Amigo Classic Owner's Manual

Mobility scooter

Advertisement

Quick Links

O W N E R ' S &
O P E R AT I N G
M A N U A L
Re a d T h i s M a n u a l
B e f o r e O p e r a t i n g
Serial Number:
Purchase Date:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Classic and is the answer not in the manual?

Questions and answers

Summary of Contents for Amigo Classic

  • Page 1 O W N E R ’ S & O P E R AT I N G M A N U A L Re a d T h i s M a n u a l B e f o r e O p e r a t i n g Serial Number: Purchase Date:...
  • Page 2: Table Of Contents

    Wishing you happiness and good health from all of us at Amigo Company Amigo Mobility International, Inc. (AMI) disclaims any responsibility for personal injury or property damage resulting from the improper or unsafe use of its products.
  • Page 3: Safety First

    • Do not drive over or off obstacles more than 1 inch (2.5 cm) high. This could be unsafe and could damage your Amigo. • Do not turn your Amigo at high speeds, as this could result in tipping.
  • Page 4: Location Of Controls

    • Do not operate your Amigo near stairs, steps, curbs or terraces where you might accidentally drop a wheel off the edge. • Do not operate your Amigo on streets or other areas with vehicular traffic. • Do not disengage your brake lever when parked on a slope.
  • Page 5: Assembling Your Amigo

    5 Tip Amigo upright, so it is resting on its wheels. 6 Unlock and remove Seat. 7 Lift Rear Platform into trunk of vehicle. Place parts in trunk. DO NOT LIFT THE AMIGO CLASSIC TILLER BY THE BATTERY CASE HANDLE.
  • Page 6: Adjusting Your Amigo

    ADJUSTING YOUR AMIGO To adjust your Amigo to a comfortable driving position, you can alter the Handle, Seat and Armrests as follows: EZ-Tilt Handle Adjustment To adjust the angle of the Handle, turn the Adjustment Lever counterclockwise. Move the Figure 1 Handle to the desired position.
  • Page 7: Operating Your Amigo

    Approach an unfamiliar door slowly. Does it have a knob or push bar? Does it open toward or away? Think in terms of using the power of the Amigo to do the work for you. Hold the doorknob or bar in one hand and apply the power with the other hand.
  • Page 8: Safety Warnings

    SAFETY WARNINGS The driving performance of your Amigo can be influenced by electromagnetic fields, such as emitted by cellular telephones and other emitting devices. We recommend the power on your unit be switched off when using such a device.
  • Page 9: Battery Information

    Battery range depends on driver weight, terrain and type of battery used. Charge your batteries daily when the Amigo is used. Make sure that the Charger Cord is unplugged from the wall outlet before moving your Amigo. Batteries should be charged, if the Battery Indicator Light is blinking while operating.
  • Page 10: Cleaning Instructions

    Don’t use solvents on Tires as they cause tire material to break down or become too soft. Platform: The Platform of the Amigo is constructed of steel and coated with a durable automotive type finish. Use cool water with mild soap to remove dirt and oils. Do not spray the entire vehicle with water. This will damage the electrical parts.
  • Page 11: Maintenance

    Check the following: Daily Charge Batteries daily when the Amigo is used. Charge the Battery until fully charged to ensure proper Battery operation. Extended charging is good for the Batteries and will not overcharge them.
  • Page 12: Battery Replacement

    Fuse Replacement Instructions A Fuse protects the wiring and battery in the event of a short circuit. If your Amigo stops abruptly, check the Fuse. If it has “blown,” check for overloads or short circuits. The Fuse is located on the Battery Case. To replace the Fuse: •...
  • Page 13: Troubleshooting

    TROUBLESHOOTING The Amigo is equipped with an ASIC Controller. This Controller has a Built-In Diagnostic Feature that will cause the Battery Indicator Light (LED) to flash a numeric code to indicate when there is a service problem. Under normal operating conditions the Battery Indicator LED will flash to indicate three different situations.
  • Page 14: Electromagnetic Interference

    ELECTROMAGNETIC INTERFERENCE RADIO WAVE SOURCES MAY AFFECT POWERED MOBILE VEHICLE CONTROL. Electromagnetic Interference (EMI) From Radio Wave Sources Powered vehicles may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios and cellular phones.
  • Page 15: Wiring Diagram

    WIRING DIAGRAM...
  • Page 16: Exploded View

    EXPLODED VIEW...
  • Page 17: Parts List

    PARTS LIST #800000 CLASSIC PARTS LIST- AMI0070505 TO PRESENT Part# Description Qty/Unit Part# Description Qty/Unit Jackshaft bushing Ground wire asm 1035 8675 Retainer snap ring Wheel housing blue 1040 9357 Washer .65 ID .88 OD shim Charger 1.5 amp 24 volt...
  • Page 18: Warranty

    Cuts and tears in seats are not covered by warranty. 4 AMI warranties batteries supplied from its factory. AMI factory-supplied batteries carry Amigo brand labels. A six-month battery warranty from the date of purchase applies against the battery manufacturer’s defects in workmanship or materials.
  • Page 19 NOTES Date Remark Date Remark Date Remark Date Remark Date Remark Date Remark Date Remark...
  • Page 20 P h o n e (800) 248-9131 • F a x (800) 334-7274 • www. m y a m i g o . c o m © 2004 Amigo Mobility International, Inc. Amigo is a trademark of Amigo Mobility International, Inc. ®...
