Function setting - Vane Angle Control

This function is to adjust angle at which airflow is blow out.
FAN
SPEED
TEMP
* Vane number and the angle of wind can be selected differently in accordance with the
products.
26 Wired Remote Controller
1
2
3
OPER
4
MODE
5
OPER
When pressing the
MODE
seconds during the operation, the vane angle
control setting function can be used.
Initial 'vane1' is indicated at the window
panel upper section and the system
becomes the setting mode as 'P0' is
indicated at the temperature display section.
Select the vane angle number from 'vane1'
to 'vane4' by pressing the
- When selecting the vane number, the vane
which is corresponded to the number will be
opened and closed.
Select the vane angle from 'P0' to 'P6' with
the temp up/down button.
- In the case of the wind flowing out angle,
(Minimum angle)................(Max angle)
' P0 < P1 < P2 < P3 < P4 < P5 < P6 '
OPER
When pressing the
MODE
the setting is finished and the vane angle
control setting is completed.
- If there isn't any button input for approx. 60
seconds after the setting, the system will
be coming out of the vane angle control
setting mode automatically.
button for approx. 3
button.
OPER
MODE
button for 3 seconds,
