Spectral Audio ProTone Service Manual page 19

C60 1u
C61 1u
C62 1u
C63 1u
C64 1u
C65 1u
Semiconductors
Q2 BC 556 B
Q3 BC 546 B
Q9 BC 546 B
Q10 BF 245 B
Q11 BC 546 B
Q17 BC 556 B
Q18 BC 556 B
Q19 BC 546 B
Q20 BC 556 B
Q21 BC 546 B
Q22 BC 546 B
Q23 BC 546 B
Q24 BC 556 B
Q25 BC 556 B
Q26 BC 556 B
D7 1N4148
D8 1N4148
D9 1N4148
D10 1N4148
D11 1N4148
D12 1N4148
D14 1N4148
D15 1N4148
D16 1N4148
DL1 2.5 x 5mm
DL2 2.5 x 5mm
DL3 2.5 x 5mm
DL4 2.5 x 5mm
U11 TL 074 CN
U13 TL 074 CN
U14 TL 072 CN
U15 TL 074 CN
U16 CA 3046
U17 TL 074 CN
U18 XR 2208 CP
U20 LM 13700 N
U21 LM13700 N
U22 TL 074 CN
U23 TL 074 CN
U24 LM13700 N
U25 LM13700 N
U26 CD 4001 BCN
Various
Service Manual ProTone
Elko 2
Elko 2
Elko 2
Elko 2
Elko 2
Elko 2
Green Assemble with 8 mm spacer (Total 17mm)
Red Assemble with 8 mm spacer (Total 17mm)
Red Assemble with 8 mm spacer (Total 17mm)
Red Assemble with 8 mm spacer (Total 17mm)
Page 19 of 20
d=5
d=5
d=5
d=5
d=5
d=5
