Please read these instructions and make sure you understand them before using the machine.
Lire attentivement et bien assimiler le manuel d'utilisation avant d'utiliser la machine.
Lea detenidamente el manual de instrucciones y asegúrese de entender su contenido antes de utilizar la máquina.
Operator's manual
Manual d'utilisation
Manual de instrucciones
EN (2-30)
FR (31-60)
ES (61-90)

Advertisement

Table of Contents
loading

Related Manuals for Jonsered CC2128

Summary of Contents for Jonsered CC2128

  • Page 1 Operator’s manual EN (2-30) Manual d’utilisation FR (31-60) Manual de instrucciones ES (61-90) Please read these instructions and make sure you understand them before using the machine. Lire attentivement et bien assimiler le manuel d’utilisation avant d’utiliser la machine. Lea detenidamente el manual de instrucciones y asegúrese de entender su contenido antes de utilizar la máquina.

  • Page 2: Key To Symbols Symbols

    SYMBOL EXPLANATION Symbols This product is in accordance with applicable EC directives. WARNING: Clearing saws, brush- cutters and trimmers can be dan- Noise emission to the gerous! Careless or incorrect use environment according to the can result in serious or fatal European Community’s injury to the operator or others.

  • Page 3: Table Of Contents

    ....Starting and stopping ....Jonsered has a policy of continuous product WORKING TECHNIQUES development and therefore reserves the right General working instructions .

  • Page 4: What Is What

    WHAT IS WHAT? What is what? 1. Grass blade 18. Locking nut 2. Grease filler cap 19. Support flange 3. Bevel gear 20. Support cup 4. Cutting attachment guard 21. Drive disc 5. Shaft 22. Trimmer head 6. Handlebar 23. Socket spanner 7.

  • Page 5: General Safety Precautions

    GENERAL SAFETY PRECAUTIONS Important Personal protective equipment IMPORTANT! The machine is only designed IMPORTANT! A clearing saw, brushcutter for trimming grass, grass clearing and/or or trimmer can be dangerous if used incor- forestry clearing. The only accessories you rectly or carelessly, and can cause serious can operate with this engine unit are the cut- or fatal injury to the operator or others.

  • Page 6: Machine's Safety Equipment

    GENERAL SAFETY PRECAUTIONS CLOTHING Wear clothes made of a strong fabric and avoid loose clothing that can catch on shrubs and branches. Always wear heavy, long pants. Do not wear jewelry, shorts sandals or go barefoot. Secure hair so it is above shoulder level.
  • Page 7 GENERAL SAFETY PRECAUTIONS Stop switch Harness quick release Make sure the engine stops when you push There is an easily accessible, harness and hold the stop switch. quick release fitted at the front in case of an emergency that requires you to free your- self from the machine and harness.

  • Page 8: Cutting Equipment

    GENERAL SAFETY PRECAUTIONS When fitting, tighten the nut in the opposite direction to the direction of rotation of the cutting attachment. To remove it, undo the nut in the same direction as the cutting at- tachment rotates. (CAUTION! The nut has a left- -hand thread.) Tighten the nut using the socket spanner.
  • Page 9 GENERAL SAFETY PRECAUTIONS Cutting equipment Check the cutting attachment for damage or cracks. A damaged cutting attachment should always be replaced. Saw blades are intended for cutting fibrous types of wood. Grass blades and grass cutters are Sharpening grass cutters and intended for cutting coarse grass.
  • Page 10 GENERAL SAFETY PRECAUTIONS Trimmer head IMPORTANT! Always ensure the trimmer line is wound tightly and evenly around the drum, other- S The filing angle is 15 degrees. File alter- wise the machine will generate harmful nate teeth to the right and those in be- vibration.

  • Page 11: Assembly

    ASSEMBLY NOTE: Make sure unit is assembled cor- rectly as shown in this manual. Fitting the handlebar S Remove the screw at the rear of the throttle handle. S Slide the throttle handle onto the right side of the handlebar (see illustration). Fitting the harness WARNING: When using a...

  • Page 12: Fitting Blades And Trimmer Heads

    ASSEMBLY Correct height IMPORTANT! Adjust the harness so that the cutting at- If a saw blade or grass blade is to be used, tachment is parallel to the ground. the machine must be equipped with the cor- rect handlebar, blade guard and harness. Fitting a blade guard, grass blade and grass cutter Correct balance...

  • Page 13: Fitting The Blade Guard And Saw Blade

    ASSEMBLY Fitting the blade guard and S When loosening and tightening the saw blade nut, there is a risk of injury from the saw blade teeth of the saw blade. You should there- fore always ensure that your hand is shielded by the blade guard when doing this.

  • Page 14: Fuel Handling

    -term storage. engines. Mixture 1:50 (2%). S The transport guard must always be S If JONSERED two- -stroke oil is not avail- fitted to the cutting attachment when the able, you may use another two-stroke oil of machine is being transported or in stor- good quality that is intended for air cooled age.

  • Page 15: Fueling

    FUEL HANDLING Mixing Fueling S Always mix the petrol and oil in a clean container intended for fuel. S Always start by filling half the amount of the petrol to be used. Then add the entire amount of oil. Mix (shake) the fuel mixture. WARNING: Taking the following Add the remaining amount of petrol.

  • Page 16: Starting And Stopping

    STARTING AND STOPPING Check before starting Starting and stopping S Check the blade to ensure that no cracks WARNING: have formed at the bottom of the teeth or The complete clutch, by the centre hole. The most common rea- clutch cover, and shaft must be son why cracks are formed is that sharp fitted before the machine is started, corners have been formed at the bottom of...
  • Page 17 STARTING AND STOPPING For throttle handles with a start throttle lock- -out: Set the throttle to the start position by first pressing the throttle lock- -out and the throttle trigger, then pressing the start throttle button (A). Then release the throttle lock- -out and the throttle trigger, followed by the start throttle button.

  • Page 18: Working Techniques

    WORKING TECHNIQUES General working instructions 5. Take great care when cutting a tree that is in tension. A tree that is in tension may spring back to its normal position before or IMPORTANT! after being cut. If you position yourself This section describes the basic safety pre- incorrectly or make the cut in the wrong cautions for working with trimmers.

  • Page 19: Basic Working Techniques

    WORKING TECHNIQUES S Work systematically to and fro across the WARNING: Watch out for area, clearing a width of around 12- -15 feet thrown objects. Always wear ap- (4- -5 meters) on each pass. This exploits proved eye protection. Never lean the full reach of the machine in both direc- over the cutting attachment guard.
  • Page 20 WORKING TECHNIQUES S To fell to the left, the bottom of the tree should be pushed to the right. Tilt the blade and bring it diagonally down to the right, exerting firm pressure. At the same time push the stem using the blade guard.
  • Page 21 WORKING TECHNIQUES Grass clearing using a grass blade S Grass blades and grass cutters must not be S The trimmer line can easily remove grass used on woody stems. and weeds up against walls, fences, trees and borders, however it can also damage S A grass blade is used for all types of tall or sensitive bark on trees and bushes, and coarse grass.
  • Page 22 WORKING TECHNIQUES S Do not allow the trimmer head to con- - WARNING: Neither the operator stantly come into contact with the ground of the machine nor anyone else may during normal cutting. Constant contact attempt to remove the cut material of this type can cause damage and wear while the engine is running or the to the trimmer head.

  • Page 23: Maintenance

    The idle speed is correctly adjusted when Carburetor the engine will run smoothly in every posi- Your Jonsered product has been designed tion. The idle speed should also be well and manufactured to specifications that re- below the speed at which the cutting attach- duce harmful emissions.

  • Page 24: Muffler

    MAINTENANCE Unit/Maintenance Safety WARNING: The inside of the Disconnect the spark plug before perform- muffler contain chemicals that may ing maintenance, except carburetor adjust- be carcinogenic. Avoid contact with ments. these elements in the event of a damaged muffler. Muffler WARNING: Bear in mind that: Engine exhaust fumes contain car-...

  • Page 25: Air Filter

    MAINTENANCE Air filter Bevel gear The air filter must be regularly cleaned to The bevel gear is filled with the right quan- remove dust and dirt in order to avoid: tity of grease at the factory. However, be- S Carburetor malfunctions fore using the machine you should check S Starting problems that the bevel gear is filled three- -quarters...

  • Page 26: Maintenance Schedule

    MAINTENANCE Maintenance schedule The following is a list of the maintenance that must be performed on the machine. Most of the items are described in the Maintenance section. The user must only carry out the main- tenance and service work described in this Operator’s Manual. More extensive work must be carried out by an authorised service workshop.

  • Page 27: Technical Data

    TECHNICAL DATA Technical data CC 2128 Engine Cylinder displacement, cm Cylinder bore, mm Stroke, mm 28,7 Idle speed, rpm 2800- -3200 Recommended max. fast idle speed, rpm 11000 Speed of output shaft, rpm 8000 Max. engine output, according to ISO 8893, kW Catalytic converter muffler Speed- -regulated ignition system Ignition system...

  • Page 28: Ec- -Declaration Of Conformity (Applies To Europe Only)

    We, Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46- -36- -146500, as authorised representative in the Community, declare that the brushcutter model Jonsered CC 2128 with serial numbers dating from 2009 and onwards (the year is clearly stated on the rating plate, followed by the serial number), comply with the requirements of the COUNCIL’S...
  • Page 29 Trimmer Head Line Loading Instructions English--- 29 115305026 Rev. 3 7/15/10...
  • Page 30 Plastic Blades (Tri Cut) English--- 30 115305026 Rev. 3 7/15/10...
