INSTALLER AND OWNER GUIDE
Model 820
Electric Heater
Fitted with one of the following fascia.
Blenheim
GC No. EF-032-33
This guide is intended to help you
install and care for your Valor Fires
electric heater. Please read carefully
before installing and using your
heater. However, if further
information is required, our
Valor Fires Technical Helpline will
be pleased to help.
Telephone 0844 8711 565 (National
call rates apply in the United
Kingdom).
In the Republic of Ireland
Telephone 0044 844 8711 565.
Important: Please keep your guide in a safe place for future reference.
©
Baxi Heating U.K. Limited 2010.
Seattle
or
5133239-02

Advertisement

loading
Need help?

Need help?

Do you have a question about the 820 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Valor Fires 820

Summary of Contents for Valor Fires 820

  • Page 1 Fitted with one of the following fascia. Blenheim Seattle GC No. EF-032-33 This guide is intended to help you install and care for your Valor Fires electric heater. Please read carefully before installing and using your heater. However, if further information is required, our Valor Fires Technical Helpline will be pleased to help.
  • Page 2 CUSTOMER CARE Thank you for choosing Valor Fires All Valor Fires heaters are designed to meet the most stringent quality, performance and safety requirements to provide our customers with many years of trouble free service. This guide aims to improve your understanding and appreciation of your new...
  • Page 3 0.63 * An optional spacer frame kit is obtainable either from the your heater supplier or direct from Valor Fires Sales. The kit is a 75mm (3 inch) spacer kit (Kit number 05801T1). One person should be sufficient to lift the heater. If for any reason this weight is considered too heavy then obtain assistance.
  • Page 4 Always use a fireguard when young children, infirm persons and pet animals can come into contact with the heater. Always use genuine Valor Fires spare parts. Never Never leave children unsupervised in a room where the heater is ON and unguarded.
  • Page 5 INSTALLER AND OWNER GUIDE CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility. Important! This heater must be earthed.
  • Page 6 At least 75mm (At least 3 inches) An optional spacer frame kit is obtainable either from the your heater supplier or direct from Valor Fires Sales. The kit is a 75mm (3 inch) spacer kit (Kit number 05801T1). Moving the cable guide.
  • Page 7 INSTALLER AND OWNER GUIDE 4. Hold the bottom of the cable guide close to the heater then gently pull the cable guide away from the rectangular slot (See figure 1- Item 3). Fitting the cable guide. When fitting the cable guide please remember that the wider part of the cable guide has to be fitted against the outer edge of the base (See figure 1- Item 1).
  • Page 8 INSTALLER AND OWNER GUIDE Heater fixing. All fixings supplied with the heater have been identified in figure 3. Contents Quantity (Illustrations are not to scale) Heater Wall plug Wood screw Eye screw Steel wire No.8 x 3/8 Screw M4 x 25mm Screw Washer Diffuser Control Knob...
  • Page 9 Spacer Frame*. * An optional spacer frame kit is obtainable either from the your heater supplier or direct from Valor Fires Sales. The kit is a 75mm (3 inch) spacer kit (Kit number 05801T1). If fitting the heater into a fireplace or surround opening, try the heater in the opening to ensure that it will fit.
  • Page 10 INSTALLER AND OWNER GUIDE marked positions. Insert wall plugs into the drilled holes. 5. Place the heater so that the slotted holes are in line with the wall plugs in the fixing surface. 6. Screw and secure the heater with two wood screws (See figure 3).
  • Page 11 INSTALLER AND OWNER GUIDE 9. At the back of the heater there will be a long piece and a short piece of wire coming through the two holes. Hold the short piece and give the long piece a gentle tug. This will secure the steel wire. Take the long piece and thread this through the eyescrew in the back of the fireplace opening (See figure 7 - item 4).
  • Page 12 INSTALLER AND OWNER GUIDE Fitting the heater. 1. Locate the spacer frame and heater over the screw heads ensuring a tight fit. If the fit is loose, remove the spacer frame and heater from the wall. Tighten the wall screws slightly and reposition the spacer frame and heater.
  • Page 13 INSTALLER AND OWNER GUIDE Seattle model. 1. With the fascia trim removed, unscrew and remove the two screws from the lower right hand side of the heater (See figure 13) then align the four holes in the firefront assembly with those on the heater (See figure 14).
  • Page 14 INSTALLER AND OWNER GUIDE 4. USING THE HEATER Important Safety Never cover the heater or obstruct the openings at the base of the heater, this could cause overheating and consequent risk of fire. Figure 15. Controls What are the three switches for? The heater is operated by three switches located below the hood on the left hand side of the heater.
  • Page 15 15 minutes and the obstruction removed before restarting. 3. I Have a problem that is different to those in the previous examples 1- 3. For general advice about your heater call: Valor Fires TECHNICAL HELPLINE 0844 8711 565. CALLERS IN THE REPUBLIC OF IRELAND Call 0044 844 8711 565 What should I do when I’m ready to dispose of my heater?
  • Page 16 INSTALLER AND OWNER GUIDE 6. WARRANTY AND SERVICE Information for the customer Standard Warranty Terms & Conditions The warranty is for 12 months subject to contract. In the United Kingdom servicing can be carried out either by a heateam service engineer or a suitably qualified person.
  • Page 17 INSTALLER AND OWNER GUIDE What this warranty does not cover Repairs to heaters which haven’t been installed properly and as set out in this guide. Faults caused by inadequate supply of electricity. Reimbursement of any third party repair or replacement costs that we haven’t been told about or agreed with you in advance.
  • Page 18 INSTALLER AND OWNER GUIDE © Baxi Heating U.K. Limited 2010. Page 18...
  • Page 19 INSTALLER AND OWNER GUIDE To be completed by the customer: Model Serial number (Can be found on the information label - See figure 16) A LABEL CONTAINING THE SERIAL NUMBER MAY HAVE BEEN PLACED INSIDE THIS BOX. Fascia name (Block Capitals) Fascia code - Can be found close to the information label (Block Capitals) A LABEL CONTAINING THE FASCIA CODE...
