Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Mercury. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it.
Page 5: Safety And Environment Protection
Introduction This Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available. Remember to pass on the Owner’s Guide when reselling the vehicle.
Page 6 Introduction Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.
Page 7 Introduction Special instructions For your safety, your vehicle is fitted with sophisticated electronic controls. By operating other electronic equipment (e.g. mobile telephone without exterior aerial) electromagnetic fields can occur which can cause malfunctions of the vehicle electronics. Therefore you should observe the instructions of the equipment manufacturers.
Page 8: Symbol Glossary
Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Tether Warning Anchorage Brake System Anti-Lock Brake System Brake Fluid - Traction Control...
Page 9 Introduction Vehicle Symbol Glossary Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid Power Steering Fluid Level Emission System...
Page 10: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 11 Instrument Cluster Service engine soon Illuminates briefly to ensure the SERVICE system is functional. If it comes on ENGINE after the engine is started, one of SOON the engine’s emission control systems may be malfunctioning. The light may illuminate without a driveability concern being noted.
Page 12 Instrument Cluster Brake system warning • Standard analog instrument cluster BRAKE • Optional electronic instrument cluster BRAKE Illuminates if the parking brake is engaged. Also momentarily illuminates at start up to ensure the circuit is functional. If the brake warning lamp does not illuminate at these times, or illuminates after releasing the parking brake, seek service immediately.
Page 13 Instrument Cluster Air bag readiness • Standard analog instrument cluster • Optional electronic instrument cluster Illuminates to confirm that the air bags are operational. If the light fails to illuminate, continues to flash or remains on, have the system serviced immediately.
Page 14 Instrument Cluster Speed control • Standard analog instrument CRUISE cluster The “CRUISE” light comes on when the ON control is pressed. The “SET” light comes on when either the COAST/SET or RES/ACCEL controls are pressed. The “SET” light turns off when the cruise cancel control is pressed or the brake is applied.
Page 15: Gauges
Instrument Cluster Turn signals Illuminates when the turn signals or the hazard lights are turned on. If the lights stay on continuously or flash faster, check for a burned-out bulb. High beams Illuminates when the high beam headlamps are turned on. Safety belt warning chime Sounds to remind you to fasten your safety belts.
Page 16 Instrument Cluster Optional electronic instrument cluster gauges CRUISE ˚F ˚C MILES/BAL L/100 km OUTSIDE TEMP km/h INST ECONOMY AVG. ECONOMY X 1000 TRIP 1 TO EMPTY TRIP 2 FUEL DOOR UNLEADED FUEL ONLY SERVICE R N D 2 1 BRAKE ENGINE SOON Engine coolant temperature gauge...
Page 17 Instrument Cluster • Optional electronic instrument cluster Fuel gauge Displays approximately how much fuel is in the fuel tank. The fuel gauge may vary slightly when the vehicle is in motion or on a grade. When refueling the vehicle from empty indication, the amount of fuel that can be added will be less than the advertised capacity due to the reserve fuel.
Page 18 Instrument Cluster Speedometer Indicates the current vehicle speed. • Standard analog instrument cluster 50 60 80 100 km/h TRIP A • Optional electronic instrument cluster CRUISE km/h X 1000 TRIP 1 TRIP 2 Odometer Registers the total kilometers (miles) of the vehicle. •...
Page 19 Instrument Cluster Trip odometer Registers the kilometers (miles) of individual journeys. • Standard analog instrument TRIP A cluster To reset, press and hold the control for one second. • Optional electronic instrument cluster CRUISE Refer to Electronic Message Center in the Driver controls chapter for information on how to switch the km/h X 1000...
Page 20: Entertainment Systems
Entertainment Systems AM/FM STEREO/CASSETTE (CD CHANGER COMPATIBLE) VOL - PUSH ON BASS TREB FADE TAPE SEEK SIDE 1 - 2 SCAN TUNE DISCS COMP SHUFFLE Volume/power control Press the control to turn the audio VOL - PUSH ON system on or off. Turn the control to raise or lower volume.
Page 21 Entertainment Systems Bass adjust The bass adjust control allows you to increase or decrease the audio system’s bass output. BASS Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output. TREB Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers.
Page 22 Entertainment Systems Seek function The seek function control works in radio or CD changer mode. Seek function in radio mode • Press to find the next SEEK listenable station down the frequency band. TUNE • Press DISCS to find the next listenable station up the frequency band.
Page 23 Entertainment Systems AM/FM select The AM/FM select control works in radio, tape and CD changer modes (if equipped). AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations. AM/FM select in tape mode Press this control to stop tape play and begin radio play.
Page 24 Entertainment Systems Setting the clock Press CLK to toggle between listening frequencies and clock mode while in radio mode. To set the hour, press and hold the CLK control and press the SEEK TAPE control: • to decrease hours and SEEK •...
Page 25 Entertainment Systems Tune adjust The tune control works in radio and CD changer modes (if equipped). Tune adjust in radio mode • Press to move to the next SEEK frequency down the band (whether or not a listenable TUNE station is located there). Hold the DISCS control to move through the frequencies quickly.
Page 26 Entertainment Systems Automatic Music Search The Automatic Music Search feature allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection. TAPE To activate the feature, momentarily depress the TAPE AMS button. Then, press either REW (for the beginning of the current selection) or FF (to advance to the next selection).
Page 27 Entertainment Systems Fast forward The fast forward control works in tape and CD changer modes. To fast forward in tape mode, press SIDE 1 - 2 the 1–2/FF control. Tape direction will automatically reverse when the end of the tape is reached.
Page 28 Entertainment Systems Shuffle feature (if equipped) The shuffle feature operates in CD SHUFFLE changer mode and plays all tracks on the current disc in random order. The shuffle feature continues to the next disc after all tracks are played. Press the SHUFFLE control to start this feature. Random order play will continue until the SHUFFLE control is pressed again.
Page 29 Entertainment Systems PREMIUM AM/FM CASSETTE (CD CHANGER COMPATIBLE) BASS TREB FADE PUSH ON TAPE RDS / CLK SEEK TUNE SCAN AUTO MUTE SIDE 1 . 2 COMP SHUFF Your audio system is equipped with selective lighting, a unique lighting strategy. This lighting feature is operable when the headlamps are illuminated.
Page 30 Entertainment Systems If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. Bass adjust The bass adjust control allows you to increase or decrease the audio BASS system’s bass output.
Page 31 Entertainment Systems Seek function The seek function control works in radio, tape or CD changer mode (if equipped). Seek function in radio mode • Press to find the next SEEK listenable station down the frequency band. • Press to find the next listenable station up the frequency band. Seek function in tape mode •...
Page 32 Entertainment Systems Scan function in CD changer mode (if equipped) Press the SCAN control to hear a short sampling of all selections on the CD (The CD scans in a forward direction, wrapping back to the first track at the end of the CD.). To stop on a particular selection, press the control again.
Page 33 Entertainment Systems Starting autoset memory preset 1. Select a frequency using the AM/FM select controls. 2. Press the AUTO control. AUTO 3. When the first six strong stations are filled, the station stored in memory preset control 1 will start playing.
Page 34 Entertainment Systems Tune adjust for CD changer • Press to select the previous TUNE disc in the CD changer. (Play will begin on the first track of the disc unless the CD changer is in shuffle mode.) Refer to Shuffle feature for more information.
Page 35 Entertainment Systems Fast forward The fast forward control works in tape and CD changer modes (if equipped). • In the tape mode, tape direction will automatically reverse when the end of the tape is reached. • In CD changer mode, pressing the control for less than three seconds results in slow forward action.
Page 36 Entertainment Systems Compression feature (if equipped) Compression adjust brings soft and COMP loud CD passages together for a more consistent listening level. Press the COMP control to activate and deactivate compression adjust. Shuffle feature (if equipped) The shuffle feature operates in CD SHUFF changer mode and plays all tracks on the current disc in random order.
Page 37 Entertainment Systems Press the RDS/CLK control until RDS OFF is displayed. • Use the SEL control to select ON or OFF. Traffic • Press the RDS control until TRAFFIC is displayed. RDS / CLK • Use the SEL control to select ON or OFF.
Page 38 Entertainment Systems Show • With RDS activated, press the RDS control until SHOW is RDS / CLK displayed. • Use the SEL control to select the program TYPE, station NAME or NONE (no text displayed). Rear audio controls (if equipped) Your vehicle may be equipped with rear audio controls for the rear seat passengers.
Page 39 Entertainment Systems Volume/power control Press the control to turn the audio VOL - PUSH ON system on or off. Turn control to raise or lower volume. VOL - PUSH ON If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 40 Entertainment Systems Treble adjust The treble adjust control allows you to increase or decrease the audio BASS TREB system’s treble output. Press the TREB control then press: • to decrease treble output and • to increase treble output. Speaker balance adjust Speaker sound distribution can be FADE adjusted between the right and left...
Page 41 Entertainment Systems Seek function The seek function control works in radio, tape or CD mode. Seek function in radio mode • Press to find the next listenable station down the frequency band. • Press to find the next listenable station up the frequency band.
Page 42 Entertainment Systems Scan function in CD mode Press the SCAN control to hear a short sampling of all selections on the CD. (The CD scans in a forward direction, wrapping back to the first track at the end of the CD.) To stop on a particular selection, press the control again.
Page 43 Entertainment Systems Autoset memory preset Autoset allows you to set strong radio stations without losing your original manually set preset stations. This feature is helpful on trips when you travel between cities with different radio stations. Starting autoset memory preset 1.
Page 44 Entertainment Systems To set the minute, press the AUTO RDS/CLK control until SELECT MIN is displayed and press: • to decrease minutes and • to increase minutes. Tune adjust The tune control works in radio or CD mode. Tune adjust in radio mode •...
Page 45 Entertainment Systems Tape/CD/CD changer (if equipped) select • To begin tape play (with a tape loaded into the audio system) TAPE while in the radio or CD mode, press the TAPE control. Press the button during rewind or fast forward to stop the rewind or fast forward function.
Page 46 Entertainment Systems Tape direction select Press SIDE 1–2 to play the alternate SIDE 1-2 side of a tape. Eject function Press the control to stop and eject a tape. Press the control to stop and eject a Dolby noise reduction Dolby noise reduction operates only in tape mode.
Page 47 Entertainment Systems Shuffle feature The shuffle feature operates in CD SHUFFLE mode and plays all tracks on the current disc in random order. If equipped with the CD changer, the shuffle feature continues to the next disc after all tracks on the current disc are played. Press the SHUFFLE control to start this feature.
Page 48 Entertainment Systems RDS traffic announcement When set ON, this traffic feature will AUTO interrupt tape or CD play to play a traffic report broadcast from a FM RDS station. To activate the traffic feature: • Press the RDS control until TRAFFIC is displayed. To see if any stations in your area are capable of broadcasting an RDS traffic alert, press SCAN or SEEK while TRAFFIC ON is displayed.
Page 49: Rear Seat Controls
Entertainment Systems RDS show RDS sends information with the FM AUTO broadcast, including: station name, station type, and/or radio text. To view this information: • With the RDS menu enabled, press the RDS control until SHOW is displayed. • Use the SEL control to select TYPE, NAME, TEXT or NONE.
Page 50 Entertainment Systems ADJUSTING THE VOLUME Press the + control to increase volume. VOLUME MEDIA SEEK Press the — control to decrease volume. From the RSC, the speaker volume can not be set higher than the current volume radio setting. Once in headphone mode, the RSC volume controls will only change the headphone volume level (muting the speakers will not mute the headphones).
Page 51 Entertainment Systems MEDIA SELECT Push the MEDIA control to toggle between AM, FM1, FM2, tape, or CD VOLUME MEDIA SEEK changer (if equipped). MEMORY PRESET CONTROL Push the MEM control successively to allow rear sear passengers to VOLUME MEDIA SEEK scroll through the six memory presets in AM, FM1, or FM2.
Page 52: Cd Changer
Entertainment Systems CD CHANGER (IF EQUIPPED) The CD changer is located in the center console of your vehicle. 1. Slide the door to access the CD changer magazine. 2. Press EJECT to eject the magazine. 3. Turn the magazine (A) over. 4.
Page 53 Entertainment Systems If you pull too hard on the disc holder, the disc holder may come completely out of the magazine. If this happens, reinsert the disc holder back into the magazine while pressing on the lever (A). 5. Line up the CD with the groove of the disc holder.
Page 54 Entertainment Systems The CD magazine may be inserted or ejected with the radio power on or off. ONLY use the magazine type supplied with the CD changer, other types will damage the unit. Keep the CD changer door closed. Coins and foreign objects will damage the CD player and void your audio system warranty.
Page 55 Entertainment Systems CD AND CD CHANGER CARE • Handle discs by their edges only. Never touch the playing surface. • Do not expose discs to direct sunlight or heat sources for extended periods of time. • Do not insert more than one disc into each slot of the CD changer magazine.
Page 56 Entertainment Systems RADIO RECEPTION FACTORS Three factors can affect radio reception: • Distance/strength. The further an FM signal travels, the weaker it is. The listenable range of the average FM station is approximately 40 km (24 miles). This range can be affected by “signal modulation.” Signal modulation is a process radio stations use to increase their strength/volume relative to other stations.
Page 57: Climate Controls
Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM CLIMATE CONTROL SYSTEM Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. Mode Selector Control Controls the direction of the airflow to the inside of the vehicle.
Page 58 Climate Controls The air condition operates in MAX A/C and when the A/C control is depressed. However, the air conditioning will only function if the outside temperature is about 4°C (40°F) or higher. Since the air conditioner removes considerable moisture from the air during operation, it is normal if clear water drips on the ground under the air conditioner drain while the system is working and even after you have stopped the vehicle.
Page 59 Climate Controls • To reduce humidity buildup inside the vehicle in warm weather conditions, don’t drive with the climate control system in the OFF position. • Under normal weather conditions, your vehicle’s climate control system should be left in any position other than the MAX A/C or OFF when the vehicle is parked.
Page 60 Climate Controls REAR PASSENGER AIR CONDITIONING SYSTEM (IF EQUIPPED) This system allows the rear seat occupants to adjust their air conditioning comfort level. The rear A/C fan speed control allows the rear passengers to control the volume of air that is distributed from the rear registers. REAR The rear seat A/C system is controlled from the main climate control system on the instrument panel.
Page 61 Climate Controls Turning the Rear A/C on 1. Set the main climate control rear fan control to Rear A/C; set the mode selector to any position (other than OFF), and depress the A/C control. OFF REAR A/C 1 2. Set the fan speed on the Rear A/C fan control to a number between 1–4 to regulate the airflow to the rear seat section.
Page 62 Climate Controls Turning the Rear A/C off: There are two ways to turn the rear air conditioning system off. The first way is to set the Rear Fan Control on the main climate control system to OFF. OFF REAR A/C 1 You can also set the Rear Fan Control on the main climate control system to Rear A/C and turn the Rear A/C Fan Control to 0.
Page 63: Electronic Automatic Temperature Control
Climate Controls ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) SYSTEM (IF EQUIPPED) OFF REAR 1 TEMP AUTOMATIC The EATC system will maintain a selected temperature and automatically control airflow. You can override automatic operation with any of the override controls or the fan speed control. Turning the EATC system on OFF REAR 1 TEMP...
Page 64 Climate Controls Turning the EATC system off Press OFF. OFF REAR 1 TEMP AUTOMATIC Automatic operation Press AUTOMATIC and select the desired temperature. The selected temperature and the word AUTO will appear in the display window. The EATC system will either heat or cool to achieve the selected temperature.
Page 65 Climate Controls To control the temperature, select any temperature between 15°C (60°F) and 32°C (90°F) by pressing the temperature controls. However, individual temperature settings between 15°C (60°F) and 18°C OFF REAR 1 TEMP (65°F) cannot be selected. The 15°C AUTOMATIC (60°F) and 18°C (65°F) temperatures are the lowest settings available.
Page 66 Climate Controls Manual override controls OFF REAR 1 TEMP AUTOMATIC The override controls allow you to: • manually control where the airflow is directed • manually control the air conditioning operation • manually select between outside or recirculated air during air conditioning operation The air conditioning can operate in all modes except OFF.
Page 67 Climate Controls • (Defrost)-Distributes outside air through the windshield defroster ducts. It can be used to clear ice or fog from the windshield. If the temperature is about 4°C (40°F) or higher, the air conditioner will automatically dehumidify the air to reduce fogging. •...
Page 68 Climate Controls During periods of high humidity, vapor may be emitted from the air outlets when using the A/C system with outside air. This can be corrected by using MAX A/C to cool the vehicle. Rear seat heating Rear seat heating is provided through the floor ducts located under the front seats.
Page 69 Climate Controls • If your vehicle has been parked with the windows closed during hot weather, the air conditioner will do a much faster job of cooling if you drive for two or three minutes with the windows open. This will force most of the hot, stale air out of the vehicle.
Page 70 Climate Controls REAR PASSENGER AIR CONDITIONING SYSTEM — EATC SYSTEMS On vehicles equipped with front passenger EATC systems, the vehicle will also have rear passenger compartment climate controls, which allow the rear seat occupants to adjust their air conditioning level. The rear A/C fan speed control allows rear passengers to control the volume of air that is distributed from the rear registers.
Page 71 Climate Controls Turning the Rear A/C on 1. Set the main climate control rear fan control to Rear A/C; set the mode selector to any position (other than OFF), and depress the A/C control. OFF REAR 1 TEMP AUTOMATIC 2. Set the fan speed on the Rear A/C fan control to a number between 1–4 to regulate the airflow to the rear seat section.
Page 72 Climate Controls You can also turn the Rear Fan Control on the main climate control system to Rear A/C and turn the Rear A/C Fan Control to 0. REAR For maximum cooling for the front seat passengers, set the rear fan switch to the OFF (0) position.
Page 73 • Protects the climate control components from particle deposits The filter is located just in front of the windshield under the cowl grille on the passenger side of the vehicle. For more information, or to replace the filter, see your Ford, Lincoln or Mercury Dealer.
Page 74: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control clockwise to the first position to turn on the parking lamps. Rotate clockwise to the second position to also turn on the headlamps. Push the control to turn on the interior lamps. Push control again to turn off the interior lamps.
Page 75 Lights High beams • Push forward to activate. • Pull toward you to deactivate. Flash to pass Pull toward you to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel. • Push and hold top of control to brighten.
Page 76 Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS Dome lamps The front dome lamp is located overhead between the driver and passenger seats. The dome lamp will stay on if the control is moved to the ON position.
Page 77: Headlamps
Lights Map lamps (if equipped) The map lamps are located on the overhead console and the side roof panels. Press the lamp lens to activate the lamps. BULBS Replacing exterior bulbs It is a good idea to check the operation of the following lights frequently: •...
Page 78: Bulb Replacement
Lights Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to assure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time.
Page 79 Lights Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure headlamp switch is in OFF position, then open the hood. 2. Disconnect the electrical connector from the bulb by pulling rearward. 3. Remove the bulb retaining ring by rotating it counterclockwise (when viewed from the rear) to free it from the bulb socket, and slide the...
Page 80 Lights 4. Turn the headlamps on and make sure they work properly. If the headlamp was correctly aligned before you changed the bulb, you should not need to align it again. Replacing front cornering/side marker lamp bulbs 1. Remove screw from the lamp assembly.
Page 81 Lights Replacing high-mount brakelamp bulbs 1. Remove the two screws and lamp assembly from vehicle. 2. Remove the bulb by rotating socket counterclockwise and pulling it out of the lamp assembly. 3. Pull bulb straight out of socket and push in the new bulb. 4.
Page 82 Lights Replacing license plate lamp bulbs 1. Remove two screws, grommets and the license plate lamp assembly from the liftgate. 2. Remove bulb socket by turning counterclockwise. 3. Carefully pull the bulb from the socket and push in the new bulb. 4.
Page 83: Driver Controls
Driver Controls WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The bars of varying length are for intermittent wipers. When in this position rotate the control upward for fast intervals and downward for slow intervals.
Page 84 Driver Controls Press the washer control to activate the rear washer. The wiper will HAZARD come on when the washer control is pressed, if it is not already on. RR WASH RR WIPER RR DEFOG SECURITY Windshield wiper blades Check the wiper blades at least twice a year or when they seem less effective.
Page 85 Driver Controls Changing the wiper blades To replace the wiper blades: 1. Pull the wiper arm away from the windshield and lock into the service position. 2. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the...
Page 86 Driver Controls ILLUMINATED VISOR MIRROR To turn on the visor mirror lamps, lift the mirror cover. OVERHEAD CONSOLE (IF EQUIPPED) The appearance of your vehicle’s overhead console will vary according to your option package. Conversation mirror (if equipped) The conversation mirror allows the driver to view the rear seating area.
Page 87 Driver Controls There are two auxiliary power points: • One is located on the instrument panel. • The second is located in the drivers side 2nd row trim panel.
Page 88: Power Windows
Driver Controls POWER WINDOWS • Press and hold the switch to open. • Pull up and hold the switch to close. AUTO L VENT R One touch down • Press AUTO completely down and release quickly. The driver’s window will open fully. Depress again to stop window operation.
Page 89: Mirrors
Driver Controls Power vent windows (if equipped) Your vehicle may be equipped with rear power vent windows which are operated the same as the front power windows. AUTO L VENT R POWER SIDE VIEW MIRRORS The ignition must be in ACC or ON position to adjust the power side view mirrors.
Page 90 Driver Controls 2. Move the control in the direction you wish to tilt the mirror. MIRRORS 3. Return to the center position to lock mirrors in place. Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated.
Page 91 Driver Controls SPEED CONTROL To turn speed control on • Press ON. Vehicle speed cannot be controlled ACCEL until the vehicle is traveling at or above 48 km/h (30 mph). Do not shift the gearshift lever CANCEL into N (Neutral) with the speed control on.
Page 92 Driver Controls To set a speed • Press COAST/ SET. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph). If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed.
Page 93 Driver Controls To set a lower set speed • Press and hold COAST/SET. Release the control when the desired speed is reached or • Press and release COAST/SET to operate the Tap-Down function. Each press will decrease the set speed by 1.6 km/h (1 mph) or •...
Page 94 Driver Controls • Press OFF. Pressing OFF will erase the ACCEL previously programmed set speed. CANCEL COAST To return to a previously set speed • Press RES/ACCEL. For RES/ACCEL to operate, the vehicle speed must be faster than ACCEL 48 km/h (30 mph). CANCEL COAST Indicator light...
Page 95 Driver Controls STEERING WHEEL CONTROLS (IF EQUIPPED) These controls allow you to operate some audio control features. Audio control features In Radio mode: • Press NEXT to select the next preset station within the current radio band. In Tape mode: NEXT •...
Page 96 Driver Controls MOON ROOF (IF EQUIPPED) To operate the moon roof: • To open, press and hold the rear portion of the control. This will fully open the moon roof. • To close, press and hold the front portion of the control. To operate the moon roof vent position: •...
Page 97 Driver Controls an object, signaling the door to stop and reverse, does not meet current U.S. federal safety standards. For more information on this matter, call toll-free: 1–800–355–3515 or on the Internet at HomeLink.jci.com. Programming Do not program the HomeLink Universal Transceiver with the vehicle parked in the garage.
Page 98 Driver Controls Canadian Programming During programming, your hand-held transmitter may automatically stop transmitting after two seconds which may not be long enough to program the HomeLink Universal Transceiver. To program your hand-held transmitters: • Continue to hold the button on the HomeLink Universal Transceiver.
Page 99 Driver Controls After completing the “Programming” functions, follow these steps to train a garage door opener with the rolling code feature: 1. Locate the training button on the garage door motor head unit. Refer to the garage door opener manual or call 1–800–355–3515 or on the Internet at HomeLink.jci.com.
Page 100: Message Center
Driver Controls Reprogramming a single HomeLink button To program a device to HomeLink using a HomeLink button previously trained, follow these steps: 1. Press and hold the desired HomeLink button. Do NOT release until step 4 has been completed. 2. When the indicator light begins to flash slowly (after 20 seconds), position the hand-held transmitter 5–14 cm (2 to 5 inches) away from the HomeLink surface.
Page 101 Driver Controls Selectable features Select Press this control to select the following features: RESET ENG / MET TRIP / RST SELECT OD / TRIP • OUTSIDE TEMP • INST ECONOMY ˚F ˚C • AVG ECONOMY MILES/GAL L/100 km • TO EMPTY MILES km OUTSIDE TEMP INST ECONOMY...
Page 102 Driver Controls Message center functions Outside temp Press SELECT until the menu displays OUTSIDE TEMP. This will display the temperature of the air ˚F ˚C MILES/GAL outside of your vehicle. The L/100 km MILES km accurate temperature will be OUTSIDE TEMP displayed after the vehicle has INST ECONOMY AVG ECONOMY...
Page 103 Driver Controls Checking your highway fuel economy using the electronic message center display Use the following procedure will allow you to accurately monitor your actual highway fuel economy. This procedure requires the vehicle speed control system to be set to highway speeds and must be run only on suitable roadways where long distance speed control can be safely maintained.
Page 104 Driver Controls POSITIVE RETENTION FLOOR MAT Position the floor mat so that the eyelet is over the pointed end of the retention post. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal. To remove the floor mat, reverse the installation procedure.
Page 105 Driver Controls Deactivating overdrive Press the Transmission Control Switch (TCS) located on the end of OVERDRIVE OFF/ON the gearshift lever. The O/D OFF indicator light will illuminate. The transaxle will operate in all gears except overdrive. To return to normal overdrive mode, press the Transmission Control Switch again.
Page 106 Driver Controls Make sure that the liftgate door and/or window are closed to prevent exhaust fumes from being drawn into the vehicle. This will also prevent passengers and cargo from falling out. If you must drive with the liftgate door or window open, keep the vents open so outside air comes into the vehicle.
Page 107 Driver Controls Front Cargo net (if equipped) The front cargo net can be used to hold small items between the front seats. To install the net, secure the hooks into the retainers located on the inboard base of the front seats. Parcel Shelf (if equipped) Your vehicle may be equipped with a 14 kg (30 lbs.) maximum capacity...
Page 108 Driver Controls To secure objects on the shelf: 1. Disconnect the net loops from the retainers underneath the shelf. 2. Place the objects underneath the net and secure the net loops to the retainers underneath the shelf. All objects loaded on the cargo shelf MUST BE SECURED UNDER THE CARGO NET.
Page 109 Driver Controls LUGGAGE RACK (IF EQUIPPED) The front and rear cross-bar can be adjusted to fit the item being carried. Do not load more than 44 kg (100 lbs.) on the luggage rack. To adjust cross-bar position: 1. Loosen the thumbwheel at both ends of the cross-bar.
Page 110: Locks And Security
Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency. POWER DOOR LOCKS Push control forward to unlock all UNLOCK...
Page 111: Anti-Theft System
Locks and Security Pull lock control out to engage the lock. Push control in to disengage childproof locks. REMOTE ENTRY SYSTEM This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 112 Locks and Security Unlocking the doors Press this control to unlock the driver’s door. The interior lamps will illuminate and the parking and tail lamps will flash once. Press the control a second time within five seconds to unlock all doors.
Page 113 Locks and Security Replacing the battery The transmitter is powered by one coin type three-volt lithium battery. Typical operating range will allow you to be up to 10 meters (33 feet) away from your vehicle. A decrease in operating range can be caused by: •...
Page 114 Locks and Security Re-insert the key and turn to the ON position. Press any control on the first transmitter. The park lamps will flash twice to confirm the programming. To program additional (up to four) transmitters yourself: • Unlock, then lock the driver’s door using the power door lock switch. •...
Page 115 Locks and Security The system is ready to arm whenever the key is removed from the ignition. Any of the following actions will prearm the alarm system: • Lock the doors with the remote transmitter (doors opened or closed). The horn will chirp (if all doors are closed) to confirm that the control was pressed.
Page 116 Locks and Security Disarming the anti-theft system Disarming an untriggered anti-theft system You can disarm the system by any of the following actions: • Unlock the doors by using your remote entry transmitter. • Unlock the doors with a key. Turn the key full travel (toward the rear of the vehicle) to make sure the alarm disarms.
Page 117: Seating And Safety Restraints
Seating and Safety Restraints SEATING Adjustable head restraints (if equipped) Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 118 Seating and Safety Restraints Adjusting the front manual seat Never adjust the driver’s seat or seatback when the vehicle is moving. Do not pile cargo higher than the seatbacks to reduce the risk of injuring people in a collision or sudden stop. Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
Page 119 Seating and Safety Restraints Using the manual lumbar support (if equipped) The lumbar control is located on the inboard side of the driver’s seat. Move the control up or down to adjust lumbar support. Adjusting the power seats (if equipped) The power seat controls are located on the outboard side of the seat.
Page 120 Seating and Safety Restraints • 6 way (driver seat) • 4 way (passenger seat) Rotate the vertical control to adjust the seatback. Memory seats and mirrors (if equipped) Some vehicles may only have the memory feature available for the seats. The memory seat control is located on the driver’s door panel.
Page 121 Seating and Safety Restraints 2. Press button 1 or 2 and hold for at least two seconds. The indicator light will stay on until the position is programmed. When the position has been programmed, the indicator light will flash three times. Repeat procedure for second position.
Page 122 Seating and Safety Restraints • 4 passenger vehicle (with third row seat in storage position) A. Cargo mat (if equipped) B. Narrow mats C. Sliding door mats, LH/RH • 5 passenger vehicle (second row seats removed) A. Cargo mat (if equipped) B.
Page 123 Seating and Safety Restraints • 5 passenger vehicle (second row seats removed and third row bench seat moved forward to limousine seating position) A. Cargo mat (if equipped) B. Narrow mats • Two passenger vehicle (second row seats removed and third row seat stored in full forward position —...
Page 124 Seating and Safety Restraints Stowed cupholders The vehicle is equipped with cupholders that pull out from the 2nd row seat: • Bench seat - below center of the seat cushion • Bucket seat (driver’s side only) - inboard side of seat base Use only soft cups in the cupholder.
Page 125 Seating and Safety Restraints 2nd row bucket seats (if equipped) • Adjusting the left side bucket seat Pull control up to recline the seatback or fold the seatback flat. • Adjusting the right side (E-Z Entry Tip Slide) bucket seat The E-Z Entry Tip Slide seat allows for easier entry and exit to and from the 3rd row seat.
Page 126 Seating and Safety Restraints To exit the third row seat, pull up on the 3rd row access control. To return the seat to a seating position, move the seat rearward until the seat track locks. Then readjust the seatback. Lift handle to move the seat forward or backward.
Page 127 Seating and Safety Restraints Pull control up to flip seatback to a forward flat position. Adjusting 3rd row bench Pull control up to adjust seatback position. This control will also allow the seatback to be put in the forward flat position.
Page 128 Seating and Safety Restraints The entire seat can be moved to four seating positions and two storage positions. Before rearranging the seats, remove any floor mats that might be in the way, see Removable floor mats in this chapter for instructions on placement of floor mats.
Page 129 Seating and Safety Restraints To move the seat to another seating or storage position: 1. Lift control (A) to release the seat cushion and flip the cushion up. The seat cushion must be moved to the storage position before the seat can be moved along the track.
Page 130 Seating and Safety Restraints After sliding the seat, check to ensure that both sides of the seat are locked in position. This must be done before the vehicle is put into motion in order to prevent unintended movement of the seat. Every time you adjust any seat, check to be sure that it is properly latched in the lock position of both seat tracks.
Page 131: Safety Restraints
Seating and Safety Restraints To install the seat: The bucket seats are not interchangeable due to the locations of the seat anchors on the floor of the vehicle. Each seat must be installed in its original position. 1. Position the seat in the vehicle. 2.
Page 132 Seating and Safety Restraints It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
Page 133 Seating and Safety Restraints 2. To unfasten, push the release button and remove the tongue from the buckle. The front and rear outboard safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat outboard safety belts have two types of locking modes described below: Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free...
Page 134 This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Ford Motor Company recommends that all safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
Page 135 Seating and Safety Restraints Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode. After any vehicle collision, the front passenger and rear outboard seat belt systems must be checked by a qualified technician to verify that the “automatic locking retractor”...
Page 136 Seating and Safety Restraints Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, push the button and slide the height adjuster down.
Page 137 Seating and Safety Restraints Shorten and fasten the belt when not in use. Safety belt warning light and indicator chime The seat belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If...
Page 138 (if equipped), shoulder belt guide on seatback (if equipped), LATCH child safety seat tether anchors and lower anchors, and attaching hardware, should be inspected after a collision. Ford recommends that all safety belt assemblies used in vehicles involved in a collision be replaced.
Page 139: Air Bags
This information will assist Ford Motor Company in the servicing vehicle and helping to better understand real world collisions and further improve the safety of future vehicles.
Page 140 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. Modifications to the front end of the vehicle, including frame, bumper, front end body structure and tow hooks may affect the performance of the air bag sensors increasing the risk of injury.
Page 141 Seating and Safety Restraints Children and air bags For additional important safety information, read all information on safety restraints in this guide. Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position.
Page 142 Seating and Safety Restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 143: Child Restraints
Seating and Safety Restraints The diagnostic module monitors its own internal circuits and the supplemental air bag electrical system warning (including the impact sensors), the system wiring, the air bag system readiness light, the air bag back up power and the air bag ignitors. Determining if the system is operational The SRS uses a readiness light in the instrument cluster to indicate the condition of the system.
Page 144 To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all applicable Federal motor vehicle safety standards. Belt-positioning booster seats raise the child and provide a shorter, firmer seating cushion that encourages safer seating posture and better fit of lap and shoulder belts on the child.
Page 145 Seating and Safety Restraints SAFETY SEATS FOR CHILDREN Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child. Carefully follow all of the manufacturer’s instructions with the safety seat you put in your vehicle.
Page 146 Seating and Safety Restraints Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage. For more information on top tether straps, refer to Attaching safety seats with tether straps.
Page 147 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
Page 148 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 149 Seating and Safety Restraints Installing child safety seats in the lap belt seating positions 1. Lengthen the lap belt. To lengthen the belt, hold the tongue so that its bottom is perpendicular to the direction of webbing while sliding the tongue up the webbing.
Page 150 Seating and Safety Restraints Tether strap anchors have been provided in your vehicle. The left side of the figure is the front of the vehicle. Second row seats 1. Position the child safety seat on the seat cushion. 2. Route the child safety seat tether strap over the back of the seat, under the head restraint, and between the head restraint posts.
Page 151 Seating and Safety Restraints 3. Grasp the tether strap and position it to the seat frame. 4. Rotate the tether strap. 5. Clip the tether strap to the seat tether slot bracket at the lower rear portion of the seatback.
Page 152 Seating and Safety Restraints If the tether strap is clipped incorrectly (as shown) the child safety seat may not be retained properly in the event of a collision. 6. Rotate the tether strap clip. 7. Refer to the instructions in this section under Installing child safety seats in combination lap and shoulder belt seating...
Page 153 Seating and Safety Restraints 8. Tighten the child safety seat tether strap according to the manufacturer’s instructions. Third row seats The third row seat child tether anchors are located on the bottom back side of the seat. Refer to Second row seats listed previously for installation instructions.
Page 154 Seating and Safety Restraints Attaching safety seats with LATCH (Lower Anchors and Tethers for CHildren) attachments for child seat anchors Some child safety seats have two rigid or webbing mounted attachments that connect to two anchors at certain seating positions in your vehicle. This type of child seat eliminates the need to use seat belts to attach the child seat.
Page 155 Seating and Safety Restraints The lower anchors for child seat installation are located at the rear section of the rear seat between the cushion and seat back. The LATCH anchors are below the locator symbols on the seat back. Follow the child seat manufacturer’s instructions to properly install a child seat with LATCH attachments.
Page 156: Driving
Driving STARTING Positions of the ignition 1. OFF/LOCK, shuts off the engine and all accessories/locks the steering wheel, gearshift lever and allows key removal. 2. ACC, allows the electrical accessories such as the radio to operate while the engine is not running.
Page 157 Driving Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately.
Page 158 Driving 5. Turn the key to 3 (ON) without turning the key to 4 (START). If there is difficulty in turning the key, firmly rotate the steering wheel left and right until the key turns freely. This condition may occur when: •...
Page 159 Driving Starting the engine Note: Whenever you start your vehicle, release the key as soon as the engine starts. Excessive cranking could damage the starter. 1. Turn the key to 4 (START) without pressing the accelerator pedal and release as soon as the engine starts.
Page 160: Brakes
Driving WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 161 Driving heard during this test. This is normal. If a malfunction is found, the ABS warning light will come on. If the vehicle has continuous vibration or shudder in the steering wheel while braking, the vehicle should be inspected by a qualified service technician. The ABS operates by detecting the onset of wheel lockup during brake applications and compensates for this...
Page 162 Driving Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. PUSH RELEASE The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the BRAKE ignition is turned ON) until the parking brake is released.
Page 163: Transmission Operation
Driving STEERING Your vehicle is equipped with power steering. Power steering uses energy from the engine to help steer the vehicle. To prevent damage to the power steering pump: • Never hold the steering wheel to the extreme right or the extreme left for more than a few seconds when the engine is running.
Page 164 Driving If your vehicle gets stuck in mud or snow it may be rocked out by shifting from forward and reverse gears, stopping between shifts, in a steady pattern. Press lightly on the accelerator in each gear. Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur.
Page 165 Driving R (Reverse) With the gearshift lever in R R N D 2 1 (Reverse), the vehicle will move backward. You should always come to a complete stop before shifting into and out of R (Reverse). N (Neutral) With the gearshift lever in the N R N D 2 1 (Neutral) position, the vehicle can be started and is free to roll.
Page 166 Driving If the O/D OFF indicator light is flashing on and off repeatedly when the vehicle is started or does not come on when the O/D OFF control is pressed, there may be a transaxle electronic system malfunction. You should contact your dealer as soon as possible or damage to the transaxle could occur.
Page 167 Driving 1 (First) Use 1 (First) for when added engine R N D 2 1 braking is desired when descending steep hills. The automatic transaxle will shift to the proper gear to ascend any grade without any need to shift to 1 (First). Do not go faster than 56 km/h (35 mph) when in this gear.
Page 168: Vehicle Loading
Driving DRIVING THROUGH WATER Do not drive quickly through standing water, especially if the depth is unknown. Traction or brake capability may be limited and if the ignition system gets wet, your engine may stall. Water may also enter your engine’s air intake and severely damage your engine.
Page 169 Driving • Maximum Trailer Weight Rating: Maximum weight of a trailer the vehicle is permitted to tow. The maximum trailer weight rating is determined by subtracting the vehicle curb weight for each engine/transmission combination, any required option weight for trailer towing and the weight of the driver from the GCWR for the towing vehicle.
Page 170: Trailer Towing
Driving Calculating the load your vehicle can carry/tow 1. Use the appropriate maximum gross combined weight rating (GCWR) chart to find the maximum GCWR for your vehicle type and whether it’s equipped with a trailer tow option. 2. Weigh your vehicle as you customarily operate the vehicle without cargo.
Page 171 Driving • Thoroughly prepare your vehicle for towing. Refer to Preparing to tow in this chapter. • Use extra caution when driving while trailer towing. Refer to Driving while you tow in this chapter. • Service your vehicle more frequently if you tow a trailer. Refer to the severe duty schedule in the scheduled maintenance guide.
Page 172 Driving Hitches For towing trailers up to 907 kg (2 000 lb), use a weight carrying hitch and ball which uniformly distributes the trailer tongue load through the underbody structure. For towing trailers up to 1 588 kg (3 500 lb) use a frame-mounted weight distributing hitch which transfers a portion of the trailer tongue load to the front axle system.
Page 173 Driving Driving while you tow When towing a trailer: • Ensure that you turn off your speed control. The speed control may shut off automatically when you are towing on long, steep grades. • Consult your local motor vehicle speed regulations for towing a trailer. •...
Page 174: Recreational Towing
Driving RECREATIONAL TOWING Follow these guidelines for your specific powertrain combination to tow your vehicle with all four wheels on the ground (such as behind a recreational vehicle). These guidelines are designed to ensure that your transmission is not damaged due to insufficient lubrication. ALL FRONT WHEEL DRIVE (FWD) VEHICLES An example of recreational towing is towing your vehicle behind a motorhome.
Page 175: Roadside Emergencies
Roadside Emergencies GETTING ROADSIDE ASSISTANCE To fully assist if you should have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: • 24–hours, seven days a week •...
Page 176 In the United States, this card is found in the Owner Guide portfolio in the glove compartment in Ford vehicles and is mailed to you if you own a Mercury or Lincoln. In Canada, the card is found in the Roadside Assistance book in the glove compartment.
Page 177: Hazard Flasher Switch
Roadside Emergencies HAZARD FLASHER Use only in an emergency to warn traffic of vehicle breakdown, approaching danger, etc. The hazard flashers can be operated when the ignition is off. • The hazard lights control is located on the instrument panel. HAZARD •...
Page 178 Roadside Emergencies FUEL FUEL PUMP SHUT-OFF SWITCH RESET The fuel pump shut-off switch is a device intended to stop the electric fuel pump when your vehicle has been involved in a substantial jolt. After a collision, if the engine cranks but does not start, the fuel pump shut-off switch may have been activated.
Page 179: Fuses And Relays
— Green Green Green Pink Pink — — Orange Green Green — — — — Blue — Yellow — — — Brown — — Natural — Black For fuses greater than 80A, please see your Ford or Lincoln Mercury Dealer.
Page 180 Roadside Emergencies Passenger compartment fuse panel The fuse panel is located below and to the left of the steering wheel by the brake pedal. Remove the panel cover to access the fuses. To remove a fuse use the fuse puller tool provided on the fuse panel cover.
Page 181 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Tail Lamp Rear Exterior Lamps Air Bag Airbag Diagnostic Monitor Audio Radio, Rear Radio Control, CD Changer Eng Cont Powertrain Control Module, Oxygen Sensors Room Lamp Interior Lamps Mirror 7.5A Smart Entry Control (SEC),...
Page 182 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description A/C Cont 7.5A Electronic Automatic Temperature Control (EATC) Module, A/C Relay, Front Climate Control Panel Electron Transmission Control, Lighting Control Module, ABS Control Module, Smart Entry Control (SEC)/Timer Module Rear Defog Rear Window Defrost Front Blower...
Page 183 Roadside Emergencies If the battery has been disconnected and reconnected, refer to the Battery section of the Maintenance and specifications chapter. USE SPECIFIED FUSES OR FUSIBLE LINKS ONLY 7.5A 7.5A HORN LAMP 100A 140A 7.5A FUEL MAIN PUMP ECCS JOINT CONN. RAD FAN RAD FAN RAD FAN...
Page 184 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 10A* Generator 20A* ABS Control Module — — Not Used H/L RH 15A* Lighting Control Module HORN 15A* Horn Relay — — Not Used H/L LH 15A* Lighting Control Module —...
Page 185 Roadside Emergencies Relay box The relay box is located in the engine compartment in front of the battery. The relays are coded as follows: Relay location Description Start Inhibit Relay Fuel Pump Relay Bulb Check Relay Fog Lamp Anti-theft Relay Horn Relay A/C Relay...
Page 186: Changing Tires
Roadside Emergencies CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily. Instead, gradually decrease your speed. Hold the steering wheel firmly and slowly move to a safe place on the side of the road. Temporary spare tire information Your vehicle may have a temporary or conventional size spare tire.
Page 187 Roadside Emergencies Removing the jack and tools 1. Lift the 3rd row seat cushion. 2. Remove the jack assembly from the bag under the seat. Removing the spare tire 1. Open the liftgate, locate the U-shaped slits in the carpet, and flip up the piece of carpet to expose the hex nut.
Page 188 Roadside Emergencies Stowing the spare tire 1. Lay the tire on the ground with the interior side facing up. 2. Install the retainer through the wheel center and slide the wheel under the vehicle. 3. Turn the wrench clockwise until the tire is raised to its original position underneath the vehicle.
Page 189 Roadside Emergencies 1. Park on a level surface, activate hazard flashers and set parking brake. PUSH RELEASE 2. Place gearshift lever in P (Park), turn engine OFF, and block the diagonally opposite wheel. 3. Remove the spare tire and jack assembly.
Page 190: Jump Starting
Roadside Emergencies 7. Turn the jack handle clockwise until the wheel is completely off the ground. To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack.
Page 191 Roadside Emergencies Preparing your vehicle When the battery is disconnected or a new battery is installed, the transmission must relearn its adaptive strategy. As a result of this, the transmission may shift firmly. This operation is considered normal and will not affect function or durability of the transmission. Over time, the adaptive learning process will fully update transmission operation to its optimum shift feel.
Page 192 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery.
Page 193 Roadside Emergencies 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system. Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped.
Page 194 Roadside Emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2.
Page 195 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 196: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.
Page 197: Customer Assistance
Ford Customer Relationship Center. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 198 P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Relationship Center: • Your telephone number (home and business).
Page 199 5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Please contact your dealer for further information. Since this information is subject to...
Page 200: The Dispute Settlement Board
What kinds of cases does the Board review? Unresolved warranty repair concerns or vehicle performance concerns as on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written new vehicle warranty are eligible for review, except those involving: •...
Page 201 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
Page 202 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 203: Utilizing The Mediation/Arbitration
UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 204: Ordering Additional Owner's Literature
If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 205 Customer Assistance IN CALIFORNIA (U.S. ONLY) California Civil Code Section 1793.2(d) requires that, if a manufacturer or its representative is unable to repair a motor vehicle to conform to the vehicle’s applicable express warranty after a reasonable number of attempts, the manufacturer shall be required to either replace the vehicle with one substantially identical or repurchase the vehicle and reimburse the buyer in an amount equal to the actual price paid or payable by the consumer (less a reasonable allowance for consumer...
Page 206: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (202–366–0123 in the Washington D.C.
Page 207: Cleaning
Detail Wash (ZC-3–A), which is available from your authorized Ford, Lincoln or Mercury dealer. Always use a clean sponge or carwash mitt with plenty of water for best results. Dry the vehicle with a chamois or soft terry cloth towel in order to eliminate water spotting.
Page 208 Minor scratches or paint damage from road debris may be repaired using the Ultra Touch Prep and Finishing Kit (F7AZ-19K507–BA), which is available at your authorized Ford, Lincoln or Mercury dealer. This kit contains: • Lacquer Touch-Up Paint (ALBZ-19500–XXXXA) •...
Page 209 Cleaning CLEANING THE ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • The engine must be cool to the touch before spraying with water. • Never spray a hot engine with cold water, as damage to the engine block or engine components may occur.
Page 210 Clean the outside of the windshield or rear window with a non-abrasive cleaner such as Ultra Clear Spray Glass Cleaner (E4AZ-19C507–AA), available from your authorized Ford, Lincoln or Mercury dealer. If after cleaning the glass surface, the water sheets from the glass (e.g., does not...
Page 211 Vinyl Cleaner (F2AZ-19521–WA). Dry the area with a soft cloth. It is recommended that you use the Deluxe Leather Care Kit (F8AZ-19G253–AA), available from your authorized Ford, Lincoln or Mercury dealer. The mild cleaner and special pad available in the kit...
Page 212: Underbody Preservation
CLEANING AND MAINTAINING THE SAFETY BELTS Clean the safety belts with Extra Strength Upholstery Cleaner (E8AZ-19523–AA), available from your authorized Ford, Lincoln or Mercury dealer. Do not use bleach, dye or any other solvent to clean the belts, as these actions may weaken the belt webbing.
Page 213 Cleaning FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 214: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 215: Hood
Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood.
Page 216: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 3.3L V6 engine 1. Power distribution box 2. Brake fluid reservoir 3. Air filter assembly 4. Battery 5. Relay box 6. Engine oil filler cap 7. Engine oil dipstick 8. Windshield washer fluid reservoir 9.
Page 217: Engine Oil
In very cold weather, do not fill the reservoir all the way. Only use a washer fluid that meets Ford specification ESR-M17P5–A. Refer to Lubricant specifications in this chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 218 Maintenance and Specifications 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan. 3. Set the parking brake and ensure the gearshift is securely latched in P. 4. Open the hood. Protect yourself from engine heat. 5.
Page 219 Motor oil displaying the API certification trademark will meet all requirements for your vehicle’s engine. Ford oil specification is WSS-M2C205–A. Do not use supplemental engine oil additives, oil treatments or engine treatments. They are unnecessary and could, under certain conditions, lead to engine damage which is not covered by your warranty.
Page 220: Battery
It is recommended that you replace the engine oil drain plug washer each time the engine oil is changed. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 221 Maintenance and Specifications When the battery is disconnected or a new battery installed, the transmission must learn its adaptive strategy. As a result of this, the transmission may shift firmly. This operation is considered normal and will fully update transmission operation to its optimum shift feel. Batteries normally produce explosive gases which can cause personal injury.
Page 222 Maintenance and Specifications • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. RECYCLE ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the mileage intervals listed in the scheduled maintenance guide.
Page 223 Use only Motorcraft Premium Engine Coolant VC-4–A (in Canada, Motorcraft CXC-8-B) or a premium engine coolant that meets Ford specification ESE-M97B44-A. • DO NOT USE Motorcraft Extended Life Engine Coolant VC-2 (or CXC-209 in Canada) (orange in color) meeting Ford specification WSS-M97B44–D.
Page 224 Maintenance and Specifications • DO NOT USE a DEX-COOL engine coolant or an equivalent engine coolant that meets Ford specification WSS-M97B44-D. • DO NOT USE alcohol or methanol antifreeze or any engine coolants mixed with alcohol or methanol antifreeze. • DO NOT USE supplemental coolant additives in your vehicle.
Page 225 Not all coolant recycling processes produce coolant which meets Ford specification WSS-M97B51–A1. Use of a recycled engine coolant which does not meet the Ford G05 specification may harm engine and cooling system components. Always dispose of used automotive fluids in a responsible manner.
Page 226: Fuel Information
Maintenance and Specifications • NEVER increase the coolant concentration above 60%. • Increased engine coolant concentrations above 60% will decrease the overheat protection characteristics of the engine coolant and may cause engine damage. • Refer to the chart on the coolant container to ensure the coolant concentration in your vehicle will provide adequate freeze protection at the temperatures in which you drive in the winter months.
Page 227 Maintenance and Specifications If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible personal injury.
Page 228 Maintenance and Specifications • Be particularly careful if you are taking “Antabuse” or other forms of disulfiram for the treatment of alcoholism. Breathing gasoline vapors, or skin contact could cause an adverse reaction. In sensitive individuals, serious personal injury or sickness may result. If fuel is splashed on the skin, promptly wash skin thoroughly with soap and water.
Page 229 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 230 Fuel Charter should be used when available. Ask your fuel supplier about gasolines that meet the World-wide Fuel Charter. In Canada, look for fuels that display the Auto Makers’ Choice logo. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality.
Page 231 Maintenance and Specifications Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components. If you have run out of fuel: • You may need to cycle the ignition from OFF to ON several times after refueling, to allow the fuel system to pump the fuel from the tank to the engine.
Page 232 Maintenance and Specifications The amount of usable fuel in the empty reserve varies and should not be relied upon to increase driving range. When refueling your vehicle after the fuel gauge indicates empty, you might not be able to refuel the full amount of the advertised capacity of the fuel tank due to the empty reserve still present in the tank.
Page 233 Maintenance and Specifications Keep a record for at least one month and record the type of driving (city or highway). This will provide an accurate estimate of the vehicle’s fuel economy under current driving conditions. Additionally, keeping records during summer and winter will show how temperature impacts fuel economy.
Page 234 Maintenance and Specifications Maintenance • Keep tires properly inflated and use only recommended size. • Operating a vehicle with the wheels out of alignment will reduce fuel economy. • Use recommended engine oil. Refer to Lubricant specifications in this chapter. •...
Page 235 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 236 Maintenance and Specifications engine. This decal identifies engine displacement and gives some tune up specifications. Please consult your Warranty Guide for complete emission warranty information. Readiness for Inspection/Maintenance (I/M) testing In some localities, it may be a legal requirement to pass an I/M test of the on-board diagnostics system.
Page 237 Maintenance and Specifications CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be...
Page 238 MAX. Do not fill above this line. 4. Use only a DOT 3 brake fluid certified to meet Ford specification ESA-M6C25–A. Refer to Lubricant specifications in this chapter. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 239 Maintenance and Specifications 1. Drive the vehicle 30 km (20 miles) or until it reaches normal operating temperature. 2. Park the vehicle on a level surface and engage the parking brake. 3. With the parking brake engaged and your foot on the brake pedal, start the engine and move the gearshift lever through all of the gear ranges.
Page 240: Air Filter(S)
Maintenance and Specifications Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used. The type of fluid used is normally indicated on the dipstick and also in the Lubricant specifications section in this chapter. Use of a non-approved automatic transmission fluid may cause internal transaxle component damage.
Page 241 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it.
Page 242 Maintenance and Specifications Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 243 Maintenance and Specifications SERVICING YOUR TIRES Checking the tire pressure • Use an accurate tire pressure gauge. • Check the tire pressure when tires are cold, after the vehicle has been parked for at least one hour or has been driven less than 5 km (3 miles).
Page 244 Make sure that all replacement tires are of the same size, type, load-carrying capacity and tread design (e.g., “All Terrain”, etc.), as originally offered by Ford. Failure to follow these precautions may adversely affect the handling of the vehicle and make it easier for the driver to lose control and roll over.
Page 245: Part Numbers
Maintenance and Specifications SNOW TIRES AND CHAINS Snow tires must be the same size and grade as the tires you currently have on your vehicle. The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains.
Page 246: Refill Capacities
Fill to line on reservoir fluid Washer Concentrate Use Motorcraft Premium Engine Coolant (green in color). DO NOT USE Ford Extended Life Engine Coolant (orange in color). Refer to Adding engine coolant, in the Maintenance and Specifications chapter. LUBRICANT SPECIFICATIONS Item...
Page 247 Washer Concentrate DO NOT USE Motorcraft Extended Life Engine Coolant VC-2 (CXC-209 in Canada) meeting Ford specification WSS-M97B44–D (orange in color). Refer to Adding engine coolant in this chapter. Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle.
Page 248: Engine Data
Maintenance and Specifications ENGINE DATA Engine 3.3L V6 engine Cubic inches Required fuel 87 octane Firing order 1-2-3-4-5-6 Spark plug gap 1.0-1.1 mm (0.039-0.043 inch) Ignition system Distributor ignition system Compression ratio 8.9:1 This ignition system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise.
Page 249 Maintenance and Specifications...
Page 250: Certification Label
Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety MFD. BY FORD MOTOR CO. DATE: XX/XX GVWR: XXXXLB/ XXXXKG Administration Regulations require FRONT GAWR: XXXXLB/ XXXXKG REAR GAWR: XXXXLB/ XXXXKG WITH PXXX/XXXXXXX TIRES WITH PXXX/XXXXXXX TIRES that a Certification label be affixed XXXX.XXX...
Page 251: Accessories
FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of genuine Ford accessories are available for your vehicle through your local authorized Ford, Lincoln, Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 252 Accessories Travel equipment Ash cup Auto headlamps with daytime running lights (DRL) Cargo box (rooftop luggage box) Cigarette lighter element Console Framed luggage covers HomeLink (in sun visor) Molded running boards Removable luggage basket Running boards, child step Soft luggage cover Track rider bars Track rider bar adaptors Trailer hitch (Class II)
Page 253 (Citizens band [CB] transceivers, garage door openers and other transmitters with outputs of five watts or less will not ordinarily affect your vehicle’s operation.) • Ford cannot assume responsibility for any adverse effects or damage that may result from the use of such equipment.
Page 254: Index
Index Axle lubricant specifications ..246 Accessory delay ......88 Air bag supplemental restraint system ......139 Battery ........220 and child safety seats ....141 acid, treating emergencies ..220 description ......139 charging system disposal ........143 warning light ......13 driver air bag ......141 jumping a disabled battery ..190 indicator light ....13, 143 maintenance-free ....220 operation .........141...
Page 255 Engine ........248 Cruise control check engine/service (see Speed control) ....91 engine soon light ......11 cleaning ........209 Customer Assistance ....175 coolant ........222 Ford accessories for idle speed control ....220 your vehicle ......213 lubrication Ford Extended specifications ....246, 248 Service Plan ......199...
Page 256 Index refill capacities ......246 service points ......216 starting after a collision ..178 Garage door opener ....96 Engine oil ........217 Gas cap (see Fuel cap) ....228 checking and adding ....217 Gas mileage dipstick ........217 (see Fuel economy) ....231 filter, specifications ..219, 245 Gauges ........15–16 recommendations ....219 engine coolant temperature...
Page 257 Index Heating bulb replacement heating and air conditioning specifications chart ....78 system .........57, 63 cargo lamps .......75 rear seat controls ....60, 70 fog lamps ........74 headlamps .........74 HomeLink universal headlamps, flash to pass ..75 transceiver (see instrument panel, dimming ..75 Garage door opener) ..96–100 interior lamps ......76 Hood ..........215...
Page 258 Index panic alarm ......112 replacement/additional Message center ....100–102 transmitters ......113 replacing the batteries ...113 Mirrors .........86 heated ........90 Roof rack ........109 side view mirrors (power) ..89 Moon roof ........96 Motorcraft parts ....231, 245 Safety belts (see Safety restraints) ....131–134, 136 Safety defects, reporting ..206 Octane rating ......230 Safety restraints ....131–136...
Page 259 Index Steering wheel controls ......85, 91, 95 tilting .........85 Vehicle dimensions ....248 Vehicle Identification Number (VIN) ..........250 Vehicle loading ......168 Tachometer .........19 Ventilating your vehicle ...160 Tires ......186, 241–243 changing ......186, 188 checking the pressure ....243 replacing ........244 Warning chimes ......15 rotating ........243 snow tires and chains ....245 Warning lights (see Lights) ..10...

Ford Mercury User Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Accessories

Index

Quick Links

Table of Contents

Related Manuals for Ford Mercury

Summary of Contents for Ford Mercury

Table of Contents
