REI LCD/LED Monitor User Manual

10.2”; 15.4”; 23” tft ceiling & wall mounted lcd/led monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Guide

LCD/LED Monitor
Read your user guide to get quick help making your REI device easy to use. If after reading the instructions you
still need support, access:
www.reibrasil.com.br
sat@reibrasil.com.br
Call to (19) 3801-5888 with the product
information within your reach
(Model / Serial Number)
Bairro Tombadouro – CEP 13337-300 – Indaiatuba / SP – Brasil
Phone: (19) 3801-5888 / Fax (19) 3801-5873
Product code:
Serial Number
:
1
10.2" TFT Ceiling mounted monitor
15.4" TFT Ceiling mounted monitor
23" TFT Wall mounted monitor
Thank you for choosing
REI of Brazil.
¿Do you need help?

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCD/LED Monitor and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for REI LCD/LED Monitor

Summary of Contents for REI LCD/LED Monitor

  • Page 1: User Guide

    23” TFT Wall mounted monitor Thank you for choosing REI of Brazil. ¿Do you need help? Read your user guide to get quick help making your REI device easy to use. If after reading the instructions you still need support, access: www.reibrasil.com.br sat@reibrasil.com.br Call to (19) 3801-5888 with the product Bairro Tombadouro –...

  • Page 2: Introduction

    Congratulations for your purchase! Dear REI device owner: Thank you for trusting in REI of Brazil. The product you have purchased is one of the best well produced and best technical support available in the market. We will do everything as possible to keep you satisfied with your acquisition for many years more.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction ............................... 2 Table of contents ............................3 1 – Warranty Policy ........................4 2 – Security Precautions........................ 4 3 – Recycling Procedures ......................4 4 – Installation ..........................5 4.1 – Caution .......................... 5 4.2 – Warning ......................... 5 4.3 –...

  • Page 4: Warranty Policy

    1 – WARRANTY POLICY:  To learn more about the warranty policy of REI of Brazil devices, access the “Warranty Terms” in: www.reibrasil.com.br/garantia.php 2 – SECURITY PRECAUTIONS:  Make sure the monitor bracket is fixed to the vehicle’s chassis and the monitor LCD is fitted and screwed to it.

  • Page 5: Installation

    It is essential that your mount is properly grounded for user’s safety and preserving device durability.  Use only parts, accessories and original cables supplied by REI of Brazil.  The screws and mounting brackets for 10.2” and 15.4” ceiling mounted monitors are suitable for solid metal structures.

  • Page 6: Mounting

    5 – MOUNTING: 5.1 Fixing the 10.2” and 15.4” Ceiling-mounted monitors: 5.1.1 Unpacking:  Remove the system from its box carefully and its plastic protection.  Remove the plastic bag from the monitor and WARNING: Discard the packaging place the monitor over a safe surface to avoid through the local waste material program falls.

  • Page 7: Fixing The 23" Wall Mounted Monitor

    Fixing the 23” Wall-mounted monitor: 5.2.1 Unpacking:  Remove the system from its box carefully and its plastic protection.  Remove the plastic bag from the monitor and WARNING: Discard the packaging place the monitor over a safe surface to avoid through the local waste material program falls.

  • Page 8: Technical Specifications

    6 – TECHNICAL SPECIFICATIONS: 6.1 – 10.2” Ceiling-mounted Monitor Item Min. Typ. Max. Unit Rated Power Source − Durable Temperature Range °C Pixel Pixels 800 x 480 − Color System NTSC / PAL Power Consumption mA (24Vdc) Ω Input Impedance Dimensions (closed) (W x H x D) 188 X 290 x 84 Weight...

  • Page 9: Troubleshooting

    The screens have polycarbonate protection acting as an antiglare agent and allowing best image visualization during the sunlight. 9.2 Technology:  The monitors manufactured by REI of Brazil use TFT technology, allowing best image quality of the LCD monitors.  Backlight LED technology guarantees less power consumption, high contrast, more...

  • Page 10: Identification

    9.3 Identification:  All the devices have an identification label with: Product code, serial number, manufacturing lot, manufacturing week and manufacturing year. This information is useful to track the device, the year and manufacturing model and identify the components in case of requiring replacement parts.
