Summary of Contents for Airpax Dimensions 12/800N
- Page 1 121139C Airpax Dimensions, Inc. 4467 White Bear Parkway (651) 653-7000 St. Paul, MN 55110-7626 Fax (651) 653-7600 OWNERS MANUAL JANUARY 2007 ISO 9001:2000 Certified Company Airpax Dimensions, Inc. DC to AC Power Inverters OWNERS MANUAL for Models: 12/800N 12/1200N Form 121139...
-
Page 2: Table Of Contents
Model (VDC) (ADC) (VAC) (Watts) 1.02 CAUTION: Inverters produce hazardous 12/800N 12.6 Up to 80 voltages, to avoid risk of harm or fire the unit must 12/1200N 12.6 Up to 120 120 1200 be properly installed. There are no user service- able parts inside, do not remove the cover. - Page 3 Distance(feet) manual. All wires should be copper conductors. Model 1-10 11-15 16-20 3.03 Mounting 12/800N 6 ga 4 ga 2 ga 3.03.1 Locate a suitable, secure vertical or 12/1200N 4 ga 2 ga 1 ga...
-
Page 4: Start Up/Operation
4. START-UP/OPERATION 5.03 Call Airpax Dimensions, Inc. for technical 4.01 To operate the inverter, turn the switch assistance and/or a return authorization number if to "ON". Assure that the output breakers are the above steps are completed and the inverter still reset. -
Page 5: Installation Figure
Figure #1 WARNING: CONNECTING THE BATTERY WITH THE WRONG POLARITY TO THE INVERTER WILL CAUSE DAMAGE THAT IS NOT COVERED UNDER THE WARRANTY. FRONT VIEW Output breaker External power Customer Installed Option Inverter power Low battery Remote Switch Pos. from Overload Violet Wire Fuse... -
Page 6: Limited Warranty
Lading and Delivery receipt with damage noted therein must accompany any claims for freight damage. Claims for shortage and lost shipments must be made in writing to Airpax Dimensions, St. Paul, MN within 10 days of date of shipment. Claims not reported within this time frame will not be honored.
