Airpax Dimensions ADI-64/500 Owner's Manual

Dc to ac power inverters
Hide thumbs

Advertisement

Table of Contents

121335B
Airpax Dimensions, Inc.
4467 White Bear Parkway
(651) 653-7000
St. Paul, MN 55110-7626
Fax (651) 653-7600
OWNERS MANUAL
JANUARY 2007
Airpax Dimensions, Inc.
DC to AC Power Inverters
OWNERS MANUAL for Model:
ADI-64/500
Form 121335

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADI-64/500 and is the answer not in the manual?

Questions and answers

Related Manuals for Airpax Dimensions ADI-64/500

Summary of Contents for Airpax Dimensions ADI-64/500

  • Page 1 121335B Airpax Dimensions, Inc. 4467 White Bear Parkway (651) 653-7000 St. Paul, MN 55110-7626 Fax (651) 653-7600 OWNERS MANUAL JANUARY 2007 Airpax Dimensions, Inc. DC to AC Power Inverters OWNERS MANUAL for Model: ADI-64/500 Form 121335...

  • Page 2: Table Of Contents

    OWNERS MANUAL CAUTION: The inverter contains a circuit breaker and capacitor that may produce a FOR AIRPAX DIMENSIONS spark. Do not mount in a confined battery or INVERTERS gas compartment. Model ADI-64/500 CAUTION: Working in the vicinity of lead- acid batteries is dangerous.
  • Page 3 if correct polarity is not observed when install- input capacitor. ing the DC input cables. 3.05.2 Use stranded copper wire be- CAUTION: Damage to the inverter will occur tween the battery and inverter as indicated. if an external AC power source is applied to the Aline fuse must be installed between the inverter’s AC outlet or its hardwire output.

  • Page 4: Start Up/Operation

    If the above steps are Call the Customer Service Department at: completed and the inverter still will not oper- 1-651-653-7000 or 1-800-553-6418 ate satisfactorily, call Airpax Dimensions, Inc. fax: 1-651-653-7600 for a return authorization number. e-mail: inverterinfo@Airpax.net NOTE: Because the inverter has a quasi-sine waveform, a TRUE RMS voltmeter (such as a Fluke 87) is required for an accurate reading.

  • Page 5: Installation Figure

    FRONT VIEW Output breaker External power Inverter power Low battery Overload High Temperature Charge voltage Fuse adjustment Fuseholder and Fuse Inverter 64 VDC Source Bonding Lug AC Hardwire Output Page 5...

  • Page 6: Limited Warranty

    Invoice, Bill of Lading and Delivery receipt with damage noted therein must accompany any claims for freight damage. Claims for shortage and lost shipments must be made in writing to Airpax Dimensions, St. Paul, MN within 10 days of date of shipment. Claims not reported within this time frame will not be honored.
