Mechanical Part List - Spectral Audio ProTone Service Manual

S1 E103-SD1CBE
S2 E201-SD1CBE
S3 E103-SD1CBE
S4 PVA1-EE
S5 PVA1-EE
S6 PVA1-EE
S8 E101-SD1CBE
S9 E101-SD1CBE
S10 PVA1-EE
S11 PVA1-EE
S12 PVA1-EE
S13 E103-SD1CBE
S14 PVA1-EE
S15 PVA1-OA
SW1 56P36-01-1-06N
J12 Connector 18 pole (Socket)

8 Mechanical part list

Pcs. Part
1 Front Panel
1 Chassis
1 Backside
4 Screw M3 x 5mm with counter bore head black
5 Cylinder head screw M3 x 5mm black
1 Nut M3 for grounding
1 Washer for grounding
8 Sheet metal screw 2.9 x 6.5mm black
6 Sheet metal screw with counter bore head 2.9 x 22mm black
6 Spacer 14 mm
2 Spacer 25 mm metal with thread M3
1 Analog PCB assembled
1 Digital PCB assembled
6 Nuts for Phone Jack
19 Knobs 18 splines
1 Knob "D" Shape 1/8"
1 Inlet IEC Socket with Fuse Box
1 Fuse 250mA
1 Cable blue with thimbles 4.8mm
2 Cable brown with thimbles 4.8mm
1 Cable yellow-green with thimbles
1 Power switch 1 pole with 4.8mm terminals
Service Manual ProTone
1pole on-off-on Toggle Switch
2pole on-on Toggle Switch
1pole on-off-on Toggle Switch
1 pole on-off Push-Push Switch
1 pole on-off Push-Push Switch
1 pole on-off Push-Push Switch
1pole on-on Toggle Switch
1pole on-on Toggle Switch
1 pole on-off Push-Push Switch
1 pole on-off Push-Push Switch
1 pole on-off Push-Push Switch
1pole on-off-on Toggle Switch
1 pole on-off Push-Push Switch
1 pole on-off Momentary Switch
6 pole Rotary Switch
mounted on Solder Side
Page 20 of 20
C&K
C&K
C&K
ITT
ITT
ITT
C&K
C&K
ITT
ITT
ITT
C&K
ITT
ITT
Grayhill
© 1996-2001 Spectral Audio
