wish to upgrade to.
  • Page 21 Step 4 Step 5 Windows will now install all the required drivers. After you see the below message “Your new You may see the below message in the system tray hardware is installed and ready to use.”, extract icon area. the downloaded file with WinRAR or compatible software.
  • Page 22 Step 6 Step 7 Read the License Agreement and click “I Agree” Choose the correct KVM that you wish to perform then click “Next” if you wish to continue with the firmware upgrade from the “Device List” and then firmware upgrade. Otherwise, click “Cancel” to exit. click “Next”...
  • Page 23 Step 8 Step 9 If you have checked the “Check Firmware Version” When the firmware upgrade is done, you will see checkbox, then the utility will check the cur- “Firmware upgrade OK” in the “Status Messages” rent firmware that is on your KVM. If the current window.
  • Page 24: Upgrade Fail

    Upgrade Fail If the upgrade fails to complete, unplug the 2 USB connections from your computer that has performed the firmware upgrade. Then, repeat the firmware upgrade process by following the procedure of Firmware Upgrade section starting from step 3.
  • Page 25: Federal Communications Commission

    Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful inter- ference in a residential setting.
  • Page 26: Ce Compliance

    CE Compliance This device has been tested and found to comply with the following European Union directives: Electro- magnetic Capability (89/336/EMC), Low Voltage (73/23/EEC) and R&TTED (1999/5/EC).
  • Page 27: Sj/T 11364-2006

    SJ/T 11364-2006 The following contains information that relates to China. 有毒有害物质或元素 部件名称 多溴联苯 多溴二苯醚 铅 (Pb) 汞 (Hg) 镉(Cd) 六价 (Cr(VI)) (PBB) (PBDE) 电器部件 ● ○ ○ ○ ○ ○ 机构部件 ○ ○ ○ ○ ○ ○ ○:表示该有毒有害物质在该部件所有均质材料中的含量均在SJ/T 11363-2006规定的限量要求之下。 ●:表示符合欧盟的豁免条款,但该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006的限量要求。...
  • Page 28: Limited Warranty

    NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Use the live chat at www.iogear.com to try and solve any issues you may be having with the product 2. Visit the Tech Info Library/FAQ on www.iogear.com (under the Support tab) 3.
  • Page 29: Contact

    IOGEAR, the IOGEAR logo, are trademarks or registered trademarks of IOGEAR. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other brand and product names are trademarks or registered trademarks of their respective holders. IOGEAR makes no warranty of any kind with regards to the information presented in this document.
  • Page 30 About Us About Us IOGEAR offers connectivity solutions that are innovative, fun, and stylish, helping people enjoy daily life using our high technology products. GREEN IOGEAR is an environmentally conscious company that emphasizes the importance of conserving natural resources. The use of our technology solutions helps reduce electronic waste.
