WIDE RANGE SPEAKER

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS ........................... 2
AND FEATURES ........................................ 3
3. IMPEDANCE CHANGE .............................. 3
is Required ......................................... 4
is Required ..........................................5
Thank you for purchasing TOA's Wide Range Speaker.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
Traceability Information for Europe (EMC directive 2004/108/EC)
Manufacturer:
TOA Corporation
7-2-1, Minatojima Nakamachi, Chuo-ku, Kobe, Hyogo,
Japan
INSTRUCTION MANUAL
5. INSTALLATION PRECAUTION ................. 7
6. DIMENSIONAL DIAGRAM ......................... 8
7. WIRING DIAGRAM ..................................... 8
8. FREQUENCY RESPONSE ......................... 8
9. SPECIFICATIONS ...................................... 9
Authorized representative:
TOA Electronics Europe GmbH
Suederstrasse 282, 20537 Hamburg,
Germany
CS-64BS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS-64BS and is the answer not in the manual?

Questions and answers

Related Manuals for Toa CS-64BS

Summary of Contents for Toa CS-64BS

  • Page 1: Table Of Contents

    Required ......... 4 4.2. When Bridge Connection is Required ..........5 Thank you for purchasing TOA's Wide Range Speaker. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment. Traceability Information for Europe (EMC directive 2004/108/EC)

  • Page 2: Safety Precautions

    • Ensure that all screws are securely tightened. If remove the speaker case. Refer all servicing to they are loose after installation, the speaker could your nearest TOA dealer. fall down, possibly resulting in personal injury. • Do not mount the speaker in locations exposed to constant vibration.

  • Page 3: General Description And Features

    It is comprised of a high-efficiency weather-resistant horn and a high quality sound cone speaker, providing clear and highly directional sound reproduction. The CS-64BS is certified to the European Standard EN 54-24: 2008 and the International Standard ISO 7240- 24: 2010, and is compliant with the British Standard BS 5839-8: 2008.

  • Page 4: Wiring

    4. WIRING The terminal cover is not mounted to the speaker unit when shipped from the factory. Note To complete speaker installation, be sure to attach the terminal cover after finishing cable connections. If the unit is left without the terminal cover attached, water or moisture may get inside the speaker, causing the unit malfunction.

  • Page 5: When Bridge Connection Is Required

    Step 4. Attach the terminal cover. Secure the terminal cover using the 4 supplied screws. In this case, take care not to pinch the wiring, and check that the waterproof gasket is secured into place. Note If wiring or the waterproof gasket is pinched between the terminal cover and the unit case, this causes water or moisture to get inside the terminal cover.
  • Page 6 Step 2. Mount the cable gland to be added. Notes • Prepare the cable gland of PG 13.5 size separately. • Ensure that the cable gland is securely tightened. If loosely tightened, water may get inside the terminal cover. Waterproof gasket Cable gland Terminal cover Step 3.

  • Page 7: Installation Precaution

    Step 6. Attach the terminal cover. Secure the terminal cover using the 4 supplied screws. In this case, take care not to pinch the wiring, and check that the waterproof gasket is secured into place. Note If wiring or the waterproof gasket is pinched between the terminal cover and the unit case, this causes water or moisture to get inside the terminal cover.

  • Page 8: Dimensional Diagram

    6. DIMENSIONAL DIAGRAM 233 (9.17) 249 (9.8) 208 (8.19) 146 (5.75) 211 (8.31) (2.01) (2.01) Unit: mm (in) ø13 (0.51) 2-ø11 (0.43) 7. WIRING DIAGRAM Thermal fuse (84°C or 183.2°F) 10 kΩ 3.3 kΩ EARTH 8 Ω 1.7 kΩ 830 Ω Screw terminal Rotary switch...

  • Page 9: Specifications

    9. SPECIFICATIONS Standards Certified to the European Standard EN 54-24: 2008 EN 54-24: 2008 Loudspeaker for voice alarm systems for fire detection and fire alarm systems 0359-CPD-0107 0359 Certification No. 0359-CPD-0107 Certified to the International Standard ISO 7240-24: 2010 Sound-system loudspeaker for fire detection and fire alarm systems In Compliance with the British Standard BS 5839-8: 2008 14.8 Environment Type...
  • Page 12 URL: http://www.toa.jp/ 533-06-245-20...
