iiNet ADSL2+ Modem User Manual

Broadband voice modem/router
Hide thumbs

Advertisement

Quick Links

ADSL2+ Modem User Manual
Broadband Voice Modem/Router

Advertisement

loading
Need help?

Need help?

Do you have a question about the ADSL2+ Modem and is the answer not in the manual?

Questions and answers

Related Manuals for iiNet ADSL2+ Modem

Summary of Contents for iiNet ADSL2+ Modem

  • Page 1 ADSL2+ Modem User Manual Broadband Voice Modem/Router...

  • Page 2: Table Of Contents

    1. Introduction ........ Thank you for purchasing the Belkin ADSL2+ Modem. This manual applies to both the 4 Port Wired (FPI242ENau) and the 4 Port Wireless (FPI242EGau) VoIP ADSL2+ Modem Routers.

  • Page 3: Product Overview

    Product Overview Product Overview Belkin Broadband Voice Modem/Router - 4 Port Built-in Dynamic Host Configuration Protocol (DHCP) Part # F1PI242ENau (Wired) Built-In Dynamic Host Configuration Protocol (DHCP) on-board makes for the easiest possible connection of a network. The DHCP server will assign IP addresses to each computer automatically so there is Compatibility with both PC’s and no need for a complicated networking setup.
  • Page 4 Product Overview Product Overview Product Overview Belkin Broadband Voice Modem with Wireless Router - 4 Port QoS (Quality of Service) limits the traffic being sent from the modem Part # F1PI242EGau (Wireless) (upstream) when using VoIP at the same time. If QoS is disabled, the quality of the VoIP call can suffer due to excessive traffic from another source, such as a PC.

  • Page 5: Knowing Your Voip Router

    Knowing Your VoIP Router Knowing Your VoIP Router The Modem is designed to be placed on a desktop. All of the cables 3. WLAN Status LED (F1PI242EGau only) exit from the rear of the Modem for better organisation and utility. The The WLAN status LED shows you when VoIP Router’s wireless is enabled.
  • Page 6 Knowing your VoIP Router Knowing your VoIP Router phone call. 2. LAN Ports The Ethernet port is RJ45, 0/00 auto-negotiation. Connect your net On - VoIP activity, i.e. phone is in use work-enabled computers or any networking devices to this port. On - Flashing, Incoming call, i.e., phone is ringing 3.

  • Page 7: Connecting And Configuring Your Router

    Connecting and Configuring your Router Connecting and Configuring your Router Step 1. Find a suitable location connect your PC or other network equipment to the hub or switch. When inserting an RJ-45 connector, be sure the tab on the connector The VoIP Router can be positioned at any convenient location in your clicks into position to ensure that it is properly seated.
  • Page 8 Connecting and Configuring your Router Connecting and Configuring your Router Step 1. How to log into the Router Making Configuration Changes After you have configured TCP/IP on a client computer, use a web Configurable parameters have a dialog box or a drop-down list. Once browser to configure the VoIP ADSL Wireless Router.

  • Page 9: Advanced Setup Method

    Connecting and Configuring your Router Advanced Setup Method Clicking the Home icon returns you to the home page. The Main Menu links are used to navigate to other menus that display configuration parameters and statistics. Making Configuration Changes Configurable parameters have a dialog box or a drop-down list. Once a configuration change has been made on a page, click the “SAVE SETTINGS”...
  • Page 10 Advanced Setup Method Advanced Setup Method Commonly Requested Features Port Forwarding (Page 52) Noted in this section is a quick reference guide to the most commonly Some programs will require you to direct certain port numbers to your requested advanced features and should save you the time of computer in order to bypass the built in Firewall.
  • Page 11 Advanced Setup Method Advanced Setup Method The LAN Menu also has 2 sub-menus: Firewall (Page 52) • VLAN • Configures a variety of security and specialized functions including: Access Control, URL blocking, Internet access control This menu allows you to set the VLAN rules for the other ports scheduling, Intruder detection, and DMZ.
  • Page 12 Advanced Setup Method Advanced Setup Method USB (Page 80) System • You can plug-in your USB hard drive or memory stick and share these resources to your home network. Time Settings Tools (Page 83) • Contains options to back up and restore the current configuration, restore all configuration settings to the factory defaults, update system firmware, or reset the system each under its own menu.
  • Page 13 Advanced Setup Method Advanced Setup Method Passwords can contain from  to2 alphanumeric characters which Note: If you check “Enabled” and specify an IP address of 0.0.0.0, are case sensitive. any host can manage the VoIP Router. Note: If your password is lost, or you cannot gain access to the user interface, press the reset button (colored blue) on the rear For remote management via a WAN IP address you need to panel (holding it down for at least 20 seconds) to restore the factory...
  • Page 14 Advanced Setup Method Advanced Setup Method Specify the WAN connection parameters provided by your Internet Service Provider (ISP). The VoIP Router can be connected to your ISP in one of the following ways: • ATM PVC • Clone MAC ATM PVC The VoIP Router uses ATM as its WAN interface.
  • Page 15 Advanced Setup Method Advanced Setup Method • LLC: Point-to-Point Protocol over ATM Logical Link Control Parameter Description (LLC) allows multiple protocols running over one virtual circuit Protocol (using slightly more overhead). Disable: Disables the connection • • 1483 Bridging: Bridging is a standardized layer 2 technology. It Protocol: Protocol used for the connection is typically used in corporate networks to extend the physical reach of a single LAN segment and increase the number of...
  • Page 16 Advanced Setup Method Advanced Setup Method Parameter Description Clone MAC Address Encapsulation Clicking on the Clone MAC Address brings up the following screen. Shows the packet encapsulation type. Packet encapsulation specifies how to handle multiple protocols at the ATM transport layer. •...
  • Page 17 Advanced Setup Method Advanced Setup Method Parameter Description Use the LAN menu to configure the LAN IP address and to enable the LAN IP DHCP server for dynamic client address allocation. IP Address: The IP address of the VoIP Router IP Subnet Mask: The subnet mask of the VoIP Router Host Name: If your ISP requires a hostname specified enter here, otherwise leave blank...
  • Page 18 Advanced Setup Method Advanced Setup Method VLAN Description: detail description of the VLAN IP Address: IP address of the VLAN virtual interface on the gateway Subnet Mask: subnet mask of the VLAN virtual interface VLAN Table: In this table you can click on the “ADD VLAN” button to NAT Domain: NAT addressing domain to define the NAPT operation of add a “VLAN”...
  • Page 19 Advanced Setup Method Advanced Setup Method VLAN Access Control: Wireless Settings (F1PI242EGau only) In this table you can enable or disable the communication between Check Enable or Disable and click “SAVE SETTINGS.” This will turn the VLAN bindings by ticking (enable) or un-ticking (disable) the the wireless function on or off and enable or disable wireless clients corresponding name in the table.
  • Page 20 Advanced Setup Method Advanced Setup Method Access Control Using the Access Control functionality, you can specify which PCs can wirelessly connect to the access point. Each PC has a unique identifier known as a Medium Access Control (MAC) address. With MAC filtering enabled, only the computers whose MAC address you have listed in the filtering table may connect to the VoIP Router.
  • Page 21 Advanced Setup Method Advanced Setup Method Security Security Client Support Implementation Considerations It is important to be aware of security issues, especially when using WEP: Built-in support on all 802.b and 802.g devices wireless. You can configure your security settings on this page. Do not WPA: Requires WPA-enabled system and network card.
  • Page 22 Advanced Setup Method Advanced Setup Method Parameter Description WEP Mode: You can choose 64-bit or 28-bit encryption. (Default: 64Bit) Key Entry Method: You can choose HEX or ASCII (Default/ Recommended: HEX) Key Provisioning: Select static key or dynamic key. (Default/ Recommended: Static) Static WEP Key: You may manually enter the keys or automatically generate...
  • Page 23 Advanced Setup Method Advanced Setup Method Wireless Distribution System (WDS) provides a means to extend the range of a Wireless Local Area Network (WLAN). WDS allows an Access Point (AP) to establish a direct link to other APs and allows stations to roam freely within the area covered by the WDS.
  • Page 24 Advanced Setup Method Advanced Setup Method Using this feature, you can put PCs with public IPs and PCs with Address Mapping private IPs in the same LAN area. If you configure the Port Forwarding settings, remote users accessing services such as web or FTP at your local site via public IP addresses can be automatically redirected to local servers configured with private IP addresses.
  • Page 25 Advanced Setup Method Advanced Setup Method Example: Trigger Trigger Public Port Public Comment Type Port Type 62 62 Battle.net 28800 200-2400 MSN Game Zone For a full list of ports and the services that run on them, see www.iana.org/assignments/port-numbers. NAT Mapping Table Specify the public port number normally associated with an application in the Trigger Port field.
  • Page 26 Advanced Setup Method Advanced Setup Method • Local Port - local (LAN) host’s port number for the flow Gateway: Displays the WAN IP address of the gateway to the remote network • Pseudo IP - translated IP address for the flow Configure: Allows you to modify or delete configuration settings •...
  • Page 27 Advanced Setup Method Advanced Setup Method If this does not match what is expected, the packet will be discarded. This method provides very little security as it is possible to learn the authentication key by watching RIP packets. MD5: An algorithm that is used to verify data integrity through the creation of a 28-bitmessage digest from data input (which may be a message of any length) that is claimed to be as unique to that specific data as a fingerprint is to a specific individual.
  • Page 28 Advanced Setup Method Advanced Setup Method The VoIP Router’s firewall enables access control of client PCs, Parameter Description blocks common hacker attacks, including IP Spoofing, Land Attack, Flags: Indicates the route status: Ping of Death, IP with zero length, Smurf Attack, UDP port loopback, C = Direct connection on the same subnet Snork Attack, TCP null scan, and TCP SYN flooding.
  • Page 29 Advanced Setup Method Advanced Setup Method area network (LAN). The MAC Filtering Table allows the VoIP Router MAC Filter to enter up to 2 MAC addresses that are not allowed access to the Use this page to block access to your network using MAC addresses WAN port.
  • Page 30 Advanced Setup Method Advanced Setup Method You may filter Internet access for local clients based on rules. Each access control rule may be activated at a scheduled time. Define the schedule on the Schedule Rule page, and apply the rule on the Access Control page.
  • Page 31 Advanced Setup Method Advanced Setup Method number of active sessions, and provides the ability to detect and those types marked with a check in the Stateful Packet Inspection section at the top of the screen. prevent certain types of network attacks such as Denial-of-Service (DoS) attacks.
  • Page 32 Advanced Setup Method Advanced Setup Method Maximum incomplete TCP/UDP sessions number from same host: SNMP Maximum half-open fragmentation packet number from same host Incomplete TCP/UDP sessions detect sensitive time period: Length of time before an incomplete TCP/UDP session is detected as incomplete Maximum half-open fragmentation packet number from same host: Maximum number of incomplete TCP/UDP sessions from the same...
  • Page 33 Advanced Setup Method Advanced Setup Method Use the SNMP configuration screen to display and modify parameters Community: A community string (password) specified for trap for the Simple Network Management Protocol (SNMP). A computer management. Enter a word, something other than public or private, attached to the network, called a Network Management Station to prevent unauthorized individuals from reading information on your (NMS), can be used to access this information.
  • Page 34 Advanced Setup Method Advanced Setup Method • T.4 Issue 2 Operation Data/Defect Indication: • G.992. (G.DMT) Noise Margin Upstream: Minimum noise margin upstream • G.922.2 (G.Lite) Downstream: Minimum noise margin downstream • G.922. (ADSL2) Output Power: Maximum fluctuation in the output power •...
  • Page 35 VoIP Router on their system so that your can call friends, family and business associates. Your Belkin/iiNet modem comes pre-configured for the iiNet VoIP service. iiNet and Belkin will only provide support for use with the iiNet VoIP service.
  • Page 36 Advanced Setup Method Advanced Setup Method redirect servers receive requests from a client and decide where to SIP is a peer-to-peer protocol. The peers in a session are called User send these requests. Proxy servers can provide functions such as Agents (UAs).
  • Page 37 Advanced Setup Method Advanced Setup Method (Default: 50 ~ 250 milliseconds) Caller ID Mode Telephony Tone Country Setting: Select the country Use DTMF Caller ID Mode. Enabling this option enabled the Dual Tone, Multi-Frequency (touch tone) mode for Caller ID. Voice Codec Configuration: Set the voice codecs Available Codecs: List of available codecs Inter Digit Delay...
  • Page 38 Advanced Setup Method Advanced Setup Method VoIP Status and Call Logs Parameter Description View the VoIP status for both FXS ports on this page. Click “Refresh” to update this page. Port Type Displays the port type, i.e., FXS. Received Call Number of received calls.
  • Page 39 Advanced Setup Method Advanced Setup Method Traffic Mapping With converging voice and data, it is imperative to establish Quality of Service (QoS) parameters to appropriately allocate bandwidth. QoS will only monitor and limit upstream traffic. QoS Settings To ensure optimum voice quality, your VoIP Router should prioritize voice over data packets.
  • Page 40 Advanced Setup Method Advanced Setup Method This page is for user to specify a classify rule. DDNS Rule Name: Assign a Name to the rule Traffic Type: Choose a Traffic type foe the rule, or click on “Advanced Config” for more advanced options Map to Forwarding Group: Choose which QOS group you wish to have the rule mapped to, which determines how much bandwidth is to be allocated with this...
  • Page 41 Advanced Setup Method Advanced Setup Method default setting is “Hotspot”. The SSID can be easily changed to suit your name or location settings. For example, the name of “World” would show as TOMIZONE_World Channel Indicates the channel setting for this device. By default the channel is set to 6.
  • Page 42 Advanced Setup Method Advanced Setup Method If you see some partitions can not be selected in the partition list Safe Clients table, check the FTP Server partition share status to make sure you You can add the MAC address of certain PCs that will be granted did not share more than 4 disk partitions at the same time.
  • Page 43 Advanced Setup Method Advanced Setup Method Configuration Tools Tools Use the Tools menu to back up the current settings, to restore previously saved settings, or to restore the factory default settings. Advanced Setup | USB | Web Server This function allow you to share your mass storage through HTTP protocol.
  • Page 44 Advanced Setup Method Advanced Setup Method Reset Perform a reset from this page. Download the file to your hard drive from the Belkin web site or from another source. Then click Browse... to find the file on your computer. Select the firmware file and click “Open.” Click “Save Settings” to start the upgrade process.
  • Page 45 Advanced Setup Method Advanced Setup Method DHCP Client LOG DHCP Client Log: Displays information on DHCP clients on your network. The security log may be saved to a file by clicking “Save” and choosing a location. The following items are included on the Status screen: Security LOG Security Log: Displays information about attempts to access ports Parameter Description...

  • Page 46: Appendices

    Appendices Appendices Appendix A1 Troubleshooting After completing hardware setup by connecting all your network devices, you should automatically be able to connect to the VoIP ADSL Wireless Router by entering 0... into your Internet browsers address bar. Should this not work please first determine how your ISP issues your IP address.
  • Page 47 Appendices Appendices Select “Use the following DNS server addresses” Enter the IP address for the VoIP Router in the Preferred DNS server field. This automatically relays DNS requests to the DNS server(s) provided by your ISP. also, add a specific DNS server of your ISP into the Alternate DNS Server field and click OK to close the dialog boxes For future reference you may record the configured information in...
  • Page 48 Appendices Appendices Double Click “Network” If “Using DHCP Server” is already selected in the configure field, your computer is already configured for DHCP. If not, select this option. Your computer is now configured to connect to the VoIP Router. Your new settings are shown in the TCP/IP tab. Verify that your IP Address is now 0...xxx, your Subnet Mask is 255.0.0.0 Configuring Your Macintosh Computer or 255.255.255.0 and your Default Gateway is 0....
  • Page 49 Appendices Appendices Internet Explorer Appendix A2 Troubleshooting Open Internet Explorer and click the Stop button. Click This section describes common problems you may encounter and Explorer/Preferences. possible solutions to them. The VoIP Router can be easily monitored through panel indicators to identify problems. In the Internet Explorer Preferences window, under Network, select Proxies.
  • Page 50 Appendices Appendices Network Connection Appendix B Cables Problems Ethernet Cable Cannot ping the • Verify that the IP addresses are properly Caution: Do not plug a phone jack connector into an RJ-45 port. VoIP Router from configured. For most applications, you For Ethernet connections, use only twisted-pair cables with RJ-45 the attached LAN, should use the VoIP Router’s DHCP function...
  • Page 51 Appendices Appendices Appendix C Specifications FXO Interface  FXO port Standards Compliance FXS Interface CE Mark 2 FXS ports Emissions Indicator Panel FCC Class B, VCCI Class B Industry Canada Class B Line, Phone -2, VoIP, USB (FPI20ENau only), LAN -4 (4 port EN55022 (CISPR 22) Class B FPI24ENau &...

  • Page 52: Glossary

    Glossary Glossary repeaters and implementations that operate on fiber, thin coax Glossary-1 and twisted-pair cable 10BASE-T Fast Ethernet IEEE 802. specification for 0 Mbps Ethernet over two pairs of A 00 Mbps network communication system based on Ethernet Category , 4, or 5 UTP cable and the CSMA/CD access method 100BASE-TX Full Duplex...
  • Page 53 Glossary Glossary-2 IEEE 802.3x Defines Ethernet frame start/stop requests and timers used for flow control on full-duplex links Local Area Network (LAN) A group of interconnected computer and support devices LAN Segment Separate LAN or collision domain Light emitting diode used or monitoring a device or network condition Local Area Network A group of interconnected computers and support devices.
  • Page 55 Support 13 22 58 support@iinet.net.au iiNet Business Support 13 24 49 bizsupport@iinet.net.au P5004au-B...

This manual is also suitable for:

F1pi242egau
