Brakes

Refer to Saf ety Precautions
Front Brake Lever Freeplay
RIGHT
(1)
SIDE
(2)
(1) front brake lever
(2) dust cover
RIGHT
(2)
SIDE
( (
( )
(4)
(3) lock nut
(4) front brake cable adjuster
82
Servicing Your Honda
on page 43 .
(3)
) )
( ) increase freeplay
( ) decrease freeplay
Inspection
Check freeplay by pulling in slowly on the
front brake lever ( ) until the brake starts to 1
engage.
13/16 1 3/16 in (20 30 mm)
Freeplay:
If necessary, adjust to the specified range.
Adjustment
1. Pull the rubber dust cover ( ) back.
2. Loosen the lock nut ( ) and turn the front
brake cable adjuster ( ).
3. Tighten the lock nut. Return the dust cover
to its normal position.
4. Apply the brake, release it, then spin the
wheel and check that it rotates freely. Repeat
this procedure several times.
2
3
4
