- Page 1 Form: 122028B Airpax Dimensions, Inc. February 2007 4467 White Bear Parkway (651) 653-7000 St. Paul, MN 55110-7626 Fax (651) 653-7600 ISO 9001 Registered Company Airpax Dimensions, Inc. DC to AC Power Inverters Owners Manual for Models: MIL-24X26UVQ...
-
Page 2: Table Of Contents
Troubleshooting LED Messages ……………………………………..… Appendix ………………………………………………………………………………… Glossary ………………………………………………………………………………….. Limited Warranty ……………………………………………………………………… ************************************************* Headquarters: Airpax Dimensions, Inc. ● 4467 White Bear Pkwy. ● Saint Paul, MN 55110-7626 Phone: 651-653-7000 ● Toll Free 1-800-553-6418 ● Fax: 651-653-7600 e-mail: inverterinfo@Airpax.net ● Website: www.airpaxdimensions.com... -
Page 3: General
GENERAL Section 1 1.1 Safety Instructions Save This Manual Read this manual before installation, it contains important safety, installation, and operating instructions. Keep it in a safe place. All wiring must follow the National Electric Code, Provincial or other codes in effect at the time of installation, regardless of suggestions in this manual. - Page 4 1.1.2 Inverter Precautions • Inverters produce hazardous voltages. To avoid risk of harm or fire, the unit must be properly installed. • There are no user serviceable parts inside, do not remove the cover. • The inverter should not be mounted in a location that may be exposed to rain or water spray.
-
Page 5: Introduction
1.2 Introduction When operating, the direct current (DC) that enters the inverter from the batteries is filtered by a large input capacitor and switched “On” and “Off” by the Metal Oxide Silicon Field Effect Transistors (MOSFET) at a rate of 60 cycles per second, and directed into the transformer which steps the voltage up to 120 volts. -
Page 6: Specifications
1.3 Specifications Inverter Model 24X26UVQ Output Power (Continuous @ 50°C) 2600 Watts Peak Current AC 90 amps Output Current AC Up to 30 amps Output Rating 1 ½ HP Input Current DC Up to 130 amps Weight 55 Lb Chassis Size: LxHxW 15.75"x11.5"x7.75"... -
Page 7: Description
DESCRIPTION Section 2 2.1 Controls and Indicators 2.1.1 Inverter Module Description FIGURE 2: Chassis physical description Inverter On/Off switch: Switches the inverter on or off Output Breaker: Trips to protect the inverter from hardwire AC output short circuit or overload. Branch Breaker: Trips to protect the inverter from GFCI outlet short circuit or overload. -
Page 8: Control Panel Led Indicators
2.1.2 LED Control Panel Description FIGURE 3: LED Front Control Panel External power: Not used. Inverter power: The green LED indicates that the inverter is operating. Low Battery: The red LED indicates a low battery voltage condition. Overload: The red LED indicates an overload condition. High temp: The red LED indicates a high internal temperature. -
Page 9: Support Items
2.2 Support Items 2.2.1 General Overview An inverter support system consists of all the equipment needed to supply DC power to the inverter. On a land vehicle the support system can be divided into two main categories depending on the size of the loads and their running time, these are: Light duty applications and heavy-duty applications. - Page 10 2.2.2 Deep Cycle Battery Theory There are two categories of lead acid deep cycle batteries; wet and sealed. Sealed batteries can be either gel cell or AGM (Absorbent Glass Mat) type. Deep cycle batteries are designed specifically for repetitive charge and discharge cycles. These batteries are also made to be discharged to a very low level before recharging.
- Page 11 a) Battery-to-Inverter Cable: If furnishing your own battery-to-inverter cable see figure 5 below, also see cable and fusing guide charts A and B in appendix section 6, page 21 then follow these steps: • Locate your inverter model in chart A. •...
-
Page 12: Installation
INSTALLATION Section 3 3.1 Inverter Components and Installation Tools 3.1.1 List of Inverter Components Check your packing slip against the following chart; make sure you received all the components listed. Picture Description and Part Number Quantity Inverter module 24X26UVQ 3.1.2 Tools for Installation Below is the list of useful tools required for the installation of the inverter •... -
Page 13: Mounting The Inverter
3.2 Mounting the Inverter 3.2.1 Mounting the Inverter Module: The inverter mounting location should provide adequate ventilation and clearance to maintain room temperature during operation. At least 1/2 inch of clearance is required on all sides. a) Locate a suitable, secure vertical or horizontal mounting surface as close to the batteries as possible without being in the same airtight compartment. -
Page 14: Inverter Wiring
3.3 Inverter Wiring Reference figure 7, page 16 DC wiring and figure 8, page 17 AC wiring diagram. 3.3.1 Grounding: Connect an 8 gauge copper wire between the bonding lug located at the right side of the chassis on the inverter and the earth grounding system of the vehicle chassis. - Page 15 3.3.4 Remote On/Off Switch: An optional customer supplied remote On/Off switch may be connected to the inverter and mounted at a convenient location. The remote switch will operate only if the inverter On/Off switch on the face of the inverter is turned a) Remove the in-line fuse from the fuse holder located on the positive (+) battery to inverter assembly wire.
- Page 16 Red cable (+) Black Cable (-) In-line Fuse 120 VAC, 60 Hz Output (See page 17) Auxiliary To vehicle Battery alternator or vehicle battery Customer supplied remote On/Off switch Customer supplied Fuse In-line Fuse FIGURE 7: DC Wiring Diagram...
- Page 17 Field Wiring Compartment White-Neutral Black-Hot Green-Ground Output Distribution Panel Breaker 15A or 20A 15A or 20A 15A or 20A Breaker Breaker Breaker 120 VAC, 60Hz Output If the inverter does not have the option "A", then install GFCI outlets as required by code.
-
Page 18: Operation
OPERATION Section 4 4.1 Startup 4.1.1 General: After successful installation to operate the inverter do the following: Switch the inverter front panel switch to ON. The Green LED “Inverter Power” will come on. If the optional customer supplied remote switch is used, the inverter is switched ON or OFF by the remote switch. -
Page 19: Troubleshooting
TROUBLESHOOTING Section 5 Call Customer Service Department for free phone consultation during business (central time zone) hours at: 1-800-553-6418 or 1-651-653-7000; fax number 1-651-653-7600; e-mail: inverterinfo@Airpax.net 5.1 Inverter Troubleshooting: 5.1.1 Important Notes: Since the inverter has a quasi-sine waveform a TRUE RMS voltmeter is required for accurate AC voltage readings. -
Page 20: Troubleshooting Led Messages
5.2 Red LED Troubleshooting Messages LED Light PROBLEM POSSIBLE CAUSE inverter Check the in-line fuses for continuity. Make sure No LEDs connected to the batteries the DC wires are clean and tight. Check the DC or the battery voltage is voltage at the inverter DC input. -
Page 21: Appendix
APPENDIX Section 6 Chart A: Wire Gauge Recommendations DC input wire gauge guide for 5% maximum DC voltage drop at full inverter output. Inverter Full Load Peak Wire length from inverter to battery Model (Amps) (Amps) 1’ – 10’ 11’ – 15’ 16’... - Page 22 Chart D: Industrial Electrical Product Wattage Ratings Watts 120 VAC Product (Full load) Amps. Inverter Model Air Compressor, 1 HP 2000 12X30U Quasi-sine Air Compressor, 3/4 HP 1500 12.5 12X25U Quasi-sine Air Cond, 9,000 BTU 1100 12X16U Quasi-sine Air Cond, 13,500 BTU 1620 13.5 12X20U...
- Page 23 Chart E: Battery Configuration: Batteries interconnect in two ways: Series or parallel. a) Series configuration: Increases voltage while keeping the Ampere Hour (AH) capacity constant. For example: Two deep cycle 12 Volt batteries @ 105 AH each connected in series, results in a total output of 24 Volts (12 Volts + 12 Volts) @ 105 AH b) Parallel configuration: Increases capacity while keeping the voltage constant.
- Page 24 Chart H: Waveform Discussion Pure sine waveform electrical power is the world's standard waveform for the electrical utility grid (see figure a below). This waveform is the naturally occurring waveform that is emitted from a rotating electrical generator, so it was a logical decision to make this the standard.
-
Page 25: Glossary
GLOSSARY Section 7 AGM: (Absorbent Glass Mat) A lead-acid battery that incorporates a sponge glass mat separator to immobilize the electrolyte. Because of the immobilized electrolyte, AGM batteries will not leak or spill. Alternating Current: Pulsating electric energy in which the direction of the electron flow is rapidly changed, so the end terminal becomes in rapid succession electrically positive, then negative. - Page 26 Open Circuit Voltage: The voltage at a battery terminal when no appreciable current is flowing. Polarity: The quality of an object characterized by two opposite charges, as in the positive and negative poles of a battery. Pure sine wave: World’s standard waveform for the electrical utility grid. This waveform is the naturally occurring waveform that is emitted from a rotating electrical generator.
-
Page 27: Limited Warranty
Material Authorization (RMA). Once obtained, send the Return Material Authorization Number along with the defective part or goods to: Airpax Dimensions, Inc., 4467 White Bear Parkway, St. Paul, MN 55110, freight prepaid. THERE ARE NO EXPRESS WARRANTIES COVERING THESE GOODS OTHER THAN AS SET FORTH ABOVE. THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED IN DURATION TO ONE YEAR FROM DATE OF PURCHASE.
