FEATURE SET

1
7 8
1. 48V: Phantom
recessed to prevent accidental turn-on
which could damage more sensitive
equipment. An LED illuminates when
phantom power is active.
2. MUTE: Use to turn off all four outputs
so that you can change the mic or DI
without noise. Saves having to change
your preamp or mixer settings when re-
confi guring.
3. OUTPUT SELECTORS 1~4: 'Radio'
style switches
the current output off when another
selector switch is depressed. Helps to
streamline the comparison process.
An LED indicator displays the active
output.
4. LIFT 1~4: Disconnects the ground at
the XLR output (pin-1) to help eliminate
hum and buzz caused by ground loops.
5. BOOK- END DESIGN: Creates a
protected zone to prevent damage to
Radial Engineering Ltd.
2 3
power switch is
automatically turn
4
9
the front panel controls.
6. 14 GAUGE
construction eliminates stress on the
PCB and provides excellent shielding
against magnetic fi elds and RF which
could otherwise introduce noise.
7. CABLE CLAMP: A handy
clamp prevents
disconnection.
8. POWER ADAPTER: Connection for
the included 15VDC Radial power
supply.
9. OUTS 1~4: Four fully insulated XLR-M
outputs are used to connect to your
various preamps or audio destinations.
10. INPUT: Balanced mic/line input is used
to connect microphones, direct boxes
or other audio devices to the Cherry
Picker.
1
5 6
10
STEEL: Heavy-duty
accidental power
Cherry Picker™
®
cable
