PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M8 Locknut M8 Star
Wave Washer M8 x 25mm
Washer (122)–4
(102)–4
(95)–2 Washer (98)–6
#8 x 1/2" #8 x 3/4" M6 x 10mm M8 x 16mm M8 x 19mm
Screw (124)–4 Screw (123)–11 Screw (121)–8 Screw (120)–8 Screw (82)–4
M8 x 35mm M10 x 75mm Screw
Bolt (96)–4 (119)–2
M10 x 90mm
Screw (84)–2
5
