REI 10.2” TFT LCD Flip-Down User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

User Guide

LCD/LED Monitor
Read your user guide to get quick help making your REI device easy to use. If after reading the instructions you
still need support, access:
www.reibrasil.com.br
sat@reibrasil.com.br
Call to (19) 3801-5888 with the product
information within your reach
(Model / Serial Number)
Bairro Tombadouro – CEP 13337-300 – Indaiatuba / SP – Brasil
Phone: (19) 3801-5888 / Fax (19) 3801-5873
Product code:
Serial Number
1
10.2" TFT LCD Flip-Down Monitor
15.4" TFT LCD Flip-Down Monitor
Thank you for choosing
¿Do you need help?
:
REI of Brazil.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 10.2” TFT LCD Flip-Down and is the answer not in the manual?

Questions and answers

Related Manuals for REI 10.2” TFT LCD Flip-Down

Summary of Contents for REI 10.2” TFT LCD Flip-Down

  • Page 1: User Guide

    15.4” TFT LCD Flip-Down Monitor Thank you for choosing REI of Brazil. ¿Do you need help? Read your user guide to get quick help making your REI device easy to use. If after reading the instructions you still need support, access: www.reibrasil.com.br sat@reibrasil.com.br Call to (19) 3801-5888 with the product Bairro Tombadouro –...

  • Page 2: Introduction

    Congratulations for your purchase! Dear REI device owner: Thank you for trusting in REI of Brazil. The product you have purchased is one of the best well produced and best technical support available in the market. We will do everything as possible to keep you satisfied with your acquisition for many years more.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction ............................... 2 Table of contents ............................3 1 – Warranty Policy ........................4 2 – Security Precautions........................ 4 3 – Recycling Procedures ......................4 4 – Installation ..........................5 4.1 – Caution .......................... 5 4.2 – Warning ......................... 5 4.3 –...

  • Page 4: Warranty Policy

    1 – WARRANTY POLICY:  To learn more about the warranty policy of REI of Brazil devices, access the “Warranty Terms” in: www.reibrasil.com.br/garantia.php 2 – SECURITY PRECAUTIONS: Make sure the monitor bracket is fixed to the vehicle’s chassis and the monitor LCD is fitted ...

  • Page 5: Installation

    It is essential that your mount is properly grounded for user’s safety and preserving device durability.  Use only parts, accessories and original cables supplied by REI of Brazil.  The screws and mounting brackets for flip-down monitors are suitable for solid metal structures.

  • Page 6: Mounting

    5 – MOUNTING: 5.1 Fixing the 10.2” Flip-Down Monitor 5.1.1 Unpacking:  Remove the system from its box carefully and its plastic protection.  Remove the plastic bag from the monitor and WARNING: Discard the packaging place the monitor over a safe surface to avoid through the local waste material program falls.
  • Page 7  Adjust the screw pins height to align the monitor bracket. An unaligned monitor bracket can prevent the opening and closing monitor cycle works correctly and can reduce the useful life.  Connect the power cord (Faston 2 pins) and then connect the video signal cable (BNC). Cover this connector to prevent short-circuit with the vehicle’s chassis.

  • Page 8: Technical Specifications

    6 – TECHNICAL SPECIFICATIONS: 6.1 – 10.2” Flip-Down Monitor Item Min. Typ. Max. Unit Rated Power Source − Durable Temperature Range °C Pixel Pixels 800 x 480 − Color System NTSC / PAL Power Consumption mA (24Vdc) Power Consumption (Closing cycle) mA (24Vdc) Ω...

  • Page 9: Troubleshooting

    7 – TROUBLESHOOTING: 7.1 No power ON:  Verify if the power cord is connected to the monitor.  Make sure that power cord is getting 24Vdc. Verify if the system fuse or the monitor fuse is blown. 7.2 No Image: ...

  • Page 10: General Specifications

    This lock will be only released when video signal is received. 9.2 Technology:  The monitors manufactured by REI of Brazil use TFT technology, allowing best image quality of the LCD monitors.  Backlight LED technology guarantees less power consumption, high contrast, more brightness, and thin screens reducing the weight and improving the heat dissipation.
