www.proform.com
Model No. PFEL09911.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri., 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Decal
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFEL09911.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Form PFEL09911.0

Summary of Contents for Pro-Form PFEL09911.0

  • Page 1 Model No. PFEL09911.0 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . . 2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM ® manual. To help us assist you, note the product model 910 E elliptical. The 910 E elliptical provides an number and serial number before contacting us. The impressive selection of features designed to make your model number and the location of the serial number workouts at home more effective and enjoyable.

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 6: Assembly

    ASSEMBLY • To hire an authorized service technician to • In addition to the included tool(s), assembly assemble this product, call 1-800-445-2480. requires the following tools: one Phillips screwdriver • Assembly requires two persons. one adjustable wrench • Place all parts in a cleared area and remove the packing materials.
  • Page 7 3. Remove the screws (not shown) and the ship- ping bracket (not shown) from the rear of the Frame (1). Discard the screws. With the help of a second person, place the ship- ping bracket (not shown) under the rear of the Frame (1).
  • Page 8 6. Tip: Avoid pinching the Main Wire (110). Set the Upright (4) on the Frame (1). Attach the Upright (4) with four M8 x 19mm Screws (82) and four M8 Star Washers (122). Avoid pinching the Main Wire (110) 7. Orient the Lower Upright Cover (56) as shown. Press the Lower Upright Cover (56) into the Shield Cover (75).
  • Page 9 8. Identify the Left and Right Inner Covers (55, 68), which are marked with “Left” and “Right” stick- ers, and orient them as shown. Slide the Left Inner Cover (55) onto the left side of the Upright (4). Then, slide the Right Inner Cover (68) onto the right side of the Upright.
  • Page 10 10. Tighten an M8 x 16mm Screw (120) and an M8 x 25mm Washer (98) into each end of the Pivot Axle (35) at the same time. 11. Identify the Right Pedal (49) and the Right Pedal Arm (58), which are marked with “Right” stickers, and orient them as shown.
  • Page 11 12. Orient the Left Pedal Arm (44) as shown. Apply grease to the axle on the Left Pedal Arm (44). Attach the Left Pedal Arm (44) to the Left Roller Arm (12) with an M8 x 16mm Screw (120), a Roller Arm Cover (81), and an M8 x 25mm Grease Washer (98).
  • Page 12 14. Insert the Right Upper Body Arm (61) into the Right Upper Body Leg (36). Attach the Right Upper Body Arm (61) with two M8 x 35mm Bolts (96) and two M8 Locknuts (102). Make sure that the Locknuts are in the hexagonal holes.
  • Page 13 16. Untie and discard the wire tie on the Main Wire (110). While a second person holds the Console (7) near the Upright (4), connect the wires on the Console to the Main Wire (110), to the Right and 63, 69 Left Sensor Wires (63, 69), and to the Extension Wire (150).
  • Page 14 19. Orient the Front Upright Cover (91) as shown. Press the Front Upright Cover (91) into the Rear Upright Cover (80). Attach the Front Upright Cover (91) to the Upright (4) with a #8 x 3/4" Screw (123). 20. Make sure that all parts are properly tightened before you use the elliptical. Note: After assembly is com- pleted, some extra parts may be left over.

  • Page 15: How To Use The Elliptical

    HOW TO USE THE ELLIPTICAL HOW TO PLUG IN THE POWER CORD The lug or wire extending from the adapter must be connected with a metal screw to a permanent This product must be grounded. If it should mal- ground such as a properly grounded outlet box cover. function or break down, grounding provides a path of Some 2-pole receptacle outlet box covers are not least resistance for electric current to reduce the risk...
  • Page 16 HOW TO MOVE THE ELLIPTICAL HOW TO EXERCISE ON THE ELLIPTICAL Due to the size and weight of the elliptical, moving To mount the elliptical, hold the upper body arms or it requires two persons. Stand in front of the elliptical, the handlebars and step onto the pedal that is in the hold the upright, and place one foot against one of the lower position.
  • Page 17 CONSOLE DIAGRAM FEATURES OF THE CONSOLE The console also features revolutionary iFit Live technology that enables the console to communicate The advanced console offers an array of features with your wireless network through an optional iFit Live designed to make your workouts more effective and module.
  • Page 18 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the elliptical has been exposed to 1. Begin pedaling or press any button on the cold temperatures, allow it to warm to room tem- console to turn on the console. perature before turning on the power.
  • Page 19 4. Follow your progress with the display. Stride—This display mode will show the total num- ber of strides you have pedaled. The display can show the following workout information: Time—When the manual mode is selected, this display mode will show the elapsed time. When a workout is selected, this display mode will show the time remaining in the workout.
  • Page 20 When a wireless iFit When your pulse is detected, a heart symbol will Live module is con- flash in the display each time your heart beats, nected, the wireless one or two dashes will appear, and then your heart symbol at the top rate will be shown.
  • Page 21 HOW TO USE A TARGET TONING WORKOUT At the end of each segment of the workout, a series of tones will sound and the next segment of 1. Begin pedaling or press any button on the the profile will begin to flash. If a different resis- console to turn on the console.
  • Page 22 HOW TO USE AN IFIT LIVE WORKOUT 5. Select an iFit Live workout. You must have an iFit Live module to use an iFit Live To select an iFit Live workout, press one of the workout. iFit Live buttons. Note: Before some workouts will download, you must go to www.iFit.com and add To purchase an iFit Live module at any time, go to them to your schedule.
  • Page 23 7. Follow your progress with the display. HOW TO USE THE SOUND SYSTEM See step 4 on page 19. To play music or audio books through the console sound system while you exercise, plug the included The My Trail tab will show a map of the trail you are audio cable into the jack on the console and into a jack walking or running or it will show a track and the on your MP3 player or CD player;...
  • Page 24 HOW TO CHANGE CONSOLE SETTINGS 6. Select an audio setting for the voice of the personal trainer if desired. The console features a user mode that allows you to view usage information, select a unit of measurement, Press the decrease button to view the audio setting and adjust the contrast level of the display.

  • Page 25: Fcc Information

    FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 26: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the elliptical regularly. HOW TO ADJUST THE DRIVE BELT Replace any worn parts immediately. If the pedals slip while you are pedaling, even while To clean the elliptical, use a damp cloth and a small the resistance is adjusted to the highest level, the drive amount of mild soap.
  • Page 27 Loosen the M6 x HOW TO ADJUST THE REED SWITCH 12mm Hex Screw (85) and the M10 x 58mm If the console does not display correct feedback, the Hex Bolt (86). Then, reed switch should be adjusted. remove the right Crank Arm (20).

  • Page 28: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 29 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 30: Part List

    PART LIST Model No. PFEL09911.0 R1111A Key No. Qty. Description Key No. Qty. Description Frame Roller Rear Stabilizer Cover Pedal Arm Cap Ramp Axle Cover Upright Left Outer Cover Rear Stabilizer Left Inner Cover Front Stabilizer Lower Upright Cover Console...
  • Page 31 Key No. Qty. Description Key No. Qty. Description Idler Screw Lift Motor Bushing M8 Locknut 1" Grommet M3.5 x 12mm Flat Head Screw Crank Arm Bushing M4 x 16mm Screw Ramp Shield M8 x 16mm Hex Screw Roller Arm Flex Bracket M4 x 13mm Bright Screw Pedal Arm Flex Bracket Standoff...

  • Page 32: Exploded Drawing

    EXPLODED DRAWING A Model No. PFEL09911.0 R1111A...
  • Page 33 EXPLODED DRAWING B Model No. PFEL09911.0 R1111A...
  • Page 34 EXPLODED DRAWING C Model No. PFEL09911.0 R1111A...
  • Page 35 EXPLODED DRAWING D Model No. PFEL09911.0 R1111A...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
